Motor Protection Filters Product Catalog

Motor Protection Filters Product Catalog mtecorp.com

Variable Frequency Drives (VFDs) are used in a variety of industries to control the speed of AC motors. While VFDs allow for precise control of motors and greater energy savings, they also can create power distortions that cause premature motor failures, unexpected ground fault trips, and erratic behavior. MTE’s best-in-class motor protection filters effectively mitigate, and in some cases eliminate, these challenges. Our unbeatable line of Nexus filters are the only product in the market today that can eliminate harmful common mode over-voltage ensuring your operations run longer and more efficient. Backed by the industry’s only 5-year motor bearing warranty, the Nexus is proven to increase productivity and your bottom line. Whether you need protection at 50 ft or 15,000 ft, MTE’s motor protection filters are built to withstand the hottest, harshest, and most remote locations in the world. Next level motor protection filters.

Contents Motor Protection Filters dV E-Series 4 Next level power protection from the power quality leaders dV Sentry® 12 Next generation dV/dt Filters for motor protection SineWave Guardian® 20 Best-in-class SineWave Filter for cleaning PWM waveforms out to 15,000 ft High Frequency SineWave Guardian® 30 Optimized motor protection solution for high frequency motors SineWave Nexus® 34 An integrated solution for both differential and common mode filtering microNexus™ 42 Powerful protection in a small, compact size 1

MTE Sets The Benchmark For Power Quality Take Advantage of Our Expertise Running a motor directly from the power source produces uniform, sinusoidal waveforms but wastes energy due to continuous speed operation regardless of the load. To enhance efficiency, Variable Frequency Drives (VFDs) control motor speed, reduce energy consumption, and minimize equipment wear. However, VFDs use pulse-width modulation (PWM) to supply electrical pulses instead of a true voltage waveform, generating harmful harmonics that can damage motors, cables, and bearings when the VFD-to-motor distance is significant. Harmonic issues between the VFD and motor are often related to differential mode or common mode voltage and current. Differential mode voltage is the voltage that energizes the motor. Increased differential mode voltages can cause premature failures in both the motor and the cable. As the motor is farther from the VFD, the adverse effects worsen due to increased cable resistance. This leads to a surge in peak voltage and rise time, known as the reflective wave, amplifying the impact. Common mode refers to the voltage or current that appears between all conductors and ground in an electrical system. It can cause interference, damage to components, and unexpected behaviors. VFDs generate power pulses that can introduce common mode voltage and current issues, such as premature motor failure, cable degradation, and electrical fluting, pitting, and frosting of bearings. These must be properly managed to ensure the reliable and efficient operation of the motor and associated equipment. What Effect Does a VFD Have on a Motor? Understanding Differential Mode and Common Mode 2

mtecorp.com RLW/RL Reactors - Protects from differential mode - Reduces motor noise & heat dV E-Series - Protects from differential mode dV Sentry® - Protects from differential mode - Reduces common mode voltage SineWave Guardian® HF SineWave Guardian® - Protects from differential mode - Eliminates peak voltage spikes - Eliminates high frequency content SineWave Nexus® microNexus™ - Protects from differential mode - Eliminate common mode voltage and current What Level Of Motor Protection Do You Need? MTE offers a family of application engineered products designed for the performance you need. The Destructive Effects of Differential and Common Mode Voltage and Current Damaged equipment due to differential mode voltage spikes jeopardize productivity and decrease profitability. Moreover, common mode problems occur outside of the VFD, which is why they are difficult to diagnose making them extremely problematic for everyday operations. Problems that can occur without motor protection filtering: • Damage to motor bearings • Unexpected ground fault trips • Erratic behavior of VFDs and PLCs • Premature motor insulation failure • Cable damage Motor VFD 1,000 ft 15,000 ft 300 ft Reactors dV/dt Filters SineWave Filters 3

mtecorp.com Motor Protection Filters dV E-Series Next level power quality you’ve come to expect from the power quality experts dV Sentry® Next generation dV/dt Filters for motor protection SineWave Guardian® Best-in-class SineWave Filter for cleaning PWM waveforms out to 15,000 ft High Frequency SineWave Guardian® The optimized motor protection solution for high frequency motors SineWave Nexus® An intergrated solution fot both differential and common mode filtering microNexus™ Powerful protection in a small, compact size VFD Motor E-Series Filters 4

dV E-Series Complete protection; convenient design. Downtime in any operation comes at a cost. Damage to motor windings and premature motor insulation failure can result in lost revenue and safety concerns. MTE’s dV E-Series dV/dt motor protection filters ensure your operation runs smoothly during your most critical times. The dV E-Series delivers premium motor protection, extends cable life, and is backed by MTE’s industry-leading Performance Guarantee. Compared to the competition, the dV E-Series offers similar electrical performance in a more compact and optimized design: • Up to 60% more efficient Saves money & runs cooler • Up to 73% lighter and 35% smaller footprint Convenient setup and handling Triple Protection: Reflective wave mitigation, rise time reduction, and peak voltage production Efficient: Low watts (heat) loss Size-optimized design: Lightweight and compact form factor Ease of installation: Footprint and mounting compatible with competitive options Silent operation: As quiet as a conversation 5

The dV E-Series delivers premium protection in a convenient package. dV E-Series A proven filter that provides TRIPLE PROTECTION, by eliminating reflective waves, providing peak voltage protection, as well as, rise time reduction for any application out to 1,000 feet of cable. Reflective wave mitigation matches the impedance of the cable and prevents voltage pulses from reflecting and causing higher peak voltage. Rise time reduction lowers motor heating, and meets NEMA MG 1-1998 Section 31 motor standards. Peak voltage protection when voltage spikes reach dangerous levels. Includes Three-Year Warranty Performance Specifications Service Load Condition Invertor Duty Three Phase Motors Voltage 208 – 600 VAC +/- 10%, 60Hz Input Voltage Wave Form PWM Inverter Switching Frequency 2kHz – 4kHz (3A – 750A) Inverter Operating Frequency 0-60Hz without derating Maximum Ambient Temperature -40C to +60C modular filter -40C to +50C enclosed filter -40C to +90C Storage Insulation System Class N (200° C) Insertion Loss (Voltage) 1.7% at 60 Hz Efficiency >99% Current Range 3A – 750A Available Form Factors Kit, Open Panel, NEMA 1/2, NEMA 3R Altitude without derating 6,600 feet above sea level Maximum Motor Lead Length 1,000 feet (VFD rated cable recommended) Relative Humidity 0% to 99% non-condensing Current Rating 100% RMS Continuous 150% for 1 minute 200% for 10 seconds *Operating in overload will result in increased proportional voltage drop Audible Noise <65db at 1 meter Rise Time Greater than 0.1 uS Peak Voltage @ Motor 150% of DC bus voltage up to 1,000 feet Final product specifications subject to change at anytime. E-Series Filters VFD Peak Rise Protection: Rise Time Reduction: With dV E-Series Without dV E-Series With dV E-Series Without dV E-Series DV E-SERIES PERFORMANCE GUARANTEE MTE Corporation guarantees that the peak voltage at the input of the motor terminals will be limited to 150% when the following conditions are met: • The appropriate size dV E-Series filter is selected and installed in a variable torque AC variable frequency drive application. • Published system limits are adhered to. • Wire lead lenght does not exceed 1,000 ft. • Carrier frequency is 4 kHz. Motor 6

mtecorp.com dV E-Series • Determine input voltage and frequency requirements • Reference motor nameplate to determine motor HP or kW and Full Load Amps • Verify motor meets inverter duty standards per NEMA MG1 Section 31 • Select filter based on Motor Full Load Amps Do not exceed filter’s maximum current rating (amps) • Specify enclosure style Kit (No Enclosure) Open (No enclosure) NEMA 1/2 (General Purpose Enclosure) NEMA 3R (Outdoor Enclosure) • Determine derating requirements Reference Performance Specifications table on previous page as well as derating tables listed below: Table 1: Drive Output Frequency Table 2: Altitude Derating Curve • Note: Filters can be paralleled for higher current ratings. Contact MTE Application Engineering for more information. appengrg@mtecorp.com How to properly size your filter Derating Curves: Understanding the dV E-Series Part Number: Current Rating (i.e. 0045 is 45 Amps) Voltage Frequency Code (208V – 600V) dV E-Series Filter Type K=Kit (No Enclosure) P=Open Magnetics (No Enclosure) G=General Purpose (NEMA 1/2) W=Weather (NEMA 3R) DVT X _ _ _ _ E Table 1: Drive Output Frequency Table 2: Altitude Derating Curve 7

dV E-Series SELECTION TABLES Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. 208 – 600V 50/60Hz Motor Filter Amps Rating MTE Part Number Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Resistor Dimensions (H x W x D) Ref Fig 208V HP 240V HP 380V kW 480V HP 550600V HP Inches Millimeters Lbs Kgs Inches Millimeters 0.5 0.75 0.51.1 0.51.5 0.5-2 3 DVTK0003E KIT 3.7 x 4.5 x 1.5 94 x 114 x 38 3 1 2 51 5.0 x 8.1 x 0.8 127 x 206 x 19 1 DVTP0003E OPEN 8.9 x 5.5 x 7.7 226 x 140 x 196 6 3 7 Preinstalled on reactor panel DVTG0003E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 20 9 12 Preinstalled in cabinet DVTW0003E NEMA 3R 15.5 x 10.9 x 12.0 394 x 277 x 305 30 14 13 0.75 1 1.5 2 3 4 DVTK0004E KIT 3.7 x 4.5 x 1.5 94 x 114 x 38 3 1 2 54 5.0 x 8.1 x 0.8 127 x 206 x 19 1 DVTP0004E OPEN 8.9 x 5.5 x 7.7 226 x 140 x 196 6 3 7 Preinstalled on reactor panel DVTG0004E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 20 9 12 Preinstalled in cabinet DVTW0004E NEMA 3R 15.5 x 10.9 x 12.0 394 x 277 x 305 30 14 13 1.5 2 2.2-3 3 5 7 DVTK0007E KIT 3.7 x 4.5 x 1.5 94 x 114 x 38 3 1 2 64 5.0 x 8.1 x 0.8 127 x 206 x 19 1 DVTP0007E OPEN 8.9 x 5.5 x 7.7 226 x 140 x 196 6 3 7 Preinstalled on reactor panel DVTG0007E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 20 9 12 Preinstalled in cabinet DVTW0007E NEMA 3R 15.5 x 10.9 x 12.0 394 x 277 x 305 30 14 13 2 3 4 5 7.5 9 DVTK0009E KIT 3.7 x 4.5 x 1.5 94 x 114 x 38 3 1 2 70 5.0 x 8.1 x 0.8 127 x 206 x 19 1 DVTP0009E OPEN 8.9 x 5.5 x 7.7 226 x 140 x 196 6 3 7 Preinstalled on reactor panel DVTG0009E NEMA 1/2 13.2 x 5.5 x 7.7 335 x 140 x 196 20 9 12 Preinstalled in cabinet DVTW0009E NEMA 3R 15.5 x 10.9 x 12.0 394 x 277 x 305 30 14 13 3 4 5.5 7.5 10 12 DVTK0012E KIT 3.7 x 4.5 x 1.5 94 x 114 x 38 3 1 2 86 5.0 x 8.1 x 0.8 127 x 206 x 19 1 DVTP0012E OPEN 8.9 x 5.5 x 7.7 226 x 140 x 196 6 3 7 Preinstalled on reactor panel DVTG0012E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 20 9 12 Preinstalled in cabinet DVTW0012E NEMA 3R 15.5 x 10.9 x 12.0 394 x 277 x 305 30 14 13 5 5.5 7.5 10 15 17 DVTK0017E KIT 4.0 x 4.2 x 4.0 102 x 107 x 102 4 2 3 111 5.0 x 8.1 x 0.8 127 x 206 x 19 1 DVTP0017E OPEN 8.9 x 5.5 x 8.0 226 x 140 x 203 7 3 7 Preinstalled on reactor panel DVTG0017E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 21 10 12 Preinstalled in cabinet DVTW0017E NEMA 3R 15.5 x 10.9 x 12.0 394 x 277 x 305 31 14 13 5.5 7.5 11 15 20 22 DVTK0022E KIT 4.0 x 4.2 x 4.0 102 x 107 x 102 4 2 3 97 5.0 x 8.1 x 0.8 127 x 206 x 19 1 DVTP0022E OPEN 8.9 x 5.5 x 8.0 226 x 140 x 203 7 3 7 Preinstalled on reactor panel DVTG0022E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 21 10 12 Preinstalled in cabinet DVTW0022E NEMA 3R 15.5 x 10.9 x 12.0 394 x 277 x 305 31 14 13 7.5 10 - 20 25 27 DVTK0027E KIT 4.0 x 4.2 x 4.0 102 x 107 x 102 4 2 3 95 5.0 x 8.1 x 0.8 127 x 206 x 19 1 DVTP0027E OPEN 8.9 x 5.5 x 8.0 226 x 140 x 203 7 3 7 Preinstalled on reactor panel DVTG0027E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 21 10 12 Preinstalled in cabinet DVTW0027E NEMA 3R 15.5 x 10.9 x 12.0 394 x 277 x 305 31 14 13 10 12.5 15 25 30 35 DVTK0035E KIT 4.0 x 4.2 x 4.0 102 x 107 x 102 4 2 3 91 5.0 x 8.1 x 0.8 127 x 206 x 19 1 DVTP0035E OPEN 12.0 x 8.0 x 8.1 305 x 203 x 206 9 4 7 Preinstalled on reactor panel DVTG0035E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 21 10 12 Preinstalled in cabinet DVTW0035E NEMA 3R 15.5 x 10.9 x 12.0 394 x 277 x 305 31 14 13 12.5 15 18.522 30 40 45 DVTK0045E KIT 4.4 x 4.2 x 4.0 112 x 107 x 102 6 3 3 54 5.0 x 8.1 x 0.8 127 x 206 x 19 1 DVTP0045E OPEN 12.0 x 8.0 x 8.1 305 x 203 x 206 11 5 7 Preinstalled on reactor panel DVTG0045E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 23 10 12 Preinstalled in cabinet DVTW0045E NEMA 3R 15.5 x 10.9 x 12.0 394 x 277 x 305 33 15 13 15 20 - 40 50 55 DVTK0055E KIT 5.0 x 5.9 x 4.3 127 x 150 x 109 8 4 3 102 5.0 x 8.1 x 0.8 127 x 206 x 19 1 DVTP0055E OPEN 12.0 x 8.0 x 9.0 305 x 203 x 229 12 5 7 Preinstalled on reactor panel DVTG0055E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 25 11 12 Preinstalled in cabinet DVTW0055E NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 66 30 14 20 25 30 50 60 65 DVTK0065E KIT 5.0 x 5.9 x 4.7 127 x 150 x 119 10 5 3 152 5.0 x 8.1 x 0.8 127 x 206 x 19 1 DVTP0065E OPEN 12.0 x 8.0 x 9.0 305 x 203 x 229 14 6 7 Preinstalled on reactor panel DVTG0065E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 27 12 12 Preinstalled in cabinet DVTW0065E NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 68 31 14 8

mtecorp.com Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. 208 – 600V 50/60Hz Motor (Ref Only) Filter Amps Rating MTE Part Number Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Resistor Dimensions (H x W x D) Ref Fig 208V HP 240V HP 380V kW 480V HP 550600V HP Inches Millimeters Lbs Kgs Inches Millimeters 25 30 37 60 75 80 DVTK0080E KIT 3.7 x 4.5 x 1.5 94 x 114 x 38 3 1 3 122 5.0 x 8.1 x 0.8 127 x 206 x 19 1 DVTP0080E OPEN 12.0 x 9.0 x 11.1 305 x 229 x 282 32 15 7 Preinstalled on reactor panel DVTG0080E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 42 19 12 Preinstalled in cabinet DVTW0080E NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 85 39 14 30 40 4555 75 100 110 DVTK0110E KIT 5.5 x 7.1 x 5.1 140 x 180 x 130 15 7 4 92 6.3 x 10.3 x 1.3 160 x 262 x 32 1 DVTP0110E OPEN 12.0 x 8.0 x 9.5 305 x 203 x 241 19 9 7 Preinstalled on reactor panel DVTG0110E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 32 15 12 Preinstalled in cabinet DVTW0110E NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 73 33 14 40 50 - 100 125 130 DVTK0130E KIT 5.5 x 7.1 x 5.1 140 x 180 x 130 13 6 4 113 6.3 x 10.3 x 1.3 160 x 262 x 32 1 DVTP0130E OPEN 6.4 x 10.5 x 8.6 163 x 267 x 218 15 7 8 Preinstalled on reactor panel DVTG0130E NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 64 29 15 Preinstalled in cabinet DVTW0130E NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 72 33 14 50 60 7590 125 150 160 DVTK0160E KIT 5.5 x 7.1 x 5.1 140 x 180 x 130 22 10 4 148 6.3 x 10.3 x 1.3 160 x 262 x 32 1 DVTP0160E OPEN 6.4 x 10.5 x 9.9 163 x 267 x 251 24 11 8 Preinstalled on reactor panel DVTG0160E NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 73 33 15 Preinstalled in cabinet DVTW0160E NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 80 36 14 60 75 110 150 200 200 DVTK0200E KIT 6.9 x 8.9 x 6.1 175 x 226 x 155 29 13 4 175 6.3 x 10.3 x 1.3 160 x 262 x 32 1 DVTP0200E OPEN 6.9 x 11.0 x 9.5 175 x 279 x 241 32 15 8 Preinstalled on reactor panel DVTG0200E NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 107 49 15 Preinstalled in cabinet DVTW0200E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 118 54 75 100 132 200 250 250 DVTK0250E KIT 6.9 x 8.9 x 6.1 175 x 226 x 155 29 13 4 207 6.3 x 10.3 x 1.3 160 x 262 x 32 1 DVTP0250E OPEN 7.0 x 11.0 x 9.5 178 x 279 x 241 32 15 9 Preinstalled on reactor panel DVTG0250E NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 107 49 15 Preinstalled in cabinet DVTW0250E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 118 54 100 125 160 250 300 305 DVTK0305E KIT 7.0 x 8.9 x 6.6 178 x 226 x 168 30 14 4 205 6.3 x 10.3 x 1.3 160 x 262 x 32 1 DVTP0305E OPEN 7.3 x 11.5 x 11.0 185 x 292 x 279 35 16 9 Preinstalled on reactor panel DVTG0305E NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 110 50 15 Preinstalled in cabinet DVTW0305E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 120 54 125 150 185200 300 350 365 DVTK0365E KIT 7.3 x 8.9 x 7.2 185 x 226 x 183 41 19 5 239 6.3 x 10.3 x 1.3 160 x 262 x 32 1 DVTP0365E OPEN 7.3 x 11.5 x 11.6 185 x 292 x 295 45 20 9 Preinstalled on reactor panel DVTG0365E NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 120 54 15 Preinstalled in cabinet DVTW0365E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 131 59 150 175 - 350 450 415 DVTK0415E KIT 7.4 x 9.6 x 8.1 188 x 244 x 206 49 22 5 330 6.3 x 10.3 x 1.3 160 x 262 x 32 1 DVTP0415E OPEN 7.3 x 11.5 x 13.0 185 x 292 x 330 57 26 9 Preinstalled on reactor panel DVTG0415E NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 128 58 15 Preinstalled in cabinet DVTW0415E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 139 63 175 225 250 400450 500550 515 DVTK0515E KIT 8.3 x 10.8 x 7.9 211 x 274 x 201 62 28 6 381 6.3 x 10.3 x 1.3 160 x 262 x 32 1 DVTP0515E OPEN 8.4 x 12.3 x 16.4 213 x 312 x 417 72 33 10 Preinstalled on reactor panel DVTG0515E NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 240 109 15 Preinstalled in cabinet DVTW0515E NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 253 115 200 250 315 500 600 600 DVTK0600E KIT 8.4 x 10.8 x 8.6 213 x 274 x 218 71 32 6 350 6.3 x 10.3 x 1.3 160 x 262 x 32 1 DVTP0600E OPEN 8.4 x 12.3 x 16.4 213 x 312 x 417 82 37 10 Preinstalled on reactor panel DVTG0600E NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 249 113 15 Preinstalled in cabinet DVTW0600E NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 262 119 250 300 375 600650 700 750 DVTK0600E KIT 11.1 x 14.3 x 9.5 282 x 363 x 241 113 51 6 411 6.3 x 10.3 x 1.3 160 x 262 x 32 1 DVTP0600E OPEN 11.4 x 15.0 x 18.0 290 x 381 x 457 129 59 11 Preinstalled on reactor panel DVTG0600E NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 296 134 15 Preinstalled in cabinet DVTW0600E NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 309 140 dV E-Series 1 9

dV E-Series REFERENCE FIGURES H H H H H H H H H H W W W W W W W W W W D D D D D D D D D D Note: Figure illustrations are for reference only. Actual hardware may differ. Please visit mtecorp.com for detailed information. FIGURE 1 RESISTOR FIGURE 2 KIT FIGURE 3 KIT FIGURE 5 KIT FIGURE 7 PANEL MOUNT FIGURE 9 PANEL MOUNT FIGURE 4 KIT FIGURE 6 KIT FIGURE 8 PANEL MOUNT FIGURE 10 PANEL MOUNT 10

mtecorp.com H W D D W H D W D W H H Note: Figure illustrations are for reference only. Actual hardware may differ. Please visit mtecorp.com for detailed information. dV E-Series FIGURE 15 FIGURE 14 FIGURE 12 FIGURE 13 NOTE: HOODS ONLY ON NEMA 3R ENCLOSURES NOTE: HOODS ONLY ON NEMA 3R ENCLOSURES H W D FIGURE 11 PANEL MOUNT ENCLOSURES 11

dV Sentry® The future is here. The dV Sentry® is the revolutionary solution for motor protection with its unique all-inone design. It is the only filter on the market proven to provide common mode and rise time reduction, as well as peak voltage protection. This gives greater motor protection over time. It features a small footprint and easy terminations to make installation faster and easier. Plus, it runs quietly and radiates less heat than previous filters. The dV Sentry is unique, and when it comes to motor protection, there is nothing better. True common mode reduction, peak voltage protection, and rise time reduction World leading motor protection technology in the market Low watts loss Small, advanced, robust design, easily installed Quiet as a conversation Three-year warranty 13

With the patented dV Sentry®, you get the most advanced motor protection in its class. dV Sentry® The unique design of the dV Sentry® allows for greater load side protection from voltage spikes and common mode voltages for your AC motors cable and VFDs. Patented designprovides over 50% common mode reduction, peak voltage protection, and rise time reduction – all in one filter. Low watts loss reduces heating in systems. Small footprint, with a unique flat design, allows filter to be easily integrated. Strong robust designallows the filter to withstand installation and other difficult environments. Runs quieter, comparable to a normal conversation. Common Mode Reduction: With dV Sentry® Without dV Sentry® Peak Rise Protection: With dV Sentry® Without dV Sentry® Rise Time Reduction: With dV Sentry® Without dV Sentry® Performance Specifications Input Voltage 208V - 600V +/- 10%; 60Hz Inverter Operating Frequency 0 – 90Hz without derating Maximum Ambient Temperature -40°C to +60°C modular filter -40°C to +50°C enclosed filter Insertion Loss (Voltage) 1.7% @ 60Hz; 2.6% @ 90Hz Efficiency >99% Altitude Without Derating 3,300 feet above sea level Maximum Motor Lead Length 1,000 feet Relative Humidity 0% to 99% non-condensing Current Rating 100% RMS continuous; 150% for 1 minute; 200% for 10 sec* *Operating in overload will result in increased proportional voltage drop Rise Time Less than 0.1 uS Peak Voltage 150% of DC bus voltage up to 1,000 feet Common Mode Reduction 50%+ peak current reduction typical Final product specifications subject to change at any time. VFD Motor Filters dV Sentry® 14

mtecorp.com • Determine input voltage and frequency requirements • Reference motor nameplate to determine motor HP or kW and Full Load Amps • Verify motor meets inverter duty standards per NEMA MG1 Section 31 • Select filter based on Motor Full Load Amps Do not exceed filter’s maximum current rating (amps) • Specify enclosure style Open (No enclosure) NEMA 1/2 (General Purpose Enclosure) NEMA 3R (Outdoor Enclosure) • Determine derating requirements Reference Performance Specifications table on previous page as well as derating tables listed below: Table 1: Drive Output Frequency Table 2: Altitude Derating Curve • Note: Filters can be paralleled for higher current ratings. Contact MTE Application Engineering for more information. appengrg@mtecorp.com How to properly size your filter Derating Curves: Understanding the dV Sentry® Part Number: Current Rating (i.e. 0045 is 45 Amps) Voltage Frequency Code (208V – 600V) dV Sentry® Filter Type P=Open Magnetics (No Enclosure) G=General Purpose (NEMA 1/2) W=Weather (NEMA 3R) DVS X _ _ _ _ E Table 1: Drive Output Frequency Table 2: Altitude Derating Curve dV Sentry® 15

dV Sentry® SELECTION TABLES Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. 208 – 600V 50/60Hz Motor (Ref Only) Filter Amps Rating MTE Part Number Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Resistor Panel Dimensions (H x W x D) Ref Fig 208V HP 240V HP 380V kW 480V HP 550600V HP Inches Millimeters Lbs Kgs Inches Millimeters 0.5 0.75 0.51.1 0.51.5 0.5-2 3 DVSP0003E OPEN 9.1 x 6.7 x 7.7 231 x 170 x 196 7 3 2 67 Preinstalled on reactor panel DVSG0003E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 18 8 6 Preinstalled in cabinet DVSW0003E NEMA 3R 15.5 x 11.0 x 12.0 394 x 279 x 305 29 13 8 0.75 1 1.5 2 3 4 DVSP0004E OPEN 9.1 x 6.7 x 7.7 231 x 170 x 196 7 3 2 67 Preinstalled on reactor panel DVSG0004E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 18 8 6 Preinstalled in cabinet DVSW0004E NEMA 3R 15.5 x 11.0 x 12.0 394 x 279 x 305 29 13 8 1.5 2 2.2-3 3 5 7 DVSP0007E OPEN 9.1 x 6.7 x 7.7 231 x 170 x 196 7 3 2 67 Preinstalled on reactor panel DVSG0007E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 18 8 6 Preinstalled in cabinet DVSW0007E NEMA 3R 15.5 x 11.0 x 12.0 394 x 279 x 305 29 13 8 2 3 4 5 7.5 9 DVSP0009E OPEN 9.1 x 6.7 x 7.7 231 x 170 x 196 7 3 2 67 Preinstalled on reactor panel DVSG0009E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 18 8 6 Preinstalled in cabinet DVSW0009E NEMA 3R 15.5 x 11.0 x 12.0 394 x 279 x 305 29 13 8 3 4 5.5 7.5 10 12 DVSP0012E OPEN 9.1 x 6.7 x 7.7 231 x 170 x 196 7 3 2 67 Preinstalled on reactor panel DVSG0012E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 18 8 6 Preinstalled in cabinet DVSW0012E NEMA 3R 15.5 x 11.0 x 12.0 394 x 279 x 305 29 13 8 5 5.5 7.5 10 15 17 DVSP0017E OPEN 9.1 x 6.7 x 7.5 231 x 170 x 191 8 4 2 96 Preinstalled on reactor panel DVSG0017E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 19 9 6 Preinstalled in cabinet DVSW0017E NEMA 3R 15.5 x 11.0 x 12.0 394 x 279 x 305 30 14 8 5.5 7.5 11 15 20 22 DVSP0022E OPEN 9.1 x 6.7 x 8.2 231 x 170 x 208 11 5 2 91 Preinstalled on reactor panel DVSG0022E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 22 10 6 Preinstalled in cabinet DVSW0022E NEMA 3R 15.5 x 11.0 x 12.0 394 x 279 x 305 32 15 8 7.5 10 - 20 25 27 DVSP0027E OPEN 9.1 x 6.7 x 8.2 231 x 170 x 208 11 5 2 92 Preinstalled on reactor panel DVSG0027E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 22 10 6 Preinstalled in cabinet DVSW0027E NEMA 3R 15.5 x 11.0 x 12.0 394 x 279 x 305 32 15 8 10 12.5 15 25 30 35 DVSP0035E OPEN 12.0 x 9.0 x 8.0 305 x 229 x 203 15 7 3 91 Preinstalled on reactor panel DVSG0035E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 25 11 6 Preinstalled in cabinet DVSW0035E NEMA 3R 15.5 x 11.0 x 12.0 394 x 279 x 305 35 16 8 12.5 15 18.522 30 40 45 DVSP0045E OPEN 12.0 x 9.0 x 8.0 305 x 229 x 203 16 7 3 88 Preinstalled on reactor panel DVSG0045E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 25 11 6 Preinstalled in cabinet DVSW0045E NEMA 3R 15.5 x 11.0 x 12.0 394 x 279 x 305 35 16 8 15 20 - 40 50 55 DVSP0055E OPEN 12.0 x 9.0 x 8.2 305 x 229 x 208 22 10 3 137 Preinstalled on reactor panel DVSG0055E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 32 15 6 Preinstalled in cabinet DVSW0055E NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 75 34 9 20 25 30 50 60 65 DVSP0065E OPEN 12.0 x 9.0 x 11.1 305 x 229 x 282 31 14 3 166 Preinstalled on reactor panel DVSG0065E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 41 19 6 Preinstalled in cabinet DVSW0065E NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 84 38 9 16

mtecorp.com Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. 208 – 600V 50/60Hz Motor (Ref Only) Filter Amps Rating MTE Part Number Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Resistor Panel Dimensions (H x W x D) Ref Fig 208V HP 240V HP 380V kW 480V HP 550600V HP Inches Millimeters Lbs Kgs Inches Millimeters 25 30 37 60 75 80 DVSP0080E OPEN 12.0 x 9.0 x 11.1 305 x 229 x 282 32 15 3 158 Preinstalled on reactor panel DVSG0080E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 42 19 6 Preinstalled in cabinet DVSW0080E NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 85 39 9 30 40 4555 75 100 110 DVSP0110E OPEN 12.0 x 9.0 x 11.1 305 x 229 x 282 36 16 3 175 Preinstalled on reactor panel DVSG0110E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 43 20 6 Preinstalled in cabinet DVSW0110E NEMA 3R 24.0 x 12.5 x 23.0 610 x 318 x 584 89 40 9 40 50 - 100 125 130 DVSP0130E OPEN 13.5 x 13.6 x 7.9 343 x 345 x 201 56 25 4 273 18.4 x 5.0 x 7.0 467 x 127 x 178 1A DVSG0130E NEMA 1/2 24.0 x 17.1 x 18.5 610 x 434 x 470 97 44 7 Preinstalled in cabinet DVSW0130E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 139 63 10 50 60 7590 125 150 160 DVSP0160E OPEN 13.5 x 13.6 x 9.1 343 x 345 x 231 72 33 4 289 18.4 x 5.0 x 7.0 467 x 127 x 178 1A DVSG0160E NEMA 1/2 24.0 x 17.1 x 18.5 610 x 434 x 470 113 51 7 Preinstalled in cabinet DVSW0160E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 155 70 10 60 75 110 150 200 200 DVSP0200E OPEN 13.5 x 13.6 x 9.1 343 x 345 x 231 76 34 4 325 18.4 x 5.0 x 7.0 467 x 127 x 178 1A DVSG0200E NEMA 1/2 24.0 x 17.1 x 18.5 610 x 434 x 470 116 53 7 Preinstalled in cabinet DVSW0200E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 157 71 10 75 100 132 200 250 250 DVSP0250E OPEN 15.0 x 15.1 x 10.3 381 x 384 x 262 90 41 5 423 18.4 x 5.0 x 7.0 467 x 127 x 178 1A DVSG0250E NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 165 75 10 Preinstalled in cabinet DVSW0250E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 173 78 100 125 160 250 300 305 DVSP0305E OPEN 15.2 x 15.1 x 10.4 386 x 384 x 264 94 43 5 481 18.4 x 5.0 x 7.0 467 x 127 x 178 1A DVSG0305E NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 170 77 10 Preinstalled in cabinet DVSW0305E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 177 80 125 150 185200 300 350 365 DVSP0365E OPEN 15.1 x 15.1 x 11.8 384 x 384 x 300 125 57 5 564 18.4 x 5.0 x 7.0 467 x 127 x 178 1A DVSG0365E NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 200 91 10 Preinstalled in cabinet DVSW0365E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 208 94 150 175 - 350 450 415 DVSP0415E OPEN 15.1 x 15.1 x 11.8 384 x 384 x 300 125 57 5 795 18.4 x 5.0 x 7.0 467 x 127 x 178 1A DVSG0415E NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 200 91 10 Preinstalled in cabinet DVSW0415E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 208 94 175 225 250 400450 500550 515 DVSP0515E OPEN 14.9 x 15.1 x 13.3 378 x 384 x 338 158 72 5 798 18.4 x 5.0 x 7.0 467 x 127 x 178 1B DVSG0515E NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 326 148 10 Preinstalled in cabinet DVSW0515E NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 339 154 200 250 315 500 600 600 DVSP0600E OPEN 15.1 x 15.1 x 13.4 384 x 384 x 340 165 75 5 822 18.4 x 5.0 x 7.0 467 x 127 x 178 1B DVSG0600E NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 332 151 10 Preinstalled in cabinet DVSW0600E NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 345 156 dV Sentry® 17

dV Sentry® REFERENCE FIGURES H W D H W D D H W D H W OPEN MAGNETICS RESISTOR PANEL FIGURE 1B FIGURE 1A H H W H H W FIGURE 4 FIGURE 5 FIGURE 2 FIGURE 3 Note: Figure illustrations are for reference only. Actual hardware may differ. Please visit mtecorp.com for detailed information. 18

mtecorp.com dV Sentry® ENCLOSURES H W D H W D D W H D W D W H H Note: Figure illustrations are for reference only. Actual hardware may differ. Please visit mtecorp.com for detailed information. FIGURE 10 FIGURE 6 FIGURE 9 FIGURE 7 FIGURE 8 NOTE: HOODS ONLY ON NEMA 3R ENCLOSURES NOTE: HOODS ONLY ON NEMA 3R ENCLOSURES 19

mtecorp.com VFD SineWave Guardian® Motor Protection Filters dV E-Series Next level power quality you’ve come to expect from the power quality experts dV Sentry® Next generation dV/dt Filters for motor protection SineWave Guardian® Best-in-class SineWave Filter for cleaning PWM waveforms out to 15,000 ft High Frequency SineWave Guardian® The optimized motor protection solution for high frequency motors SineWave Nexus® An intergrated solution fot both differential and common mode filtering microNexus™ Powerful protection in a small, compact size Motor 20

SineWave Guardian® Quality motor protection for miles - literally. Motor protection and power quality don’t have to be a mystery. MTE makes it easy. Case in point: our SineWave Guardian® Filter. This best-in-class filter delivers unequaled performance in cleaning the PWM waveforms generated by Variable Frequency Drives (VFDs). It virtually eliminates high frequency content and voltage peaks, thereby reducing motor heating to give you extended motor life – and less downtime. The SineWave Guardian also offers incredible reliability and durability. It is more efficient and tolerates higher ambient temperatures, making it ideal for a variety of applications from steel mills to oil fields. Its modular design and smaller footprint make it easier to integrate and install. It all adds up to the best SineWave Filter, and the best value on the market today. Increases motor life Easy to integrate, install and service Operates in high ambient temperatures High performance and reliability Three-year warranty 21

How to properly size your filter • Determine voltage and frequency requirements • Reference motor nameplate to determine motor HP or kW and Full Load Amps • Verify motor meets inverter duty standards per NEMA MG1 Section 31 • Select filter based on Motor Full Load Amps Do not exceed filter’s maximum current rating (amps) • Specify enclosure style Open (No enclosure) NEMA 1/2 (General Purpose Enclosure) NEMA 3R (Outdoor Enclosure) • Determine derating requirements Reference Performance Specifications table Understanding the SineWave Guardian® Part Number: Current Rating 0002 is 2 Amps 0720 is 720 Amps Voltage Frequency Code A (208V – 240V) D (380V – 480V) E (600V) SineWave Guardian® Enclosure Type M=Open Magnetics (No Enclosure) G=General Purpose (NEMA 1/2) W=Weather (NEMA 3R) SWG X _ _ _ _ X VFD Improve efficiency, improve motor life, and improve your bottom line with our new SineWave Guardian®. SineWave Guardian® SineWave Guardian® Filters transform the output of Variable Frequency Drives (VFDs) to a near perfect sinusoidal waveform for the best level of motor protection. MTE’s unique, patented design offers higher performance with smaller size and better efficiency than traditional LC Filters. Application Configurations: Extreme Long Lead to Motor Long Lead with Step-up Transformer Multiple Motors Performance Specifications Service Load Condition Conventional 3 phase motors Standard step-up transformer optional Input Voltage 208V – 600V +/– 10% Current Range 2A – 1500A (.75 HP – 1200 HP) Harmonic Voltage Distortion 5% maximum @ 2kHz Inverter Switching Frequency 2kHz to 8kHz Inverter Operating Frequency 6Hz to 75Hz; >75Hz to 120Hz with derating Maximum Ambient Temperature -40°C to +60°C modular filter -40°C to +55°C enclosed filter -40°C to +90°C storage Insertion Loss (Voltage) 6% maximum @ 60Hz Efficiency >98% Altitude Without Derating 3,300 feet above sea level Maximum Motor Lead Length 15,000 feet Relative Humidity 0% to 95% non-condensing Current Rating 100% RMS continuous; 150% for 1 minute intermittent Final product specifications subject to change at any time. SineWave Guardian® Filters SineWave Guardian® Filters SineWave Guardian® Filters 22

mtecorp.com SineWave Guardian® Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. 208V – 240V 75Hz Motor (Ref Only) Filter Amps Rating MTE Part Number Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Capacitor/Capacitor Panel Assembly Dimensions (H x W x D) Qty Req’d Ref Fig 208V HP 240V HP Inches Millimeters Lbs Kgs Inches Millimeters 2 3 9 SWGM0009A OPEN 6.6 x 8.0 x 4.8 168 x 203 x 122 11 5 7 63 7.5 x 3.0 191 x 76 1 1 SWGG0009A NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 28 13 3 Preinstalled in cabinet SWGW0009A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 69 31 5 3 4 12 SWGM0012A OPEN 6.7 x 8.0 x 5.1 170 x 203 x 130 14 6 7 75 7.5 x 3.0 191 x 76 1 1 SWGG0012A NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 30 14 3 Preinstalled in cabinet SWGW0012A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 69 31 5 5 5.5 17 SWGM0017A OPEN 6.7 x 8.0 x 5.1 170 x 203 x 130 14 6 7 101 7.5 x 3.9 191 x 99 1 1 SWGG0017A NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 30 14 3 Preinstalled in cabinet SWGW0017A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 69 31 5 5.5 7.5 22 SWGM0022A OPEN 6.6 x 8.0 x 5.4 168 x 203 x 137 15 7 7 112 8.3 x 3.0 211 x 76 1 1 SWGG0022A NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 32 15 3 Preinstalled in cabinet SWGW0022A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 71 32 5 7.5 10 30 SWGM0030A OPEN 7.5 x 9.0 x 4.8 191 x 229 x 122 18 8 7 100 8.3 x 3.0 211 x 76 1 1 SWGG0030A NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 34 15 3 Preinstalled in cabinet SWGW0030A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 73 33 5 10 - 12.5 15 45 SWGM0045A OPEN 8.7 x 10.5 x 6.7 221 x 267 x 170 28 13 7 138 8.3 x 4.6 211 x 117 1 1 SWGG0045A NEMA 1/2 24.0 x 17.0 x 18.5 610 x 432 x 470 78 35 4 Preinstalled in cabinet SWGW0045A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 85 39 5 15 20 55 SWGM0055A OPEN 9.0 x 10.5 x 7.4 229 x 267 x 188 32 15 8 162 8.3 x 4.6 211 x 117 1 1 SWGG0055A NEMA 1/2 24.0 x 17.0 x 18.5 610 x 432 x 470 80 36 4 Preinstalled in cabinet SWGW0055A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 87 40 5 20 25 70 SWGM0070A OPEN 9.0 x 10.5 x 7.9 229 x 267 x 201 34 15 8 192 8.3 x 3.0 211 x 76 1 1 SWGG0070A NEMA 1/2 24.0 x 17.0 x 18.5 610 x 432 x 470 82 37 4 Preinstalled in cabinet SWGW0070A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 90 41 5 25 30 85 SWGM0085A OPEN 8.7 x 10.5 x 7.2 221 x 267 x 183 38 17 8 201 8.3 x 3.0 211 x 76 1 1 SWGG0085A NEMA 1/2 24.0 x 17.0 x 18.5 610 x 432 x 470 86 39 4 Preinstalled in cabinet SWGW0085A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 93 42 5 30 40 110 SWGM0110A OPEN 8.7 x 10.5 x 8.9 221 x 267 x 226 53 24 8 226 8.3 x 4.0 211 x 102 1 1 SWGG0110A NEMA 1/2 24.0 x 17.0 x 18.5 610 x 432 x 470 101 46 4 Preinstalled in cabinet SWGW0110A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 109 49 5 40 50 135 SWGM0135A OPEN 11.0 x 12.0 x 9.3 279 x 305 x 236 72 33 9 299 8.3 x 3.0 211 x 76 1 1 SWGG0135A NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 148 67 6 Preinstalled in cabinet SWGW0135A NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 159 72 50 60 160 SWGM0160A OPEN 10.6 x 12.0 x 9.7 269 x 305 x 246 74 34 9 303 8.3 x 4.6 211 x 117 1 1 SWGG0160A NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 150 68 6 Preinstalled in cabinet SWGW0160A NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 161 73 60 75 200 SWGM0200A OPEN 10.9 x 12.0 x 11.4 277 x 305 x 290 120 54 9 387 8.3 x 4.0 211 x 102 1 1 SWGG0200A NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 199 90 6 Preinstalled in cabinet SWGW0200A NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 209 95 75 100 250 SWGM0250A OPEN 10.5 x 12.0 x 11.2 267 x 305 x 284 110 50 9 374 8.3 x 3.0 211 x 76 1 1 8.3 x 4.6 211 x 117 1 SWGG0250A NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 189 86 6 Preinstalled in cabinet SWGW0250A NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 199 90 100 125 320 SWGM0320A OPEN 14.2 x 15.3 x 11.8 361 x 389 x 300 153 69 10 637 7.4 x 16.4 x 7.6 188 x 417 x 193 1 2 SWGG0320A NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 321 146 6 Preinstalled in cabinet SWGW0320A NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 334 151 23

SineWave Guardian® SELECTION TABLES Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. 380V – 480V 75Hz Motor (Ref Only) Filter Amps Rating MTE Part Number Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Capacitor/Capacitor Panel Assembly Dimensions (H x W x D) Qty Req’d Ref Fig 380V kW 480V HP Inches Millimeters Lbs Kgs Inches Millimeters 0.55 0.75 2 SWGM0002D OPEN 4.9 x 4.4 x 2.6 124 x 112 x 66 5 2 7 25 7.5 x 3.0 191 x 76 1 1 SWGG0002D NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 19 9 3 Preinstalled in cabinet SWGW0002D NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 62 28 5 0.75 1.5 3 SWGM0003D OPEN 4.9 x 4.4 x 3.3 124 x 112 x 84 7 3 7 45 7.5 x 3.0 191 x 76 1 1 SWGG0003D NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 21 10 3 Preinstalled in cabinet SWGW0003D NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 64 29 5 2.2 3 5 SWGM0005D OPEN 6.6 x 8.0 x 4.8 168 x 203 x 122 11 5 7 75 7.5 x 3.0 191 x 76 1 1 SWGG0005D NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 25 11 3 Preinstalled in cabinet SWGW0005D NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 68 31 5 3 4 7 SWGM0007D OPEN 6.7 x 8.0 x 5.1 170 x 203 x 130 13 6 7 91 7.5 x 3.0 191 x 76 1 1 SWGG0007D NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 27 12 3 Preinstalled in cabinet SWGW0007D NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 61 28 5 4 5.5 9 SWGM0009D OPEN 6.7 x 8.0 x 5.1 170 x 203 x 130 14 6 7 97 7.5 x 3.0 191 x 76 1 1 SWGG0009D NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 28 13 3 Preinstalled in cabinet SWGW0009D NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 54 24 5 5.5 7.5 12 SWGM0012D OPEN 6.7 x 8.0 x 5.4 170 x 203 x 137 15 7 7 127 7.5 x 3.0 191 x 76 1 1 SWGG0012D NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 29 13 3 Preinstalled in cabinet SWGW0012D NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 70 32 5 7.5 10 17 SWGM0017D OPEN 7.5 x 9.0 x 4.8 191 x 229 x 122 20 9 7 130 7.5 x 3.0 191 x 76 1 1 SWGG0017D NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 34 15 3 Preinstalled in cabinet SWGW0017D NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 76 34 5 11 15 22 SWGM0022D OPEN 8.7 x 10.5 x 6.7 221 x 267 x 170 32 15 7 135 7.5 x 3.0 191 x 76 1 1 SWGG0022D NEMA 1/2 24.0 x 17.0 x 18.5 610 x 432 x 470 79 36 4 Preinstalled in cabinet SWGW0022D NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 87 39 5 - 20 27 SWGM0027D OPEN 8.7 x 10.5 x 6.7 221 x 267 x 170 35 16 8 140 7.5 x 3.0 191 x 76 1 1 SWGG0027D NEMA 1/2 24.0 x 17.0 x 18.5 610 x 432 x 470 82 37 4 Preinstalled in cabinet SWGW0027D NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 90 41 5 18.5 25 35 SWGM0035D OPEN 8.9 x 10.5 x 6.7 226 x 267 x 170 39 18 8 210 7.5 x 3.9 191 x 99 1 1 SWGG0035D NEMA 1/2 24.0 x 17.0 x 18.5 610 x 432 x 470 87 39 4 Preinstalled in cabinet SWGW0035D NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 94 43 5 22 30 45 SWGM0045D OPEN 8.8 x 10.5 x 7.2 224 x 267 x 183 40 18 8 225 7.5 x 3.9 191 x 99 1 1 SWGG0045D NEMA 1/2 24.0 x 17.0 x 18.5 610 x 432 x 470 90 41 4 Preinstalled in cabinet SWGW0045D NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 98 44 5 - 40 55 SWGM0055D OPEN 8.8 x 10.5 x 6.7 224 x 267 x 170 54 24 9 301 8.0 x 3.9 203 x 99 1 1 SWGG0055D NEMA 1/2 24.0 x 17.0 x 18.5 610 x 432 x 470 101 46 4 Preinstalled in cabinet SWGW0055D NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 109 49 5 30 50 65 SWGM0065D OPEN 10.7 x 12.0 x 8.6 272 x 305 x 218 59 27 9 310 8.0 x 3.9 203 x 99 1 1 SWGG0065D NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 136 62 6 Preinstalled in cabinet SWGW0065D NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 143 65 37 60 80 SWGM0080D OPEN 10.8 x 12.0 x 9.0 274 x 305 x 229 75 34 9 387 8.3 x 4.6 211 x 117 1 1 SWGG0080D NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 150 68 6 Preinstalled in cabinet SWGW0080D NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 157 71 55 75 110 SWGM0110D OPEN 10.7 x 12.0 x 10.5 272 x 305 x 267 105 48 9 395 8.3 x 4.6 211 x 117 1 1 SWGG0110D NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 180 82 6 Preinstalled in cabinet SWGW0110D NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 187 85 24

mtecorp.com SineWave Guardian® Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. 380V – 480V 75Hz Motor (Ref Only) Filter Amps Rating MTE Part Number Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Capacitor/Capacitor Panel Assembly Dimensions (H x W x D) Qty Req’d Ref Fig 380V kW 480V HP Inches Millimeters Lbs Kgs Inches Millimeters - 100 130 SWGM0130D OPEN 10.7 x 12.0 x 11.5 272 x 305 x 292 108 49 10 420 8.3 x 4.6 211 x 117 1 1 SWGG0130D NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 182 83 6 Preinstalled in cabinet SWGW0130D NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 189 86 75 125 160 SWGM0160D OPEN 14.5 x 15.3 x 11.3 368 x 389 x 287 160 73 10 595 6.7 x 16.4 x 7.6 170 x 417 x 193 1 2 SWGG0160D NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 327 148 6 Preinstalled in cabinet SWGW0160D NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 340 154 110 150 200 SWGM0200D OPEN 14.5 x 15.3 x 14.8 368 x 389 x 376 166 75 10 650 6.7 x 16.4 x 7.6 170 x 417 x 193 1 2 SWGG0200D NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 336 152 6 Preinstalled in cabinet SWGW0200D NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 349 158 132 200 250 SWGM0250D OPEN 14.5 x 15.3 x 13.8 368 x 389 x 351 220 100 10 775 6.9 x 16.3 x 7.6 175 x 414 x 193 1 2 SWGG0250D NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 381 173 6 Preinstalled in cabinet SWGW0250D NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 395 179 160 250 305 SWGM0305D OPEN 14.6 x 15.3 x 14.8 371 x 389 x 376 260 118 11 945 7.4 x 16.4 x 7.6 188 x 417 x 193 1 2 SWGG0305D NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 430 195 6 Preinstalled in cabinet SWGW0305D NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 443 201 200 300 365 SWGM0365D OPEN 14.6 x 15.3 x 15.2 371 x 389 x 386 310 141 11 1,050 8.3 x 16.4 x 7.6 211 x 417 x 193 1 2 SWGG0365D NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 480 218 6 Preinstalled in cabinet SWGW0365D NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 493 224 220 350 415 SWGM0415D OPEN 14.6 x 15.3 x 15.2 371 x 389 x 386 326 148 11 1,137 8.3 x 16.4 x 7.6 211 x 417 x 193 1 2 SWGG0415D NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 496 225 6 Preinstalled in cabinet SWGW0415D NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 509 231 280 450 515 SWGM0515D OPEN 15.0 x 15.3 x 16.2 381 x 389 x 411 355 161 12 1,235 9.9 x 16.4 x 7.6 251 x 417 x 193 1 2 SWGG0515D NEMA 1/2 87.6 x 43.7 x 31.1 2225 x 1110 x 790 764 347 6 Preinstalled in cabinet SWGW0515D NEMA 3R 87.6 x 43.7 x 40.1 2225 x 1110 x 1019 800 363 335 500 600 SWGM0600D OPEN 18.3 x 24.0 x 14.6 465 x 610 x 371 483 219 12 2,225 9.9 x 16.4 x 7.6 251 x 417 x 193 1 2 SWGG0600D NEMA 1/2 87.6 x 43.7 x 31.1 2225 x 1110 x 790 896 406 6 Preinstalled in cabinet SWGW0600D NEMA 3R 87.6 x 43.7 x 40.1 2225 x 1110 x 1019 932 423 375 600 720 SWGM0720D OPEN 18.2 x 24.0 x 17.5 462 x 610 x 445 711 323 12 2,300 8.3 x 16.4 x 7.6 211 x 417 x 193 1 2 9.9 x 16.4 x 7.6 251 x 417 x 193 1 SWGG0720D NEMA 1/2 87.6 x 43.7 x 31.1 2225 x 1110 x 790 1,127 511 6 Preinstalled in cabinet SWGW0720D NEMA 3R 87.6 x 43.7 x 40.1 2225 x 1110 x 1019 1,164 528 450 700 850 SWGM0850D OPEN 18.2 x 24.0 x 19.0 462 x 610 x 483 835 379 12 2,556 7.7 x 16.4 x 7.6 196 x 417 x 193 1 2 9.9 x 16.4 x 7.6 251 x 417 x 193 2 SWGG0850D NEMA 1/2 84.0 x 52.0 x 36.5 2134 x 1321 x 927 1,470 667 6 Preinstalled in cabinet SWGW0850D NEMA 3R 84.0 x 52.0 x 45.5 2134 x 1321 x 1156 1,511 685 560 850 1000 SWGM1000D OPEN 18.1 x 24.0 x 20.6 460 x 610 x 523 942 427 12 2,850 7.4 x 16.4 x 7.6 188 x 417 x 193 1 2 9.9 x 16.4 x 7.6 251 x 417 x 193 2 SWGG1000D NEMA 1/2 84.0 x 52.0 x 36.5 2134 x 1321 x 927 1,580 717 6 Preinstalled in cabinet SWGW1000D NEMA 3R 84.0 x 52.0 x 45.5 2134 x 1321 x 1156 1,621 735 675 1000 1200 SWGM1200D OPEN 25.7 x 24.0 x 20.3 653 x 610 x 516 1,272 577 13 3,000 9.9 x 16.4 x 7.6 251 x 416.6 x 193 3 2 SWGG1200D NEMA 1/2 84.0 x 52.0 x 36.5 2134 x 1321 x 927 1,921 871 6 Preinstalled in cabinet SWGW1200D NEMA 3R 84.0 x 52.0 x 45.5 2134 x 1321 x 1156 1,962 890 800 1200 1500 SWGM1500D OPEN 25.9 x 24.0 x 20.0 658 x 610 x 508 1,296 588 13 3,210 9.9 x 16.4 x 7.6 251 x 417 x 193 3 2 SWGG1500D NEMA 1/2 84.0 x 52.0 x 36.5 2134 x 1321 x 927 1,945 882 6 Preinstalled in cabinet SWGW1500D NEMA 3R 84.0 x 52.0 x 45.5 2134 x 1321 x 1156 1,986 901 25

SineWave Guardian® SELECTION TABLES Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. 600V 75Hz Motor (Ref Only) Filter Amps Rating MTE Part Number Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Capacitor/Capacitor Panel Assembly Dimensions (H x W x D) Qty Req’d Ref Fig 600V kW 600V HP Inches Millimeters Lbs Kgs Inches Millimeters 0.75 1 2 SWGM0002E OPEN 4.9 x 4.4 x 3.0 124 x 112 x 76 8 4 7 30 7.9 x 3.0 201 x 76 1 1 SWGG0002E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 22 10 3 Preinstalled in cabinet SWGW0002E NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 65 29 5 1.5 2 3 SWGM0003E OPEN 6.7 x 8.0 x 4.8 170 x 203 x 122 11 5 7 51 7.9 x 3.0 201 x 76 1 1 SWGG0003E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 25 11 3 Preinstalled in cabinet SWGW0003E NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 68 31 5 3 3 5 SWGM0005E OPEN 6.6 x 8.0 x 5.1 168 x 203 x 130 14 6 7 77 7.9 x 3.0 201 x 76 1 1 SWGG0005E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 28 13 3 Preinstalled in cabinet SWGW0005E NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 69 31 5 3.7 5 7 SWGM0007E OPEN 6.7 x 8.0 x 5.4 170 x 203 x 137 15 7 7 97 7.9 x 3.0 201 x 76 1 1 SWGG0007E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 29 13 3 Preinstalled in cabinet SWGW0007E NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 70 32 5 5.5 7.5 9 SWGM0009E OPEN 6.7 x 8.0 x 4.3 170 x 203 x 109 17 8 7 124 7.9 x 3.0 201 x 76 1 1 SWGG0009E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 32 15 3 Preinstalled in cabinet SWGW0009E NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 72 33 5 7.5 10 12 SWGM0012E OPEN 7.5 x 9.0 x 4.8 191 x 229 x 122 20 9 7 126 7.9 x 3.0 201 x 76 1 1 SWGG0012E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 35 16 3 Preinstalled in cabinet SWGW0012E NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 75 34 5 11 15 17 SWGM0017E OPEN 7.5 x 9.0 x 5.3 191 x 229 x 135 26 12 7 133 7.9 x 3.0 201 x 76 1 1 SWGG0017E NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 40 18 3 Preinstalled in cabinet SWGW0017E NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 81 37 5 15 20 22 SWGM0022E OPEN 8.7 x 10.5 x 6.7 221 x 267 x 170 34 15 7 146 7.9 x 3.0 201 x 76 1 1 SWGG0022E NEMA 1/2 24.0 x 17.0 x 18.5 610 x 432 x 470 82 37 4 Preinstalled in cabinet SWGW0022E NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 89 40 5 18.5 25 27 SWGM0027E OPEN 8.7 x 10.5 x 7.7 221 x 267 x 196 40 18 8 156 7.9 x 3.0 201 x 76 1 1 SWGG0027E NEMA 1/2 24.0 x 17.0 x 18.5 610 x 432 x 470 88 40 4 Preinstalled in cabinet SWGW0027E NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 95 43 5 22 30 35 SWGM0035E OPEN 8.7 x 10.5 x 7.7 221 x 267 x 196 40 18 8 210 7.9 x 3.0 201 x 76 1 1 SWGG0035E NEMA 1/2 24.0 x 17.0 x 18.5 610 x 432 x 470 88 40 4 Preinstalled in cabinet SWGW0035E NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 95 43 5 30 40 45 SWGM0045E OPEN 8.7 x 10.5 x 8.7 221 x 267 x 221 53 24 8 251 7.9 x 3.0 201 x 76 1 1 SWGG0045E NEMA 1/2 24.0 x 17.0 x 18.5 610 x 432 x 470 101 46 4 Preinstalled in cabinet SWGW0045E NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 109 49 5 37 50 55 SWGM0055E OPEN 10.7 x 12.0 x 9.4 272 x 305 x 239 63 29 9 293 7.9 x 3.0 201 x 76 1 1 SWGG0055E NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 138 63 6 Preinstalled in cabinet SWGW0055E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 149 68 45 60 65 SWGM0065E OPEN 10.7 x 12.0 x 9.7 272 x 305 x 246 78 35 9 302 7.9 x 3.0 201 x 76 1 1 SWGG0065E NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 152 69 6 Preinstalled in cabinet SWGW0065E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 163 74 55 75 80 SWGM0080E OPEN 10.7 x 12.0 x 10.1 272 x 305 x 257 92 42 9 359 7.9 x 3.0 201 x 76 1 1 SWGG0080E NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 166 75 6 Preinstalled in cabinet SWGW0080E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 177 80 75 100 110 SWGM0110E OPEN 10.7 x 12.0 x 10.5 272 x 305 x 267 106 48 9 449 7.9 x 3.0 201 x 76 1 1 SWGG0110E NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 181 82 6 Preinstalled in cabinet SWGW0110E NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 191 87 90 125 130 SWGM0130E OPEN 14.4 x 15.3 x 11.2 366 x 389 x 284 161 73 9 647 7.9 x 3.0 201 x 76 1 1 SWGG0130E NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 332 151 6 Preinstalled in cabinet SWGW0130E NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 345 156 26
