Harmonic Filters Product Catalog

Harmonic Filters Product Catalog mtecorp.com

Non-linear power systems, found in Variable Frequency Drives (VFDs) and uninterrupted power supplies, can generate harmonic distortions that lead to overheated components, circuit breaker tripping, and inaccurate sensor measurements. Such problems result in wasted time and financial resources. At MTE, we offer a comprehensive range of harmonic mitigation solutions that effectively address these challenges. Our flagship product, Matrix AP, stands as the industry’s leading harmonic filter, while Matrix ONE excels as a single-phase solution. With our innovative solutions, we optimize system efficiency and enhance productivity, redefining the possibilities. Peace of mind delivered to you.

Contents Harmonic Filters Matrix® AP 2 Adaptive Passive Technology for superior harmonic mitigation at varying loads Matrix® E-Series 16 Power quality you’ve come to expect from the power quality experts Single Phase Matrix® One 22 Optimized harmonic filters with proven harmonic mitigation 1

Harmonics refer to the shape or features of a voltage or current waveform compared to its fundamental frequency. In power systems, the ideal scenario involves smooth sinusoidal waves without any harmonics. However, when waveforms deviate from this ideal sinusoidal shape, they introduce harmonics. These harmonics have the potential to distort the voltage waveform and cause various issues within the power system. A power system’s ability to perform at optimal levels is compromised when harmonic distortion enters the system. It creates inefficiencies in equipment operations due to the increased need for power consumption. The increase of overall current required creates higher installation and utility costs, heating, and decreasing profitability. Power system problems that can occur without a harmonic filter: • Increased installation and utility cost • Overheating of components • Equipment malfunction • Nuisance tripping of circuit breakers • Inaccurate measurements on sensors • Telecommunication interference What are Harmonics? The Destructive Effects of Harmonic Distortion MTE Sets The Benchmark For Power Quality Take Advantage of Our Expertise 2

What Level Of Harmonic Mitigation Do You Need? MTE offers a family of application engineered products designed for the performance you need. Harmonic Mitigation Is Essential For Extending Equipment Life mtecorp.com Total Harmonic Distortion (THID%) Dependent on Application Used. WITHOUT ANY harmonic mitigation, VFDs can generate THID in excess of 100% of the fundamental frequency. VFD Utility Power RL Reactors Matrix ONE (Single Phase) Matrix E-Series Matrix AP THID 30-40% THID 12% THID 8% THID <5% IEEE-519 STANDARD The IEEE-519 standard, established by the Institute of Electrical and Electronics Engineers (IEEE), provides guidance on managing harmonic distortion. This standard focuses on determining acceptable levels of harmonic distortion at the “point of common coupling,” which is the connection point between a facility and the public power system. Essentially, it serves as a guideline for setting limits on the amount of harmonic distortion that a facility can introduce back into the power grid. The purpose is to prevent individual customers from generating excessive harmonics that could cause unacceptable distortion for other nearby users. In return, the utility company commits to maintaining specified levels of voltage distortion supplied to the facility. 3

VFD Harmonic FIlter Utility Power mtecorp.com Harmonic Filters Matrix® AP Adaptive Passive Technology for superior harmonic mitigation at varying loads Matrix® E-Series Power quality you’ve come to expect from the power quality experts Single Phase Matrix® ONE Optimized harmonic filters with proven harmonic mitigation 4

Matrix® AP The key to success: adapt. Simply put, our Matrix® AP is the most advanced passive filter on the market today. Most traditional filters work fine at 100% power load, but severely underperform at lower loads. Matrix® AP is different, because we know almost no one runs at full load all the time. Its patented Adaptive Passive Technology virtually eliminates harmonic distortion by adapting to varying power loads. It delivers better THID performance, increases energy efficiency, and allows you to meet IEEE-519 requirements. Its unique design generates less heat, and is easy to install and maintain. Plus it is generator compatible. With Matrix® AP Harmonic Filters, power quality, energy efficiency and reduced downtime are easy to achieve. Adapts to varying power loads Best performance in the industry Extends the service life of electrical equipment Generator compatible Performance guarantee 5

Performance Specifications Service Load Condition Load: 6-pulse rectifier only Input Voltage 208 – 240V +/– 10%; 60 Hz; 3-phase 380 – 415V +/– 10%; 50 Hz; 3-phase 480V +/– 10%; 60 Hz; 3-phase 600V +/– 10%; 60 Hz; 3-phase 690V +/– 10%; 50 Hz; 3-phase Current Range 208 – 240V: 6A – 403A (3 HP – 150 HP) 380 – 415V: 6A – 1200A (1.1 kW – 600 kW) 480V: 6A – 2300A (3 HP – 1850 HP) 600V: 6A – 786A (5 HP – 800 HP) 690V: 52A – 636A (37 kW – 450 kW) Maximum THID 8% @ 30% load; 5% @ full load Maximum Ambient Temperature -40°C to +50°C open panel filter -40°C to +40°C – 45°C enclosed filter -40°C to +90°C storage Insertion Loss @ Full Load <5% Efficiency 97% – 99% Altitude Without Derating 3,300 feet above sea level Relative Humidity 0% to 95% non-condensing Current Rating 150% for 1 minute duration Final product specifications subject to change at any time. Matrix® AP The best-in-class Matrix® AP Harmonic Filters can be specified for use on the input of your VFD or other 6-pulse rectifier power supply to enable your system to meet the IEEE-519 requirements for harmonic distortion, regardless of power load. Features our patented Adaptive Passive Technology for superior harmonic mitigation and better THID performance over a wider load range. MTE performance guarantee provides peace of mind that the Matrix® AP will meet or exceed performance expectations – every time. Extends service life of electrical equipment, especially transformers and motors, due to the virtual elimination of CEMF and the skin effect. Alleviates system downtime by preventing blown fuses and tripped circuit breakers. Industry leading THREE year warranty because the best products deserve the best warranty. Matrix® AP Harmonic Filters can help ensure that your system meets the IEEE-519 requirements for harmonic current. 3.0 3.5 4.0 4.5 5.0 5.5 6.0 6.5 7.0 7.5 8.0 8.5 9.0 9.5 10.0 10.5 11.0 11.5 12.0 12.5 13.0 13.5 0 10 20 30 40 50 60 70 80 90 100 Matrix AP - Generator Compatible Competition A - Not Generator Compatible Competition B - Not Generator Compatible Competition C MTE vs. Competition THID [%] Matrix® AP Filters Utility Power VFD Percentage of full load [%] Percent THID [%] Improve power quality and reduce downtime with our patented Adaptive Passive Technology. 6

mtecorp.com Matrix® AP Filters Matrix® AP Options Contactor Option 002: Contactor for capacitor disconnect • Includes NO/NC auxiliary contacts • Wired to customer terminal block • Pre-wired within enclosed part numbers • Requires 120V 50/60Hz power source Contactor Option 012: Contactor with control transformer (Only available for enclosed filters) • Option 002 including a 120 VAC control transformer Contactor Option 009: Contactor with adjustable pick up and drop out (Only available for enclosed filters) • Includes NO/NC auxiliary contacts • Includes a 120 VAC control transformer • Includes two current operated switches • Ability to adjust pick-up and drop current levels • Switches are preset at factory Pick-up is 35% of filter output current rating Drop out is 20% of filter output current rating Contactor Option 013: Filter bypass and capacitor contactor with control transformer (Only available for enclosed filters) • Includes NO/NC auxiliary contacts • Includes a 120 VAC control transformer • Pilot relay provided to limit inrush current • Jumper selection allows for single contact switching (Normal bypass control with capacitor removal) Option – 400: Standard NEMA 3R enclosure with optional rodent/serpent screen. • Provides intake exhaust air screens with (¼ x ¼) mesh • Not available on units 1600A (480V) and above Understanding the Matrix® AP Part Number: Voltage Frequency Code A 208 – 240 Volts 60 Hz C 380 – 415 Volts 50 Hz D 480 Volts 60 Hz E 600 Volts 60 Hz F 690 Volts 50 Hz Optional Contactor Options 002 - Contactor for capacitor disconnect 012 - Contactor with control transformer 009 - Contactor with adjustable pick up and drop out 013 - F ilter bypass and capacitor contactor with control transformer Enclosure Type P = Open Magnetics (No Enclosure) G = General Purpose (NEMA 1/2) W = Weather (NEMA 3R) Current Rating 0006 is 6 Amps 0083 is 83 Amps 2300 is 2300 Amps Matrix® AP How to properly size your filter MAP X _ _ _ _ X _ _ _ • Determine voltage and frequency requirements • Reference motor nameplate to determine motor HP or kW and Full Load Amps • Select filter based on Motor Full Load Amps Do not exceed filter's maximum current rating (amps) • Specify enclosure style Open (No enclosure) NEMA 1/2 (General Purpose Enclosure) NEMA 3R (Outdoor Enclosure) • Determine derating requirements Reference Performance Specifications table on previous page • Select desired options (if applicable) 7

MATRIX® AP SELECTION TABLES Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. S = Standard stock offering * = Call for availability 208 – 240V 60Hz Motor (Ref Only) Filter Amps Rating Catalog No. Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Capacitor/Capacitor Panel Assembly Dimensions (H x W x D) Qty Req’d Ref Fig Available Options HP Inches Millimeters Lbs Kgs Inches Millimeters 002 009 012 013 1.5 6 MAPP0006A OPEN 8.5 x 8.0 x 5.4 216 x 203 x 137 19 9 3 95 7.5 x 3.0 191 x 76 1 2 S * * * MAPG0006A NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 65 29 6 Preinstalled in cabinet * * * * MAPW0006A NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 73 33 * * * * 2 8 MAPP0008A OPEN 8.5 x 8.0 x 5.4 216 x 203 x 137 19 9 3 102 7.5 x 3.0 191 x 76 1 2 S * * * MAPG0008A NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 65 29 6 Preinstalled in cabinet * * * * MAPW0008A NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 73 33 * * * * 3 11 MAPP0011A OPEN 8.6 x 8.0 x 5.4 218 x 203 x 137 22 10 3 122 7.5 x 3.0 191 x 76 1 2 S * * * MAPG0011A NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 69 31 6 Preinstalled in cabinet * * * * MAPW0011A NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 77 35 * * * * 4 14 MAPP0014A OPEN 8.6 x 8.0 x 5.4 218 x 203 x 137 21 10 3 180 7.5 x 3.0 191 x 76 1 2 S * * * MAPG0014A NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 68 31 6 Preinstalled in cabinet * * * * MAPW0014A NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 76 34 * * * * 5 21 MAPP0021A OPEN 9.8 x 8.0 x 4.8 249 x 203 x 122 30 14 3 187 9.1 x 4.6 231 x 117 1 2 S * * * MAPG0021A NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 77 35 6 Preinstalled in cabinet * * * * MAPW0021A NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 85 39 * * * * 7.5 27 MAPP0027A OPEN 9.7 x 9.0 x 5.3 246 x 229 x 135 36 16 3 191 9.1 x 4.6 231 x 117 1 2 S * * * MAPG0027A NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 84 38 6 Preinstalled in cabinet * * * * MAPW0027A NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 92 42 * * * * 10 34 MAPP0034A OPEN 11.7 x 10.5 x 6.7 297 x 267 x 170 51 23 3 217 10.6 x 4.6 269 x 117 1 2 S * * * MAPG0034A NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 98 44 6 Preinstalled in cabinet * * * * MAPW0034A NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 105 48 * * * * 15 44 MAPP0044A OPEN 11.6 x 10.5 x 7.2 295 x 267 x 183 52 24 3 269 9.0 x 4.6 229 x 117 1 2 S * * * MAPG0044A NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 100 45 6 Preinstalled in cabinet * * * * MAPW0044A NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 108 49 * * * * 20 52 MAPP0052A OPEN 11.7 x 10.5 x 7.2 297 x 267 x 183 56 25 3 287 9.0 x 3.5 229 x 89 1 2 S * * * MAPG0052A NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 105 48 6 Preinstalled in cabinet * * * * MAPW0052A NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 109 49 * * * * 25 66 MAPP0066A OPEN 11.6 x 10.5 x 7.7 295 x 267 x 196 64 29 3 334 9.0 x 3.9 229 x 99 1 2 S * * * MAPG0066A NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 112 51 6 Preinstalled in cabinet * * * * MAPW0066A NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 120 54 * * * * 30 83 MAPP0083A OPEN 11.6 x 10.5 x 9.1 295 x 267 x 231 77 35 4 373 9.0 x 3.9 229 x 99 1 2 S * * * MAPG0083A NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 124 56 6 Preinstalled in cabinet * * * * MAPW0083A NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 132 60 * * * * 40 103 MAPP0103A OPEN 14.0 x 12.0 x 9.6 356 x 305 x 244 111 50 4 475 10.6 x 4.6 269 x 117 2 2 S * * * MAPG0103A NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 185 84 7 Preinstalled in cabinet * * * * MAPW0103A NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 195 88 * * * * 8

mtecorp.com Matrix® AP Filters Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. S = Standard stock offering * = Call for availability 208 – 240V 60Hz Motor (Ref Only) Filter Amps Rating Catalog No. Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Capacitor/Capacitor Panel Assembly Dimensions (H x W x D) Qty Req’d Ref Fig Available Options HP Inches Millimeters Lbs Kgs Inches Millimeters 002 009 012 013 50 128 MAPP0128A OPEN 14.0 x 12.0 x 10.8 356 x 305 x 274 134 61 4 558 10.6 x 4.6 269 x 117 2 2 S * * * MAPG0128A NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 207 94 7 Preinstalled in cabinet * * * * MAPW0128A NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 218 99 * * * * 60 165 MAPP0165A OPEN 13.9 x 12.0 x 12.3 353 x 305 x 312 157 71 4 601 10.6 x 4.6 269 x 117 1 2 S * * * 9.0 x 4.6 229 x 117 1 MAPG0165A NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 232 105 7 Preinstalled in cabinet * * * * MAPW0165A NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 243 110 * * * * 75 208 MAPP0208A OPEN 14.0 x 12.0 x 13.4 356 x 305 x 340 174 79 4 681 9.0 x 4.6 229 x 117 2 2 S * * * MAPG0208A NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 249 113 7 Preinstalled in cabinet * * * * MAPW0208A NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 259 117 * * * * 100 240 MAPP0240A OPEN 19.9 x 15.3 x 11.9 505 x 389 x 302 225 102 4 1,093 6.7 x 7.6 x 16.4 170 x 193 x 417 1 1 S * * * MAPG0240A NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 396 180 7 Preinstalled in cabinet * * * * MAPW0240A NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 407 185 * * * * 125 320 MAPP0320A OPEN 19.9 x 15.3 x 12.8 505 x 389 x 325 263 119 4 1,305 6.7 x 7.6 x 16.4 170 x 193 x 417 1 1 S * * * MAPG0320A NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 432 196 7 Preinstalled in cabinet * * * * MAPW0320A NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 445 202 * * * * 150 403 MAPP0403A OPEN 20.0 x 15.3 x 12.8 508 x 389 x 325 280 127 4 1,636 8.3 x 7.6 x 16.4 211 x 193 x 417 1 1 S * * * MAPG0403A NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 448 203 7 Preinstalled in cabinet * * * * MAPW0403A NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 461 209 * * * * 9

Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. S = Standard stock offering * = Call for availability 380 – 415V 50Hz Motor (Ref Only) Filter Amps Rating MTE Part Number Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Capacitor/Capacitor Panel Assembly Dimensions (H x W x D) Qty Req’d Ref Fig Available Options kW Inches Millimeters Lbs Kgs Inches Millimeters 002 009 012 013 1.1 - 2.2 6 MAPP0006C OPEN 8.6 x 8.0 x 5.4 218 x 203 x 137 20 9 3 114 7.5 x 3.0 191 x 76 1 2 S * * * MAPG0006C NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 66 30 6 Preinstalled in cabinet * * * * MAPW0006C NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 74 34 * * * * - 8 MAPP0008C OPEN 8.7 x 8.0 x 5.4 221 x 203 x 137 20 9 3 149 7.5 x 3.0 191 x 76 1 2 S * * * MAPG0008C NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 68 31 6 Preinstalled in cabinet * * * * MAPW0008C NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 75 34 * * * * 3.7 11 MAPP0011C OPEN 9.9 x 9.0 x 4.8 251 x 229 x 122 28 13 3 180 7.5 x 3.0 191 x 76 1 2 S * * * MAPG0011C NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 75 34 6 Preinstalled in cabinet * * * * MAPW0011C NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 83 38 * * * * 5.5 14 MAPP0014C OPEN 9.8 x 9.0 x 5.3 249 x 229 x 135 34 15 3 206 8.0 x 3.9 203 x 99 1 2 S * * * MAPG0014C NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 82 37 6 Preinstalled in cabinet * * * * MAPW0014C NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 90 41 * * * * 7.5 21 MAPP0021C OPEN 11.7 x 10.5 x 6.7 297 x 267 x 170 50 23 3 235 8.0 x 3.9 203 x 99 1 2 S * * * MAPG0021C NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 98 44 6 Preinstalled in cabinet * * * * MAPW0021C NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 107 49 * * * * 11 27 MAPP0027C OPEN 11.8 x 10.5 x 7.2 300 x 267 x 183 56 25 3 266 8.3 x 4.6 211 x 117 1 2 S * * * MAPG0027C NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 103 47 6 Preinstalled in cabinet * * * * MAPW0027C NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 111 50 * * * * 15 34 MAPP0034C OPEN 11.7 x 10.5 x 7.7 297 x 267 x 196 68 31 3 298 9.2 x 4.6 234 x 117 1 2 S * * * MAPG0034C NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 115 52 6 Preinstalled in cabinet * * * * MAPW0034C NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 123 56 * * * * 18.5 - 22 44 MAPP0044C OPEN 11.7 x 10.5 x 8.2 297 x 267 x 208 79 36 3 356 9.2 x 4.6 234 x 117 1 2 S * * * MAPG0044C NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 127 58 6 Preinstalled in cabinet * * * * MAPW0044C NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 134 61 * * * * - 52 MAPP0052C OPEN 14.0 x 12.0 x 9.0 356 x 305 x 229 100 45 4 388 9.2 x 4.6 234 x 117 1 2 S * * * MAPG0052C NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 174 79 7 Preinstalled in cabinet * * * * MAPW0052C NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 181 82 * * * * 30 66 MAPP0066C OPEN 14.0 x 12.0 x 9.0 356 x 305 x 229 112 51 4 459 10.6 x 4.6 269 x 117 1 2 S * * * MAPG0066C NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 186 84 7 Preinstalled in cabinet * * * * MAPW0066C NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 194 88 * * * * 37 - 45 83 MAPP0083C OPEN 14.0 x 12.0 x 10.9 356 x 305 x 277 139 63 4 565 10.6 x 4.6 269 x 117 1 2 S * * * MAPG0083C NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 212 96 7 Preinstalled in cabinet * * * * MAPW0083C NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 219 99 * * * * 55 103 MAPP0103C OPEN 14.1 x 12.0 x 11.0 358 x 305 x 279 147 67 4 660 10.6 x 4.6 269 x 117 1 2 S * * * MAPG0103C NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 221 100 7 Preinstalled in cabinet * * * * MAPW0103C NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 228 103 * * * * MATRIX® AP SELECTION TABLES 10

Matrix® AP Filters Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. S = Standard stock offering * = Call for availability 380 – 415V 50Hz Motor (Ref Only) Filter Amps Rating MTE Part Number Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Capacitor/Capacitor Panel Assembly Dimensions (H x W x D) Qty Req’d Ref Fig Available Options kW Inches Millimeters Lbs Kgs Inches Millimeters 002 009 012 013 - 128 MAPP0128C OPEN 20.0 x 15.3 x 10.7 508 x 389 x 272 218 99 4 973 11.1 x 16.4 x 7.6 282 x 417 x 193 1 1 S * * * MAPG0128C NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 390 177 7 Preinstalled in cabinet * * * * MAPW0128C NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 396 180 * * * * 75 - 90 165 MAPP0165C OPEN 20.0 x 15.3 x 11.7 508 x 389 x 297 273 124 4 1,030 6.7 x 16.4 x 7.6 170 x 417 x 193 1 1 S * * * MAPG0165C NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 442 200 7 Preinstalled in cabinet * * * * MAPW0165C NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 455 206 * * * * 110 208 MAPP0208C OPEN 20.1 x 15.3 x 11.8 511 x 389 x 300 290 132 4 1,263 8.0 x 16.4 x 7.6 203 x 417 x 193 1 1 S * * * MAPG0208C NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 459 208 7 Preinstalled in cabinet * * * * MAPW0208C NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 472 214 * * * * - 240 MAPP0240C OPEN 19.9 x 15.3 x 12.8 505 x 389 x 325 325 147 4 1,423 8.0 x 16.4 x 7.6 203 x 417 x 193 1 1 S * * * MAPG0240C NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 494 224 7 Preinstalled in cabinet * * * * MAPW0240C NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 507 230 * * * * 150 320 MAPP0320C OPEN 20.0 x 15.3 x 17.8 508 x 389 x 452 421 191 4 1,450 9.9 x 16.4 x 7.6 251 x 417 x 193 1 1 S * * * MAPG0320C NEMA 1/2 76.0 x 27.7 x 24.9 1930 x 704 x 632 658 298 7 Preinstalled in cabinet * * * * MAPW0320C NEMA 3R 76.0 x 27.7 x 34.0 1930 x 704 x 864 683 310 * * * * 185 - 220 403 MAPP0403C OPEN 23.2 x 15.3 x 13.7 589 x 389 x 348 433 196 4 1,816 11.1 x 16.4 x 7.6 282 x 417 x 193 1 1 S * * * MAPG0403C NEMA 1/2 76.0 x 27.7 x 24.9 1930 x 704 x 632 635 288 7 Preinstalled in cabinet * * * * MAPW0403C NEMA 3R 76.0 x 27.7 x 34.0 1930 x 704 x 864 667 303 * * * * - 482 MAPP0482C OPEN 23.3 x 15.3 x 14.8 592 x 389 x 376 543 246 4 2,008 8.0 x 16.4 x 7.6 203 x 417 x 193 2 1 S * * * MAPG0482C NEMA 1/2 87.6 x 43.7 x 31.1 2225 x 1110 x 790 955 433 7 Preinstalled in cabinet * * * * MAPW0482C NEMA 3R 87.6 x 43.7 x 40.1 2225 x 1110 x 1019 1,000 454 * * * * 280 636 MAPP0636C OPEN 25.8 x 24.0 x 16.5 655 x 610 x 419 683 310 5 2,359 9.9 x 16.4 x 7.6 251 x 417 x 193 2 1 S * * * MAPG0636C NEMA 1/2 87.6 x 43.7 x 31.1 2225 x 1110 x 790 1,094 496 7 Preinstalled in cabinet * * * * MAPW0636C NEMA 3R 87.6 x 43.7 x 40.1 2225 x 1110 x 1019 1,131 513 * * * * 375 786 MAPP0786C OPEN 25.7 x 24.0 x 17.9 653 x 610 x 455 777 352 5 2,604 11.1 x 16.4 x 7.6 282 x 417 x 193 2 1 S * * * MAPG0786C NEMA 1/2 87.6 x 43.7 x 31.1 2225 x 1110 x 790 1,183 537 7 Preinstalled in cabinet * * * * MAPW0786C NEMA 3R 87.6 x 43.7 x 40.1 2225 x 1110 x 1019 1,228 557 * * * * 450 850 MAPP0850C OPEN 25.9 x 24.0 x 20.3 658 x 610 x 516 981 445 5 2,974 9.9 x 16.4 x 7.6 251 x 417 x 193 2 1 S * * * 8.0 x 16.4 x 7.6 203 x 417 x 193 1 MAPG0850C NEMA 1/2 84.0 x 52.0 x 36.5 2134 x 1321 x 927 1,604 728 7 Preinstalled in cabinet * * * * MAPW0850C NEMA 3R 84.0 x 52.0 x 45.5 2134 x 1321 x 1156 1,644 746 * * * * 525 1000 MAPP1000C OPEN 25.9 x 24.0 x 21.2 658 x 610 x 538 973 441 5 3,954 9.9 x 16.4 x 7.6 251 x 417 x 193 3 1 S * * * MAPG1000C NEMA 1/2 84.0 x 52.0 x 36.5 2134 x 1321 x 927 1,579 716 7 Preinstalled in cabinet * * * * MAPW1000C NEMA 3R 84.0 x 52.0 x 45.5 2134 x 1321 x 1156 1,620 735 * * * * 600 1200 MAPP1200C OPEN 26.0 x 24.0 x 22.2 660 x 610 x 564 989 449 5 4,136 11.1 x 16.4 x 7.6 282 x 417 x 193 3 1 S * * * MAPG1200C NEMA 1/2 84.0 x 52.0 x 36.5 2134 x 1321 x 927 1,575 714 7 Preinstalled in cabinet * * * * MAPW1200C NEMA 3R 84.0 x 52.0 x 45.5 2134 x 1321 x 1156 1,616 733 * * * * mtecorp.com 11

Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. S = Standard stock offering * = Call for availability 480V 60Hz Motor (Ref Only) Filter Amps Rating MTE Part Number Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Capacitor/Capacitor Panel Assembly Dimensions (H x W x D) Qty Req’d Ref Fig Available Options HP Inches Millimeters Lbs Kgs Inches Millimeters 002 009 012 013 3 6 MAPP0006D OPEN 8.7 x 8.0 x 5.4 221 x 203 x 137 20 9 3 122 7.5 x 3.0 191 x 76 1 2 S * * * MAPG0006D NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 66 30 6 Preinstalled in cabinet S S S S MAPW0006D NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 74 34 S S S S 5 8 MAPP0008D OPEN 8.7 x 8.0 x 5.4 221 x 203 x 137 20 9 3 158 7.5 x 3.0 191 x 76 1 2 S * * * MAPG0008D NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 68 31 6 Preinstalled in cabinet S S S S MAPW0008D NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 75 34 S S S S 7.5 11 MAPP0011D OPEN 9.9 x 9.0 x 4.8 251 x 229 x 122 28 13 3 192 7.5 x 3.0 191 x 76 1 2 S * * * MAPG0011D NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 75 34 6 Preinstalled in cabinet S S S S MAPW0011D NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 83 38 S S S S 10 14 MAPP0014D OPEN 9.8 x 9.0 x 5.3 249 x 229 x 135 33 15 3 220 7.5 x 3.0 191 x 76 1 2 S * * * MAPG0014D NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 80 36 6 Preinstalled in cabinet S S S S MAPW0014D NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 88 40 S S S S 15 21 MAPP0021D OPEN 11.7 x 10.5 x 6.6 297 x 267 x 168 50 23 3 251 8.0 x 3.9 203 x 99 1 2 S * * * MAPG0021D NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 98 44 6 Preinstalled in cabinet S S S S MAPW0021D NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 107 49 S S S S 20 27 MAPP0027D OPEN 11.8 x 10.5 x 7.2 300 x 267 x 183 56 25 3 283 8.0 x 3.9 203 x 99 1 2 S * * * MAPG0027D NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 104 47 6 Preinstalled in cabinet S S S S MAPW0027D NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 112 51 S S S S 25 34 MAPP0034D OPEN 11.7 x 10.5 x 7.7 297 x 267 x 196 67 30 3 318 8.0 x 3.9 203 x 99 1 2 S * * * MAPG0034D NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 113 51 6 Preinstalled in cabinet S S S S MAPW0034D NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 122 55 S S S S 30 44 MAPP0044D OPEN 11.7 x 10.5 x 8.2 297 x 267 x 208 78 35 3 379 8.3 x 4.6 211 x 117 1 2 S * * * MAPG0044D NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 128 58 6 Preinstalled in cabinet S S S S MAPW0044D NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 133 60 S S S S 40 52 MAPP0052D OPEN 14.0 x 12.0 x 9.1 356 x 305 x 231 99 45 4 413 9.2 x 4.6 234 x 117 1 2 S * * * MAPG0052D NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 173 78 7 Preinstalled in cabinet S S S S MAPW0052D NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 181 82 S S S S 50 66 MAPP0066D OPEN 14.0 x 12.0 x 9.0 356 x 305 x 229 111 50 4 488 9.2 x 4.6 234 x 117 1 2 S * * * MAPG0066D NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 185 84 7 Preinstalled in cabinet S S S S MAPW0066D NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 193 88 S S S S 60 83 MAPP0083D OPEN 14.0 x 12.0 x 10.9 356 x 305 x 277 139 63 4 600 10.6 x 4.6 269 x 117 1 2 S * * * MAPG0083D NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 209 95 7 Preinstalled in cabinet S S S S MAPW0083D NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 217 98 S S S S 75 103 MAPP0103D OPEN 14.1 x 12.0 x 11.0 358 x 305 x 279 147 67 4 702 10.6 x 4.6 269 x 117 1 2 S * * * MAPG0103D NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 221 100 7 Preinstalled in cabinet S S S S MAPW0103D NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 228 103 S S S S 100 128 MAPP0128D OPEN 20.0 x 15.3 x 10.7 508 x 389 x 272 195 88 4 1,035 6.9 x 16.3 x 7.6 175 x 414 x 193 1 1 S * * * MAPG0128D NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 360 163 7 Preinstalled in cabinet S S S S MAPW0128D NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 373 169 S S S S MATRIX® AP SELECTION TABLES 12

Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. S = Standard stock offering * = Call for availability 480V 60Hz Motor (Ref Only) Filter Amps Rating MTE Part Number Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Capacitor/Capacitor Panel Assembly Dimensions (H x W x D) Qty Req’d Ref Fig Available Options HP Inches Millimeters Lbs Kgs Inches Millimeters 002 009 012 013 125 165 MAPP0165D OPEN 20.0 x 15.3 x 11.7 508 x 389 x 297 233 106 4 1,096 6.7 x 16.4 x 7.6 170 x 417 x 193 1 1 S * * * MAPG0165D NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 435 197 7 Preinstalled in cabinet S S S S MAPW0165D NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 448 203 S S S S 150 208 MAPP0208D OPEN 20.1 x 15.3 x 11.8 511 x 389 x 300 287 130 4 1,343 6.7 x 16.4 x 7.6 170 x 417 x 193 1 1 S * * * MAPG0208D NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 452 205 7 Preinstalled in cabinet S S S S MAPW0208D NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 464 210 S S S S 200 240 MAPP0240D OPEN 20.0 x 15.3 x 12.7 508 x 389 x 323 323 147 4 1,514 6.7 x 16.4 x 7.6 170 x 417 x 193 1 1 S * * * MAPG0240D NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 488 221 7 Preinstalled in cabinet S S S S MAPW0240D NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 501 227 S S S S 250 320 MAPP0320D OPEN 20.0 x 15.3 x 14.8 508 x 389 x 376 416 189 4 1,543 8.0 x 16.4 x 7.6 203 x 417 x 193 1 1 S * * * MAPG0320D NEMA 1/2 76.0 x 27.7 x 24.9 1930 x 704 x 632 654 297 7 Preinstalled in cabinet S S S * MAPW0320D NEMA 3R 76.0 x 27.7 x 34.0 1930 x 704 x 864 679 308 S S S * 300 403 MAPP0403D OPEN 23.3 x 15.3 x 13.7 592 x 389 x 348 419 190 4 1,932 9.9 x 16.4 x 7.6 251 x 417 x 193 1 1 S * * * MAPG0403D NEMA 1/2 76.0 x 27.7 x 24.9 1930 x 704 x 632 649 294 7 Preinstalled in cabinet S S S * MAPW0403D NEMA 3R 76.0 x 27.7 x 34.0 1930 x 704 x 864 674 306 S S S * 400 482 MAPP0482D OPEN 23.3 x 15.3 x 14.8 592 x 389 x 376 532 241 4 2,137 6.7 x 16.4 x 7.6 170 x 417 x 193 2 1 S * * * MAPG0482D NEMA 1/2 87.6 x 43.7 x 31.1 2225 x 1110 x 790 944 428 7 Preinstalled in cabinet S S S * MAPW0482D NEMA 3R 87.6 x 43.7 x 40.1 2225 x 1110 x 1019 981 445 S S S * 500 636 MAPP0636D OPEN 25.8 x 24.0 x 16.5 655 x 610 x 419 667 303 5 2,509 8.0 x 16.4 x 7.6 203 x 417 x 193 2 1 S * * * MAPG0636D NEMA 1/2 87.6 x 43.7 x 31.1 2225 x 1110 x 790 1,085 492 7 Preinstalled in cabinet S S S * MAPW0636D NEMA 3R 87.6 x 43.7 x 40.1 2225 x 1110 x 1019 1,122 509 S S S * 600 786 MAPP0786D OPEN 25.7 x 24.0 x 17.9 653 x 610 x 455 773 351 5 2,771 9.9 x 16.4 x 7.6 251 x 417 x 193 2 1 S * * * MAPG0786D NEMA 1/2 87.6 x 43.7 x 31.1 2225 x 1110 x 790 1,180 535 7 Preinstalled in cabinet S S S * MAPW0786D NEMA 3R 87.6 x 43.7 x 40.1 2225 x 1110 x 1019 1,225 556 S S S * 700 850 MAPP0850D OPEN 25.9 x 24.0 x 20.3 658 x 610 x 516 967 439 5 3,163 8.0 x 16.4 x 7.6 203 x 417 x 193 2 1 S * * * 6.7 x 16.4 x 7.6 170 x 417 x 193 1 MAPG0850D NEMA 1/2 84.0 x 52.0 x 36.5 2134 x 1321 x 927 1,590 721 7 Preinstalled in cabinet S S S * MAPW0850D NEMA 3R 84.0 x 52.0 x 45.5 2134 x 1321 x 1156 1,630 739 S S S * 900 1000 MAPP1000D OPEN 25.9 x 24.0 x 21.2 658 x 610 x 538 946 429 5 4,206 8.0 x 16.4 x 7.6 203 x 417 x 193 2 1 S * * * 9.9 x 16.4 x 7.6 251 x 417 x 193 1 MAPG1000D NEMA 1/2 84.0 x 52.0 x 36.5 2134 x 1321 x 927 1,566 710 7 Preinstalled in cabinet S S S * MAPW1000D NEMA 3R 84.0 x 52.0 x 45.5 2134 x 1321 x 1156 1,607 729 S S S * 1000 1200 MAPP1200D OPEN 26.0 x 24.0 x 22.2 660 x 610 x 564 983 446 5 4,400 9.9 x 16.4 x 7.6 251 x 417 x 193 3 1 S * * * MAPG1200D NEMA 1/2 84.0 x 52.0 x 36.5 2134 x 1321 x 927 1,571 713 7 Preinstalled in cabinet S S S * MAPW1200D NEMA 3R 84.0 x 52.0 x 45.5 2134 x 1321 x 1156 1,612 731 S S S * 1300 1600 MAPP1600D OPEN 33.4 x 36.0 x 29.3 848 x 914 x 744 2,272 1031 5 4,500 9.9 x 16.4 x 7.6 251 x 417 x 193 4 1 * * * * 1500 2000 MAPP2000D OPEN 33.6 x 36.0 x 31.3 853 x 914 x 795 2,678 1215 5 5,050 9.9 x 16.4 x 7.6 251 x 417 x 193 5 1 * * * * 1850 2300 MAPP2300D OPEN 33.4 x 36.0 x 32.4 848 x 914 x 823 2,885 1309 5 6,100 9.9 x 16.4 x 7.6 251 x 417 x 193 6 1 * * * * mtecorp.com Matrix® AP Filters 13

Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. S = Standard stock offering * = Call for availability 600V 60Hz Motor (Ref Only) Filter Amps Rating MTE Part Number Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Capacitor/Capacitor Panel Assembly Dimensions (H x W x D) Qty Req’d Ref Fig Available Options HP Inches Millimeters Lbs Kgs Inches Millimeters 002 009 012 013 5 6 MAPP0006E OPEN 8.7 x 8.0 x 5.4 221 x 203 x 137 18 8 3 150 7.5 x 3.0 191 x 76 1 2 S * * * MAPG0006E NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 67 30 6 Preinstalled in cabinet S * S * MAPW0006E NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 75 34 S * S * 5 8 MAPP0008E OPEN 9.8 x 9.0 x 4.8 249 x 229 x 122 28 13 3 183 7.5 x 3.0 191 x 76 1 2 S * * * MAPG0008E NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 75 34 6 Preinstalled in cabinet S * S * MAPW0008E NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 83 38 S * S * 10 11 MAPP0011E OPEN 9.8 x 9.0 x 5.3 249 x 229 x 135 32 15 3 205 7.5 x 3.0 191 x 76 1 2 S * * * MAPG0011E NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 79 36 6 Preinstalled in cabinet S * S * MAPW0011E NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 87 39 S * S * 10 14 MAPP0014E OPEN 11.7 x 10.5 x 6.7 297 x 267 x 170 47 21 3 250 9.2 x 4.6 234 x 117 1 2 S * * * MAPG0014E NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 94 43 6 Preinstalled in cabinet S * S * MAPW0014E NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 102 46 S * S * 15 21 MAPP0021E OPEN 11.7 x 10.5 x 7.2 297 x 267 x 183 58 26 3 285 7.5 x 3.9 191 x 99 1 2 S * * * MAPG0021E NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 106 48 6 Preinstalled in cabinet S * S * MAPW0021E NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 113 51 S * S * 25 27 MAPP0027E OPEN 11.7 x 10.5 x 7.7 297 x 267 x 196 68 31 3 304 8.3 x 4.6 211 x 117 1 2 S * * * MAPG0027E NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 115 52 6 Preinstalled in cabinet S * S * MAPW0027E NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 123 56 S * S * 30 34 MAPP0034E OPEN 11.7 x 10.5 x 8.2 297 x 267 x 208 89 40 3 366 8.3 x 4.6 211 x 117 1 2 S * * * MAPG0034E NEMA 1/2 24.0 x 12.5 x 17.9 610 x 318 x 455 124 56 6 Preinstalled in cabinet S * S * MAPW0034E NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 131 59 S * S * 40 44 MAPP0044E OPEN 14.0 x 12.0 x 9.9 356 x 305 x 251 118 54 4 395 9.2 x 4.6 234 x 117 1 2 S * * * MAPG0044E NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 192 87 7 Preinstalled in cabinet S * S * MAPW0044E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 199 90 S * S * 50 52 MAPP0052E OPEN 14.1 x 12.0 x 10.3 358 x 305 x 262 142 64 4 494 9.2 x 4.6 234 x 117 1 2 S * * * MAPG0052E NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 197 89 7 Preinstalled in cabinet S * S * MAPW0052E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 204 93 S * S * 60 66 MAPP0066E OPEN 14.0 x 12.0 x 11.0 356 x 305 x 279 166 75 4 655 10.6 x 4.6 269 x 117 1 2 S * * * MAPG0066E NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 209 95 7 Preinstalled in cabinet S * S * MAPW0066E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 217 98 S * S * 75 83 MAPP0083E OPEN 14.1 x 12.0 x 10.9 358 x 305 x 277 144 65 4 718 10.6 x 4.6 269 x 117 1 2 S * * * MAPG0083E NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 218 99 7 Preinstalled in cabinet S * S * MAPW0083E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 226 103 S * S * MATRIX® AP SELECTION TABLES 14

Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. S = Standard stock offering * = Call for availability 600V 60Hz Motor (Ref Only) Filter Amps Rating MTE Part Number Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Capacitor/Capacitor Panel Assembly Dimensions (H x W x D) Qty Req’d Ref Fig Available Options HP Inches Millimeters Lbs Kgs Inches Millimeters 002 009 012 013 100 103 MAPP0103E OPEN 20.0 x 15.3 x 10.7 508 x 389 x 272 210 95 4 1,085 6.7 x 16.4 x 7.6 170 x 417 x 193 1 1 S * * * MAPG0103E NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 376 171 7 Preinstalled in cabinet S * S * MAPW0103E NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 389 176 S * S * 125 128 MAPP0128E OPEN 20.0 x 15.3 x 11.7 508 x 389 x 297 270 122 4 1,090 6.7 x 16.4 x 7.6 170 x 417 x 193 1 1 S * * * MAPG0128E NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 436 198 7 Preinstalled in cabinet S * S * MAPW0128E NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 449 204 S * S * 150 165 MAPP0165E OPEN 20.1 x 15.3 x 11.9 511 x 389 x 302 287 130 4 1,285 6.7 x 16.4 x 7.6 170 x 417 x 193 1 1 S * * * MAPG0165E NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 456 207 7 Preinstalled in cabinet S * S * MAPW0165E NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 469 213 S * S * 200 208 MAPP0208E OPEN 20.1 x 15.3 x 12.8 511 x 389 x 325 322 146 4 1,431 7.7 x 16.4 x 7.6 196 x 417 x 193 1 1 S * * * MAPG0208E NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 482 219 7 Preinstalled in cabinet S * S * MAPW0208E NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 516 234 S * S * 250 240 MAPP0240E OPEN 19.9 x 15.3 x 15.8 505 x 389 x 401 427 194 4 1,624 7.7 x 16.4 x 7.6 196 x 417 x 193 1 1 S * * * MAPG0240E NEMA 1/2 76.0 x 27.7 x 24.9 1930 x 704 x 632 661 300 7 Preinstalled in cabinet S * S * MAPW0240E NEMA 3R 76.0 x 27.7 x 34.0 1930 x 704 x 864 687 312 S * S * 300 320 MAPP0320E OPEN 23.2 x 15.3 x 15.7 589 x 389 x 399 501 227 4 2,021 9.2 x 16.4 x 7.6 234 x 417 x 193 1 1 S * * * MAPG0320E NEMA 1/2 76.0 x 27.7 x 24.9 1930 x 704 x 632 740 336 7 Preinstalled in cabinet S * S * MAPW0320E NEMA 3R 76.0 x 27.7 x 34.0 1930 x 704 x 864 765 347 S * S * 400 403 MAPP0403E OPEN 23.3 x 15.3 x 15.8 592 x 389 x 401 504 229 4 2,208 12.1 x 16.4 x 7.6 307 x 417 x 193 1 1 S * * * MAPG0403E NEMA 1/2 87.6 x 43.7 x 31.1 2225 x 1110 x 790 909 412 7 Preinstalled in cabinet S * S * MAPW0403E NEMA 3R 87.6 x 43.7 x 40.1 2225 x 1110 x 1019 945 429 S * S * 500 482 MAPP0482E OPEN 25.9 x 24.0 x 16.6 658 x 610 x 422 670 304 5 2,481 7.7 x 16.4 x 7.6 196 x 417 x 193 2 1 S * * * MAPG0482E NEMA 1/2 87.6 x 43.7 x 31.1 2225 x 1110 x 790 1,091 495 7 Preinstalled in cabinet S * S * MAPW0482E NEMA 3R 87.6 x 43.7 x 40.1 2225 x 1110 x 1019 1,136 515 S * S * 600 636 MAPP0636E OPEN 25.9 x 24.0 x 17.7 658 x 610 x 450 754 342 5 2,884 9.2 x 16.4 x 7.6 234 x 417 x 193 2 1 S * * * MAPG0636E NEMA 1/2 87.6 x 43.7 x 31.1 2225 x 1110 x 790 1,227 557 7 Preinstalled in cabinet S * S * MAPW0636E NEMA 3R 87.6 x 43.7 x 40.1 2225 x 1110 x 1019 1,264 573 S * S * 800 786 MAPP0786E OPEN 26.0 x 24.0 x 19.5 660 x 610 x 495 927 420 5 3,368 12.1 x 16.4 x 7.6 307 x 417 x 193 2 1 S * * * MAPG0786E NEMA 1/2 84.0 x 52.0 x 36.5 2134 x 1321 x 927 1,509 684 7 Preinstalled in cabinet S * S * MAPW0786E NEMA 3R 84.0 x 52.0 x 45.5 2134 x 1321 x 1156 1,549 703 S * S * mtecorp.com Matrix® AP Filters 15

Notes: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. S = Standard stock offering * = Call for availability 690V 50Hz Motor (Ref Only) Filter Amps Rating MTE Part Number Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Capacitor/Capacitor Panel Assembly Dimensions (H x W x D) Qty Req’d Ref Fig Available Options kW Inches Millimeters Lbs Kgs Inches Millimeters 002 009 012 013 37 52 MAPP0052F OPEN 19.8 x 15.3 x 11.1 503 x 389 x 282 167 76 3 681 6.7 x 16.4 x 7.6 170 x 417 x 193 1 1 * * * * 45 66 MAPP0066F OPEN 19.9 x 15.3 x 11.2 505 x 389 x 284 193 88 3 844 7.7 x 16.4 x 7.6 196 x 417 x 193 1 1 * * * * 55 83 MAPP0083F OPEN 19.9 x 15.3 x 11.6 505 x 389 x 295 254 115 3 850 6.7 x 16.4 x 7.6 170 x 417 x 193 1 1 * * * * 75 103 MAPP0103F OPEN 20.1 x 15.3 x 11.7 511 x 389 x 297 242 110 3 1,051 9.2 x 16.4 x 7.6 234 x 417 x 193 1 1 * * * * 90 128 MAPP0128F OPEN 19.9 x 15.3 x 12.7 505 x 389 x 323 323 147 3 1,106 8.0 x 16.4 x 7.6 203 x 417 x 193 1 1 * * * * 110 165 MAPP0165F OPEN 19.9 x 15.3 x 14.8 505 x 389 x 376 378 171 3 1,257 10.7 x 16.3 x 7.6 272 x 414 x 193 1 1 * * * * 150 208 MAPP0208F OPEN 23.1 x 15.3 x 13.7 587 x 389 x 348 448 203 3 1,400 6.7 x 16.4 x 7.6 170 x 417 x 193 1 1 * * * * 7.7 x 16.4 x 7.6 196 x 417 x 193 1 * * * * 185 240 MAPP0240F OPEN 23.2 x 15.3 x 14.9 589 x 389 x 378 503 228 3 1,721 7.7 x 16.4 x 7.6 196 x 417 x 193 1 1 * * * * 8.0 x 16.4 x 7.6 203 x 417 x 193 1 * * * * 222 320 MAPP0320F OPEN 25.9 x 24.0 x 16.7 658 x 610 x 424 912 414 4 2,031 9.9 x 16.4 x 7.6 251 x 417 x 193 2 1 * * * * 280 403 MAPP0403F OPEN 25.8 x 24.0 x 17.8 655 x 610 x 452 982 445 4 2,780 6.7 x 16.4 x 7.6 170 x 417 x 193 1 1 * * * * 9.9 x 16.4 x 7.6 251 x 417 x 193 2 * * * * 375 482 MAPP0482F OPEN 25.9 x 24.0 x 19.0 658 x 610 x 483 1,167 529 4 2,883 9.9 x 16.4 x 7.6 251 x 417 x 193 3 1 * * * * 450 636 MAPP0636F OPEN 25.9 x 24.0 x 21.6 658 x 610 x 549 1,084 492 4 3,140 11.1 x 16.4 x 7.6 282 x 417 x 193 3 1 * * * * MATRIX® AP SELECTION TABLES 16

CAPACITOR/CAPACITOR PANEL OPEN MAGNETICS FIGURE 1 FIGURE 2 ENCLOSURES (NOTE: HOODS ONLY ON NEMA 3R ENCLOSURES) FIGURE 5 FIGURE 6 FIGURE 7 H H H H H W W W H W W D D D D D D FIGURE 3 FIGURE 4 W H Note: Figure illustrations are for reference only. Actual hardware may differ. Please visit mtecorp.com for detailed information. mtecorp.com Matrix® AP Filters 17

mtecorp.com Harmonic Filters Matrix® AP Adaptive Passive Technology for superior harmonic mitigation at varying loads Matrix® E-Series Power quality you’ve come to expect from the power quality experts Single Phase Matrix® ONE Optimized harmonic filters with proven harmonic mitigation VFD Harmonic FIlter Utility Power 18

Matrix® E-Series Performance you can count on - at an affordable cost. The patented Matrix® E-series is the latest in a long line of highly effective harmonic filters from MTE. The E-series delivers the performance you’ve come to expect out of a Matrix filter without being over engineered. It is an affordable solution to managing unwanted harmonic distortions - such as nuisance tripping of circuit breakers, inaccurate measurements on sensors, overheating of components, and system downtime - generated by Variable Frequency Drives (VFDs). The Matrix E-Series features a flexible design that is compact and robust, making it easy to integrate and install in nearly any application. Power quality, energy efficiency, and reduced downtime are easy to achieve with the new Matrix E-Series from MTE. Meets essential harmonic distortion requirements Flexible, compact design Easy to integrate and install Extends the service life of electrical equipment 19

The Matrix® E-Series harmonic filter meets the international harmonic distortion requirement of 10%- 15% while also supporting the compliance of IEEE-519. Patented design with reliable components provides harmonic mitigation and reduced THID (Total Harmonic Distortion) where you need it most. Affordable solution that is easy to install and maintain. Improves system efficiency and reliability to lower total cost. Helps extend service life of electrical equipment and transformers. Alleviates system downtime by preventing blown fuses and tripped circuit breakers. Power quality you’ve come to expect from the power quality experts. Performance Specifications Service Load Condition Load: 6-pulse rectifier only Input Voltage 380V - 415V +/- 10%; 50 + 0.75Hz; 3-phase 480V +/- 10%; 60 + 0.75Hz; 3-phase Current Range 6A - 320A (1.1 KW - 150 KW; 3HP - 250HP) Maximum THID With DC Link Choke or Reactor 8% @ full load; 12% @ 40% load Without DC Link Choke or Reactor 12% @ full load; 17% @ 40% load System Power Conditions at Rated Power THVD: <3% Line Voltage Unbalance: <1% Source Impedance Maximum: 6% Minimum: 1.5% Maximum Output Voltage at No Load (RMS Peak) +5% Minimum Output Voltage at Full Load (RMS Peak) -5% Service Factor 1.00 Maximum Ambient Temperature -40C to +50C open panel filters -40C to +90C storage Insertion Loss @ Full Load <5% Efficiency >98% Altitude Without Derating 3,300 feet above sea level Relative Humidity 0% to 95% non-condensing Current Rating 150% for 1 minute duration Product specifications subject to change at anytime. Matrix® E-Series Matrix® E-Series Filters Utility Power VFD Matrix® E-Series Harmonic Spectrum Chart 20

mtecorp.com Matrix® E-Series • Determine voltage and frequency required • Reference motor nameplate to determine motor HP or kW and Full Load Amps • Select filter based on Motor Full Load Amps Do not exceed filter’s maximum current rating (amps) • Determine derating requirements Reference Performance Specifications table on previous page How to properly size your filter Understanding the Matrix® E-Series Part Number: Voltage Frequency Code C 380 – 415 Volts 50 Hz D 480 Volts 60 Hz Enclosure Type P = Panel Mount (No Enclosure) Current Rating 0006 is 6 Amps 0083 is 83 Amps 0320 is 320 Amps Matrix® E-Series MAE P _ _ _ _ X Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. 380V - 415V 50Hz Motor (Ref Only) Filter Amps Rating MTE Part Number Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Capacitor/Capacitor Panel Assembly Dimensions (H x W x D) Qty Req’d Ref Fig kW Inches Millimeters Lbs Kgs Inches Millimeters 1.1 - 2.2 6 MAEP0006C OPEN 8.2 x 6.9 x 3.5 208 x 175 x 8 13 6 2 65 7.5 x 3.0 191 x 76 1 1 - 8 MAEP0008C OPEN 9.8 x 6.9 x 3.5 249 x 175 x 89 18 8 2 74 7.5 x 3.9 191 x 99 1 1 3.7 11 MAEP0011C OPEN 9.8 x 6.9 x 4.1 249 x 175 x 104 27 12 2 94 7.5 x 3.9 191 x 99 1 1 5.5 14 MAEP0014C OPEN 9.8 x 6.9 x 4.1 249 x 175 x 104 27 12 2 106 7.5 x 3.9 191 x 99 1 1 7.5 21 MAEP0021C OPEN 12.0 x 7.1 x 5.4 305 x 180 x 137 30 14 2 192 7.5 x 4.6 191 x 117 1 1 11 27 MAEP0027C OPEN 12.0 x 7.1 x 5.6 305 x 180 x 142 36 16 2 212 9.1 x 4.6 231 x 117 1 1 15 34 MAEP0034C OPEN 12.0 x 7.1 x 6.1 305 x 180 x 155 41 19 2 205 9.1 x 4.6 231 x 117 1 1 18.5 - 22 44 MAEP0044C OPEN 12.0 x 7.1 x 6.1 305 x 180 x 155 43 20 2 270 10.6 x 4.6 269 x 117 1 1 - 52 MAEP0052C OPEN 14.5 x 9.6 x 6.9 368 x 244 x 175 55 25 3 278 9.1 x 4.6 231 x 117 1 1 7.5 x 3.9 191 x 99 1 1 30 66 MAEP0066C OPEN 14.6 x 9.6 x 6.7 371 x 244 x 170 60 27 3 359 10.6 x 4.6 269 x 117 1 1 9.1 x 4.6 231 x 117 1 1 37 - 45 83 MAEP0083C OPEN 14.5 x 9.6 x 7.5 368 x 244 x 191 74 34 3 378 10.6 x 4.6 269 x 117 2 1 55 103 MAEP0103C OPEN 14.6 x 9.6 x 8.3 371 x 244 x 211 86 39 3 397 10.6 x 4.6 269 x 117 2 1 - 128 MAEP0128C OPEN 14.9 x 9.6 x 8.8 378 x 244 x 224 97 44 3 480 10.6 x 4.6 269 x 117 2 1 75 - 90 165 MAEP0165C OPEN 16.9 x 11.0 x 9.0 429 x 279 x 299 119 54 4 668 10.6 x 4.6 269 x 117 3 1 110 208 MAEP0208C OPEN 17.1 x 11.0 x 9.3 434 x 279 x 236 136 62 4 732 10.6 x 4.6 269 x 117 3 1 - 240 MAEP0240C OPEN 16.8 x 11.0 x 10.5 427 x 279 x 267 166 75 4 768 7.5 x 3.0 191 x 76 3 1 10.6 x 4.6 269 x 117 1 1 150 320 MAEP0320C OPEN 17.1 x 11.0 x 10.4 434 x 279 x 264 181 82 4 929 10.6 x 4.6 269 x 117 4 1 21

480V 60Hz Motor (Ref Only) Filter Amps Rating MTE Part Number Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Capacitor/Capacitor Panel Assembly Dimensions (H x W x D) Qty Req’d Ref Fig HP Inches Millimeters Lbs Kgs Inches Millimeters 3 6 MAEP0006D OPEN 8.2 x 6.9 x 3.5 208 x 175 x 89 13 6 2 70 7.5 x 3.0 191 x 76 1 1 5 8 MAEP0008D OPEN 9.8 x 6.9 x 3.5 249 x 175 x 89 17 8 2 79 7.5 x 3.0 191 x 76 1 1 7.5 11 MAEP0011D OPEN 9.8 x 6.9 x 3.8 249 x 175 x 97 24 11 2 101 7.5 x 3.9 191 x 99 1 1 10 14 MAEP0014D OPEN 9.8 x 6.9 x 4.1 249 x 175 x 104 27 12 2 114 7.5 x 3.9 191 x 99 1 1 15 21 MAEP0021D OPEN 12.0 x 7.1 x 5.4 305 x 180 x 137 29 13 2 206 7.5 x 3.9 191 x 99 1 1 20 27 MAEP0027D OPEN 12.0 x 7.1 x 5.6 305 x 180 x 142 33 15 2 227 7.5 x 3.9 191 x 99 1 1 25 34 MAEP0034D OPEN 12.0 x 7.1 x 6.1 305 x 180 x 155 40 18 2 220 7.5 x 3.9 191 x 99 1 1 7.5 x 3.0 191 x 76 1 1 30 44 MAEP0044D OPEN 12.0 x 7.1 x 6.1 305 x 180 x 155 43 20 2 289 7.5 x 3.0 191 x 76 1 1 9.1 x 4.6 231 x 117 1 1 40 52 MAEP0052D OPEN 14.5 x 9.6 x 6.9 368 x 244 x 175 53 24 3 298 9.1 x 4.6 231 x 117 1 1 50 66 MAEP0066D OPEN 14.6 x 9.6 x 6.7 371 x 244 x 170 56 25 3 384 7.5 x 3.0 191 x 76 1 1 10.6 x 4.6 269 x 117 1 1 60 83 MAEP0083D OPEN 14.5 x 9.6 x 7.5 368 x 244 x 191 73 33 3 405 9.1 x 4.6 231 x 117 2 1 75 103 MAEP0103D OPEN 14.6 x 9.6 x 8.3 371 x 244 x 211 82 37 3 425 10.6 x 4.6 269 x 117 1 1 7.5 x 3.9 191 x 99 1 1 100 128 MAEP0128D OPEN 14.9 x 9.6 x 8.8 378 x 244 x 224 97 44 3 514 10.6 x 4.6 269 x 117 2 1 125 165 MAEP0165D OPEN 16.9 x 11.0 x 9.0 429 x 279 x 229 115 52 4 715 7.5 x 3.0 191 x 76 2 1 10.6 x 4.6 269 x 117 1 1 150 208 MAEP0208D OPEN 17.1 x 11.0 x 9.3 434 x 279 x 236 136 62 4 783 7.5 x 3.9 191 x 99 2 1 10.6 x 4.6 269 x 117 2 1 200 240 MAEP0240D OPEN 16.8 x 11.0 x 10.5 427 x 279 x 267 160 73 4 822 7.5 x 3.0 191 x 76 2 1 9.1 x 4.6 231 x 117 2 1 250 320 MAEP0320D OPEN 17.1 x 11.0 x 10.4 434 x 279 x 264 183 83 4 994 10.6 x 4.6 269 x 117 4 1 7.5 x 3.0 191 x 76 1 1 Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. MATRIX® E-Series SELECTION TABLES 22

mtecorp.com CAPACITOR/CAPACITOR PANEL OPEN MAGNETICS FIGURE 1 FIGURE 4 H H H W W H W D D D D FIGURE 2 FIGURE 3 Matrix® E-Series 23

Matrix® One Power quality you can count on. The Single Phase Matrix® ONE Filter provides reliable harmonic protection in environments where utility power may not be optimal. MTE has built the Single Phase Matrix® ONE Filter with time-tested components to work in rural, remote areas where three phase power is often not available. Its patented technology reduces harmonic distortion allowing your equipment to run with increased energy efficiency and better overall THID performance. The Matrix® ONE is designed to generate less heat and reduce system downtime. Easy to install and maintain, the Single Phase Matrix® ONE produces the protection you need to extend the service life of your equipment. Extends the service life of electrical equipment Reduces system downtime Easy to install and maintain Increases energy efficiency Three-year warranty 25

The Single Phase Matrix® ONE Filter is proven to produce harmonic mitigation for your VFD or other single phase power applications. Patented design with reliable components provides harmonic mitigation and reduced THID (Total Harmonic Distortion) where you need it most. Low cost solution that is easy to install and maintain. Performance that is able to withstand harsh and remote conditions. Extends service life of equipment by reducing heat, and improving system efficiency. Alleviates system downtime by preventing blown fuses and tripped circuit breakers. Improve power quality and reduce downtime with our optimized single phase harmonic filters. Matrix®ONE Matrix® ONE Harmonic Spectrum Chart 0 10 20 30 40 50 60 70 Harmonic Current (%) Harmonic Number (n) Drive 100% Load Matrix ONE 100% Load 0 2 4 6 8 10 12 14 16 18 0 20 40 60 80 100 Percent THID (%) Percentage of Full Load (%) Matrix® ONE THID Reduction (%) Matrix® ONE THID Performance (%) Matrix® ONE Filters Utility Power VFD Performance Specifications Service Load Condition Load: typically a 4-pulse rectifier Input Voltage 240V +/- 10%; 60 + 0.75Hz; 1-phase 480V +/- 10%; 60 + 0.75Hz; 1-phase Maximum THID 12% @ Full Load Maximum Ambient Temperature -40°C to +50°C open panel filters; -40°C to +40°C enclosed filters; -40°C to +90°C storage Insertion Loss +10% no load; -10% full load Efficiency 97% - 99% Altitude Without Derating 3,300 feet above sea level Relative Humidity 0% to 95% non-condensing Overload 150% for 1 minute duration Final product specifications subject to change at any time. ® 26

mtecorp.com • Determine voltage, frequency, and number of phases required • Reference motor nameplate to determine motor HP or kW and Full Load Amps • Select filter based on Motor Full Load Amps Do not exceed filter’s maximum current rating (amps) • Specify enclosure style Open (No enclosure) NEMA 1/2 (General Purpose Enclosure) NEMA 3R (Outdoor Enclosure) • Determine derating requirements Reference Performance Specifications table on previous page as well as derating tables listed below: Table 1: Drive Output Frequency Derating Table 2: Altitude Derating Curve Understanding the Matrix® ONE Part Number: Voltage Frequency Code A 240 Volts 60 Hz D 480 Volts 60 Hz Enclosure Type P = Open Magnetics (No Enclosure) G = General Purpose (NEMA 1/2) W = Weather (NEMA 3R) Current Rating 0008 is 8 Amps 0090 is 90 Amps 0620 is 620 Amps Matrix® ONE How to properly size your filter MS X _ _ _ _ X Derating Curves: Table 1: Drive Output Frequency Derating Table 2: Altitude Derating Curve Matrix® One 27
