Reactors Product Catalog

Reactors Product Catalog mtecorp.com

MTE RL and RLW line/load reactors and DC link chokes are well-known for their outstanding performance and robustness. With their long-established history of proven reliability, these products are unmatched in their ability to absorb power line disturbances that can cause damage to sensitive equipment such as Variable Frequency Drives (VFDs), motors, and more. By reducing nuisance tripping, minimizing long lead effects, and lowering harmonic distortion, MTE line/load reactors and DC link chokes can significantly enhance productivity, making them the best-in-class choice for customers. Improve power quality. Enhance productivity. Increase your bottom line. We set the benchmark for power quality.

Contents Reactors Why Use a Reactor? 2 Learn the benefits of using a reactor RL Reactor 4 Best-in-class power quality units for absorbing power line disturbances RLW Reactors 12 State-of-the-art solution for absorbing everyday power line disturbances DC Link Chokes 20 The cost-effective, versatile solution to solving power quality problems 1

MTE’s versatile family of reactors offer many benefits on both the line or load side of a VFD. With their impressive capability to reduce harmonic levels by almost 50%, these reactors serve as a reliable and cost-effective safeguard against power line disturbances, surge currents, and voltage distortions—an invaluable insurance policy for uninterrupted power quality and enhanced operational stability. Take Advantage of Our Expertise WHYUse A Reactor? 2

mtecorp.com RLW RL Concerned About Size 3 Concerned About Weight 3 Concerned About Watts Loss 3 Application FLA rating >750A 3 Reactor required on both line and load side 3 3 Reactor Needs To Be Robust (Handle Overload) 3 Need To Be Price Competitive 3 RLW or RL - Which reactor should I use? I I I I I I I I I Benefit 1: Equipment Protection Benefit 3: Voltage Stabilization Benefit 2: Harmonic Mitigation MTE line/load reactors offer equipment protection by limiting inrush currents, preventing damage from start-up or load changes, and reducing voltage transients, extending equipment life and minimizing downtime risk. MTE line/load reactors provide impedance to the system, smoothing out voltage spikes and sags, ensuring a stable voltage supply, and enhancing equipment reliability. MTE line/load reactors effectively reduce harmonic distortion in electrical systems, maintaining a cleaner power supply and protecting sensitive equipment. Benefit 4: Power Loss Reduction MTE line/load reactors minimize power losses by improving power factor and reducing reactive power flow, resulting in energy savings and potential cost reduction. 3

VFD Motor RL Reactor RL Reactor Utility Power Reactors RL Reactors Best-in-class power quality units for absorbing power line disturbances RLW Reactors State-of-the-art solution for absorbing everyday power line disturbances DC Link Chokes The cost-effective, versatile solution to solving power quality problems mtecorp.com 4

Peace of mind included. Our RL Line/Load Reactors are best-in-class power quality units with a long history of proven performance. Rugged and robust, they are unequaled in absorbing power line disturbances that can damage or shut down variable frequency drives (VFDs) and other sensitive equipment. They work on both the line side and load side to give you an easy solution that reduces nuisance tripping, reduces harmonic distortion and minimizes long lead effects. Improved power quality, enhanced productivity and complete peace of mind are easy with RL Line/ Load Reactors. Best-in-class line/load reactors Most robust, highest continuous service factor Low watts loss Performance and durability that is unmatched by the competition RL Reactors 5

Final product specifications subject to change at any time. Get best-in-class performance with our RL Line/Load Reactors. Our RL Line/Load Reactors are a robust, best-in-class filtering solution for virtually any 4 or 6-pulse rectifier or power conversion unit. There is no need to derate these reactors. They are harmonic compensated and protected to assure optimum performance in the presence of harmonics, and can help you meet IEEE-519 requirements. There are units available for a full line of currents (1A to 1,500A) and a full line of impedance options (1.5%, 3% and 5%). Robust design and construction for unequaled filtering of power line disturbances. Highest continuous service factor virtually eliminates breakdowns in the field. Reduces audible noise. Multiple cabinet designs help meet NEMA 1/2 and 3R. RL Reactors Waveform without reactor Waveform without reactor Waveform with reactor Waveform with reactor MTE Output Reactor MTE Input Reactor RL Reactors RL Reactors Utility Power Motor VFD Performance Specifications Impedance Levels 1.5%, 3% and 5% Continuous Service Factor Reactors rated 1 to 750 Amps – 150% of rating Reactors rated above 750 Amps – 125% of rating Overload Rating 200% of rated for 30 minutes 300% of rated for 1 minute Input Voltage Range 208V – 690V Current Range 1A – 1,500A Temperature Rise 135°C Ambient Temperature -40°C to 50°C Altitude Maximum Without Derating 1,000 meters Fundamental Frequency 50/60 Hz Inductance Curve 100% at 100% Current 100% at 150% Current 50% at 350% Current 0 3300 6600 9900 13200 16500 1.05 1.00 0.95 0.90 0.85 0.80 0.75 0.70 Current Derating Factor Altitude (feet) Altitude Derating Curve 6

mtecorp.com ENCLOSURES FIGURE 1 FIGURE 3 FIGURE 4 FIGURE 5 FIGURE 2 NOTE: HOODS ONLY ON NEMA 3R ENCLOSURES NOTE: HOODS ONLY ON NEMA 3R ENCLOSURES H H H W W W W D D D D D W H Note: Figure illustrations are for reference only. Actual hardware may differ. Please visit mtecorp.com for detailed information. H RL Reactors 7

RL REACTOR SELECTION TABLES Impedance Rating: 3% impedance reactors are typically sufficient to absorb power line spikes and motor current surges. They will prevent nuisance tripping of drives or circuit breakers in most applications. 5% impedance reactors are best for reducing harmonic currents and frequencies. Use them when you must reduce VFD drive generated harmonics, and to reduce motor operating temperature, or to reduce motor noise. *The effective impedance of the reactor changes with actual RMS current. A 5% impedance reactor becomes 3% if its current is reduced to 60%. Input Voltage & Hz % Impedance 0.25 HP 0.18 kW 0.33 HP 0.25 kW 0.5 HP 0.37 kW 0.75 HP 0.55 kW 1.0 HP 0.75 kW 1.5 HP 1.1 kW 2.0 HP 1.5 kW 3.0 HP 2.2 kW 5.0 HP 3.7 kW 7.5 HP 5.5 kW 10.0 HP 7.5 kW 15.0 HP 11.0 kW 20.0 HP 15.0 kW 25.0 HP 18.5 kW 30.0 HP 22.0 kW Three Phase Input or Output Applications Selected by Motor 208V 60 Hz 3% RL-00204 RL-00204 RL-00401 RL-00401 RL-00801 RL-00801 RL-00801 RL-01801 RL-02501 RL-03501 RL-05501 RL-05501 RL-08001 RL-10001 RL-10001 208V 60 Hz 5% RL-00201 RL-00403 RL-00402 RL-00803 RL-00802 RL-00802 RL-01202 RL-01802 RL-02502 RL-03502 RL-05502 RL-04501 RL-05501 RL-08001 RL-13002 240V 60 Hz 3% RL-00204 RL-00204 RL-00402 RL-00401 RL-00802 RL-00801 RL-00801 RL-01201 RL-01801 RL-02501 RL-03501 RL-04501 RL-05501 RL-08001 RL-10001 240V 60 Hz 5% RL-00201 RL-00201 RL-00403 RL-00402 RL-00803 RL-00802 RL-00802 RL-01202 RL-02502 RL-03502 RL-03502 RL-05502 RL-08002 RL-10001 RL-08001 400V 50 Hz 3% RL-00103 RL-00103 RL-00202 RL-00201 RL-00403 RL-00402 RL-00402 RL-00803 RL-00802 RL-01202 RL-01802 RL-02502 RL-03502 RL-04502 RL-04502 400V 50 Hz 5% RL-00102 RL-00102 RL-00203 RL-00202 RL-00202 RL-00404 RL-00403 RL-00804 RL-00803 RL-01203 RL-01803 RL-02503 RL-03503 RL-04503 RL-05503 480V 60 Hz 3% RL-00103 RL-00103 RL-00104 RL-00201 RL-00201 RL-00402 RL-00402 RL-00803 RL-00802 RL-01202 RL-01802 RL-02502 RL-03502 RL-03502 RL-04502 480V 60 Hz 5% RL-00102 RL-00102 RL-00103 RL-00202 RL-00202 RL-00404 RL-00403 RL-00804 RL-00803 RL-01203 RL-01803 RL-02503 RL-03503 RL-03503 RL-05503 600V 60 Hz 3% RL-00102 RL-00103 RL-00103 RL-00202 RL-00202 RL-00201 RL-00403 RL-00402 RL-00803 RL-01202 RL-01202 RL-01802 RL-02502 RL-02502 RL-03502 600V 60 Hz 5% RL-00101 RL-00102 RL-00102 RL-00203 RL-00203 RL-00202 RL-00404 RL-00404 RL-00804 RL-01203 RL-01203 RL-01803 RL-02503 RL-02503 RL-03503 690V 50 Hz 2% - - - - - - - RL-00403 RL-00803 RL-00803 RL-01202 RL-01202 RL-01802 RL-02502 RL-02502 690V 50 Hz 3% - - - - - - - RL-00404 RL-00804 RL-00804 RL-01203 RL-01203 RL-01803 RL-02503 RL-02503 Single Phase Input Applications 120V 60 Hz 5% RL-01801 RL-01801 RL-01201 RL-01801 RL-01801 RL-02501 RL-03501 RL-05501 RL-10001 RL-16001 RL20001B14 - - - - 208V 60 Hz 5% RL-00204 RL-00803 RL-00802 RL-01202 RL-00801 RL-01201 RL-01201 RL-01801 RL-03501 RL-04501 RL-05501 RL-08001 RL-10001 RL-13001 RL-16001 240V 60 Hz 5% RL-00402 RL-00402 RL-00803 RL-00802 RL-01202 RL-01201 RL-01201 RL-01801 RL-02501 RL-04501 RL-04501 RL-08001 RL-10001 RL-13001 RL-16002 240V 50 Hz 5% RL-00403 RL-00402 RL-00803 RL-00802 RL-00802 RL-01802 RL-01802 RL-02502 RL-03502 RL-03501 RL-05502 RL-10002 RL-13002 RL-13002 RL-16002 400V 50 Hz 5% RL-00103 RL-00203 RL-00201 RL-00404 RL-00403 RL-00803 RL-00803 RL-01203 RL-01803 RL-02503 RL-03503 RL-04502 RL-05502 RL-08002 RL-08002 480V 60 Hz 5% RL-00203 RL-00202 RL-00202 RL-00404 RL-00403 RL-00803 RL-00803 RL-01203 RL-01803 RL-02503 RL-02502 RL-04502 RL-05503 RL-08003 RL-08002 600V 60 Hz 5% RL-00102 RL-00103 RL-00202 RL-00202 RL-00404 RL-00403 RL-00804 RL-00803 RL-01203 RL-01803 RL-02503 RL-03503 RL-04503 RL-05503 RL-05503 Note: The recommended reactor selections above are based on fundamental current ratings. Contact appengrg@mtecorp.com with any questions regarding the proper reactor selection. 8

mtecorp.com 40.0 HP 30.0 kW 50.0 HP 37.5 kW 60.0 HP 45.0 kW 75.0 HP 55.0 kW 100.0 HP 75.0 kW 125.0 HP 93.0 kW 150.0 HP 112.0 kW 200.0 HP 150.0 kW 250.0 HP 187.0 kW 300.0 HP 225.0 kW 350.0 HP 262.0 kW 400.0 HP 300.0 kW 500.0 HP 375.0 kW 600.0 HP 450.0 kW 700.0 HP 550.0 kW 800.0 HP 600.0 kW Three Phase Input or Output Applications Selected by Motor RL-13001 RL-16001 RL20001B14 RL25001B14 RL32001B14 RL40001B14 RL50001B14 RL-60001 RL-75001 RL85001B14 RL100001B14 RL120001B14 RL-140001 - - - RL-16002 RL20002B14 RL20002B14 RL25002B14 RL32002B14 RL40002B14 RL-50002 RL-75002 RL-75002 RL90002B14 RL100002B14 RL120002B14 RL-150002 - - - RL-13001 RL-13001 RL-16001 RL20001B14 RL25001B14 RL32001B14 RL40001B14 RL50001B14 RL-60001 RL-75001 RL85001B14 RL100001B14 RL120001B14 - - - RL-13002 RL-16002 RL-16002 RL20002B14 RL25002B14 RL40002B14 RL40002B14 RL-60002 RL-75002 RL-75002 RL85002B14 RL100002B14 RL-140002 - - - RL-08002 RL-08002 RL-10002 RL-13002 RL-16002 RL20002B14 RL20002B14 RL32002B14 RL40002B14 RL40002B14 RL-50002 RL-60002 RL-75002 RL85002B14 RL90002B14 RL120002B14 RL-08003 RL-10003 RL-10003 RL-13003 RL-16003 RL20003B14 RL20003B14 RL32003B14 RL40003B14 RL40003B14 RL-50003 RL-60003 RL-75003 RL85003B14 RL90003B14 RL120003B14 RL-05502 RL-08002 RL-10002 RL-10002 RL-13002 RL-16002 RL20002B14 RL25002B14 RL32002B14 RL40002B14 RL-50002 RL-50002 RL-60002 RL-75002 RL85002B14 RL100002B14 RL-05503 RL-08003 RL-10003 RL-10003 RL-13003 RL-16003 RL20003B14 RL25003B14 RL32003B14 RL40003B14 RL-50003 RL-50003 RL-60003 RL-75003 RL85003B14 RL100003B14 RL-04502 RL-05502 RL-08002 RL-08002 RL-10002 RL-13002 RL-16002 RL20002B14 RL25002B14 RL32002B14 RL32002B14 RL40002B14 RL-50002 RL-60002 RL-75002 RL-75002 RL-04503 RL-05503 RL-08003 RL-08003 RL-10003 RL-13003 RL-16003 RL20003B14 RL25003B14 RL32003B14 RL32003B14 RL40003B14 RL-50003 RL-60003 RL-75003 RL-75003 RL-03502 RL-04502 RL-05502 RL-05502 RL-08002 RL-10002 RL-13002 RL-16002 RL20002B14 RL25002B14 RL25002B14 RL32002B14 RL40002B14 RL40002B14 RL-50002 RL-60002 RL-03503 RL-04503 RL-04502 RL-05503 RL-08003 RL-10003 RL-13003 RL-16003 RL20003B14 RL25003B14 RL25003B14 RL32003B14 RL40003B14 RL-50003 RL-50003 RL-60003 Single Phase Input Applications - - - - - - - - - - - - - - - - RL20001B14 RL25001B14 RL32001B14 RL40001B14 RL50001B14 - - - - - - - - - - - RL20002B14 RL25002B14 RL32002B14 RL32001B14 RL40001B14 - - - - - - - - - - - RL20002B14 RL25002B14 RL32002B14 RL40002B14 RL-50002 - - - - - - - - - - - RL-10002 RL-13003 RL-16003 RL20003B14 RL25003B14 - - - - - - - - - - - RL-10002 RL-13003 RL-16003 RL20003B14 RL25003B14 RL32003B14 RL40003B14 RL40003B14 - - - - - - - - RL-08003 RL-10003 RL-13003 RL-13003 RL20003B14 RL25003B14 RL25003B14 RL32003B14 - - - - - - - - Note: The recommended reactor selections above are based on fundamental current ratings. Contact appengrg@mtecorp.com with any questions regarding the proper reactor selection. RL Reactors 9

Open Open Part Number Amps Rating Inductance mh Watts Loss Open Weight (lbs) Size (in) (H x W x D) RL-00101 1 100 14.1 4 4.0 x 4.2 x 3.0 RL-00102 1 50 14.8 4 4.1 x 4.4 x 2.8 RL-00103 1 36 12.0 3 4.1 x 4.4 x 2.8 RL-00104 1 18 8.0 3 4.1 x 4.4 x 2.8 RL-00201 2 12 7.5 4 4.0 x 4.2 x 2.6 RL-00202 2 20 11.3 4 4.0 x 4.2 x 2.6 RL-00203 2 32 16 4 4.0 x 4.2 x 2.6 RL-00204 2 6 10.7 3 4.0 x 4.2 x 2.6 RL-00401 4 3 14.5 4 4.0 x 4.2 x 2.6 RL-00402 4 6.5 20 4 4.0 x 4.2 x 2.6 RL-00403 4 9 20 5 4.0 x 4.2 x 3.0 RL-00404 4 12 21 6 4.0 x 4.2 x 3.3 RL-00801 8 1.5 19.5 7 4.6 x 5.9 x 2.9 RL-00802 8 3 29 8 4.6 x 5.9 x 2.9 RL-00803 8 5 25.3 11 4.7 x 5.9 x 3.3 RL-00804 8 7.5 28 13 4.7 x 5.9 x 3.3 RL-01201 12 1.25 26 9 5.0 x 5.9 x 3.2 RL-01202 12 2.5 31 10 5.0 x 5.9 x 3.2 RL-01203 12 4.2 41 18 5.0 x 5.9 x 3.8 RL-01801 18 0.8 36 9 5.1 x 5.9 x 3.2 RL-01802 18 1.5 43 12 5.1 x 5.9 x 3.5 RL-01803 18 2.5 43 16 5.7 x 7.1 x 3.7 RL-02501 25 0.5 48 11 5.7 x 7.1 x 3.4 RL-02502 25 1.2 52 14 5.8 x 7.1 x 3.4 RL-02503 25 1.8 61 20 5.8 x 7.1 x 4.2 RL-03501 35 0.4 49 14 5.7 x 7.1 x 3.7 RL-03502 35 0.8 54 16 5.8 x 7.1 x 3.7 RL-03503 35 1.2 54 26 7.2 x 8.9 x 4.6 RL-04501 45 0.3 54 22 7.1 x 8.9 x 4.6 RL-04502 45 0.7 62 26 7.2 x 8.9 x 4.6 RL-04503 45 1.2 65 34 7.3 x 8.9 x 5.1 RL-05501 55 0.25 64 24 6.9 x 9.0 x 5.3 RL-05502 55 0.5 67 26 6.9 x 9.0 x 5.3 RL-05503 55 0.85 71 34 6.9 x 8.9 x 6.3 RL-08001 80 0.2 82 25 6.9 x 8.9 x 5.7 RL-08002 80 0.4 86 33 7.1 x 8.9 x 5.7 RL-08003 80 0.7 96 63 8.5 x 10.8 x 6.6 RL-10001 100 0.15 94 29 7.0 x 8.9 x 6.0 RL-10002 100 0.3 84 37 7.0 x 8.9 x 6.6 RL-10003 100 0.45 108 67 8.4 x 10.8 x 7.8 RL-13001 130 0.1 108 29 7.3 x 9.6 x 5.9 RL-13002 130 0.2 180 43 7.2 x 9.6 x 6.0 RL-13003 130 0.3 128 64 8.5 x 10.8 x 7.3 Open Open Part Number Amps Rating Inductance mh Watts Loss Open Weight (lbs) Size (in) (H x W x D) RL-16001 160 0.075 116 41 7.2 x 9.6 x 6.0 RL-16002 160 0.15 149 54 8.4 x 10.8 x 6.7 RL-16003 160 0.23 138 74 8.5 x 10.8 x 7.4 RL-20001B14 200 0.055 124 38 7.2 x 9.6 x 7.1 RL-20002B14 200 0.11 168 54 7.2 x 9.6 x 7.9 RL-20003B14 200 0.185 146 100 8.3 x 10.8 x 9.1 RL-25001B14 250 0.045 154 47 7.0 x 9.6 x 8.1 RL-25002B14 250 0.09 231 80 8.5 x 10.8 x 7.6 RL-25003B14 250 0.15 588 125 11.2 x 14.3 x 8.7 RL-32001B14 320 0.04 224 80 8.4 x 10.8 x 7.9 RL-32002B14 320 0.075 264 102 8.4 x 10.8 x 8.9 RL-32003B14 320 0.125 642 160 11.1 x 14.3 x 9.4 RL-40001B14 400 0.03 213 84 8.4 x 11.0 x 8.6 RL-40002B14 400 0.06 571 118 11.1 x 14.3 x 9.4 RL-40003B14 400 0.105 293 149 11.1 x 14.3 x 10.9 RL-50001B14 500 0.025 226 93 8.5 x 10.8 x 9.4 RL-50002 500 0.05 694 160 11.1 x 14.3 x 10.6 RL-50003 500 0.085 985 210 11.1 x 14.3 x 13.0 RL-60001 600 0.02 609 120 11.1 x 14.3 x 8.8 RL-60002 600 0.04 689 175 11.1 x 14.3 x 11.0 RL-60003 600 0.065 406 270 11.1 x 14.3 x 13.5 RL-75001 750 0.015 713 140 11.2 x 14.3 x 10.4 RL-75002 750 0.029 630 190 11.1 x 14.3 x 11.5 RL-75003 750 0.048 552 265 14.1 x 14.0 x 13.0 RL-85001B14 850 0.015 798 195 15.5 x 17.8 x 14.8 RL-85002B14 850 0.027 930 215 15.5 x 17.8 x 15.5 RL-85003B14 850 0.042 1133 315 15.8 x 17.8 x 17.5 RL-90001B14 900 0.013 655 195 14.4 x 16.2 x 13.8 RL-90002B14 900 0.025 1020 215 14.6 x 17.0 x 14.7 RL-90003B14 900 0.04 1365 315 15.8 x 17.8 x 17.1 RL-100001B14 1000 0.011 810 144 14.4 x 17.0 x 12.5 RL-100002B14 1000 0.022 1080 215 14.6 x 17.0 x 14.7 RL-100003B14 1000 0.038 1250 315 14.6 x 17.0 x 17.2 RL-120001B14 1200 0.009 870 195 14.7 x 17.0 x 13.8 RL-120002B14 1200 0.019 1270 275 14.9 x 17.0 x 16.2 RL-120003B14 1200 0.03 1530 390 14.7 x 17.0 x 17.7 RL-140001 1400 0.008 1235 500 16.6 x 21.0 x 15.2 RL-140002 1400 0.016 1523 525 16.6 x 21.0 x 17.1 RL-140003 1400 0.027 1680 850 16.8 x 21.0 x 22.0 RL-150001 1500 0.008 1432 635 17.1 x 24.0 x 13.7 RL-150002 1500 0.015 1100 460 16.8 x 18.0 x 15.5 RL-150003 1500 0.025 2621 760 16.6 x 21.0 x 19.9 RL REACTOR SELECTION TABLES Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. 10

mtecorp.com NEMA 1/2 Part Number Weight (lbs) Cabinet Size (in) (H x W x D) Ref Figure RL-00111 9 CAB-8 8.0 x 8.2 x 6.3 1 RL-00112 9 CAB-8 8.0 x 8.2 x 6.3 1 RL-00113 8 CAB-8 8.0 x 8.2 x 6.3 1 RL-00114 8 CAB-8 8.0 x 8.2 x 6.3 1 RL-00211 9 CAB-8 8.0 x 8.2 x 6.3 1 RL-00212 9 CAB-8 8.0 x 8.2 x 6.3 1 RL-00213 9 CAB-8 8.0 x 8.2 x 6.3 1 RL-00214 8 CAB-8 8.0 x 8.2 x 6.3 1 RL-00411 9 CAB-8 8.0 x 8.2 x 6.3 1 RL-00412 9 CAB-8 8.0 x 8.2 x 6.3 1 RL-00413 10 CAB-8 8.0 x 8.2 x 6.3 1 RL-00414 11 CAB-8 8.0 x 8.2 x 6.3 1 RL-00811 12 CAB-8 8.0 x 8.2 x 6.3 1 RL-00812 13 CAB-8 8.0 x 8.2 x 6.3 1 RL-00813 16 CAB-8 8.0 x 8.2 x 6.3 1 RL-00814 18 CAB-8 8.0 x 8.2 x 6.3 1 RL-01211 14 CAB-8 8.0 x 8.2 x 6.3 1 RL-01212 15 CAB-8 8.0 x 8.2 x 6.3 1 RL-01213 23 CAB-8 8.0 x 8.2 x 6.3 1 RL-01811 14 CAB-8 8.0 x 8.2 x 6.3 1 RL-01812 17 CAB-8 8.0 x 8.2 x 6.3 1 RL-01813 30 CAB-13V 13.2 x 13.2 x 13.1 4 RL-02511 25 CAB-13V 13.2 x 13.2 x 13.1 4 RL-02512 28 CAB-13V 13.2 x 13.2 x 13.1 4 RL-02513 34 CAB-13V 13.2 x 13.2 x 13.1 4 RL-03511 28 CAB-13V 13.2 x 13.2 x 13.1 4 RL-03512 30 CAB-13V 13.2 x 13.2 x 13.1 4 RL-03513 40 CAB-13V 13.2 x 13.2 x 13.1 4 RL-04511 36 CAB-13V 13.2 x 13.2 x 13.1 4 RL-04512 40 CAB-13V 13.2 x 13.2 x 13.1 4 RL-04513 48 CAB-13V 13.2 x 13.2 x 13.1 4 RL-05511 38 CAB-13V 13.2 x 13.2 x 13.1 4 RL-05512 40 CAB-13V 13.2 x 13.2 x 13.1 4 RL-05513 48 CAB-13V 13.2 x 13.2 x 13.1 4 RL-08011 39 CAB-13V 13.2 x 13.2 x 13.1 4 RL-08012 47 CAB-13V 13.2 x 13.2 x 13.1 4 RL-08013 77 CAB-13V 13.2 x 13.2 x 13.1 4 RL-10011 43 CAB-13V 13.2 x 13.2 x 13.1 4 RL-10012 51 CAB-13V 13.2 x 13.2 x 13.1 4 RL-10013 81 CAB-13V 13.2 x 13.2 x 13.1 4 RL-13011 43 CAB-13V 13.2 x 13.2 x 13.1 4 RL-13012 57 CAB-13V 13.2 x 13.2 x 13.1 4 RL-13013 78 CAB-13V 13.2 x 13.2 x 13.1 4 RL-16011 55 CAB-13V 13.2 x 13.2 x 13.1 4 RL-16012 68 CAB-13V 13.2 x 13.2 x 13.1 4 RL-16013 88 CAB-13V 13.2 x 13.2 x 13.1 4 RL-20011B14 52 CAB-13V 13.2 x 13.2 x 13.1 4 RL-20012B14 68 CAB-13V 13.2 x 13.2 x 13.1 4 RL-20013B14 114 CAB-13V 13.2 x 13.2 x 13.1 4 RL-25011B14 61 CAB-13V 13.2 x 13.2 x 13.1 4 RL-25012B14 123 CAB-17V 24.0 x 17.1 x 18.5 5 RL-25013B14 168 CAB-17V 24.0 x 17.1 x 18.5 5 RL-32011B14 123 CAB-17V 24.0 x 17.1 x 18.5 5 RL-32012B14 145 CAB-17V 24.0 x 17.1 x 18.5 5 RL-32013B14 203 CAB-17V 24.0 x 17.1 x 18.5 5 RL-40011B14 127 CAB-17V 24.0 x 17.1 x 18.5 5 RL-40012B14 161 CAB-17V 24.0 x 17.1 x 18.5 5 RL-40013B14 192 CAB-17V 24.0 x 17.1 x 18.5 5 RL-50011B14 136 CAB-17V 24.0 x 17.1 x 18.5 5 RL-50012 297 CAB-26C2 47.0 x 26.6 x 24.9 3 RL-50013 347 CAB-26C2 47.0 x 26.6 x 24.9 3 RL-60011 257 CAB-26C2 47.0 x 26.6 x 24.9 3 RL-60012 312 CAB-26C2 47.0 x 26.6 x 24.9 3 RL-60013 407 CAB-26C2 47.0 x 26.6 x 24.9 3 RL-75011 277 CAB-26C2 47.0 x 26.6 x 24.9 3 RL-75012 327 CAB-26C2 47.0 x 26.6 x 24.9 3 RL-75013 402 CAB-26C2 47.0 x 26.6 x 24.9 3 RL-85011B14 332 CAB-26C2 47.0 x 26.6 x 24.9 3 RL-85012B14 352 CAB-26C2 47.0 x 26.6 x 24.9 3 RL-85013B14 481 CAB-26D2 72.0 x 26.6 x 24.9 3 RL-90011B14 361 CAB-26D2 72.0 x 26.6 x 24.9 3 RL-90012B14 381 CAB-26D2 72.0 x 26.6 x 24.9 3 RL-90013B14 481 CAB-26D2 72.0 x 26.6 x 24.9 3 RL-100011B14 310 CAB-26D2 72.0 x 26.6 x 24.9 3 RL-100012B14 381 CAB-26D2 72.0 x 26.6 x 24.9 3 RL-100013B14 481 CAB-26D2 72.0 x 26.6 x 24.9 3 RL-120011B14 361 CAB-26D2 72.0 x 26.6 x 24.9 3 RL-120012B14 441 CAB-26D2 72.0 x 26.6 x 24.9 3 RL-120013B14 556 CAB-26D2 72.0 x 26.6 x 24.9 3 RL-140011 815 CAB-42C2 72.0 x 42.6 x 30.9 3 RL-140012 840 CAB-42C2 72.0 x 42.6 x 30.9 3 RL-140013 1165 CAB-42C2 72.0 x 42.6 x 30.9 3 RL-150011 950 CAB-42C2 72.0 x 42.6 x 30.9 3 RL-150012 775 CAB-42C2 72.0 x 42.6 x 30.9 3 RL-150013 1075 CAB-42C2 72.0 x 42.6 x 30.9 3 NEMA 3R Part Number Weight (lbs) Cabinet Size (in) (H x W x D) Ref Figure RL-00131 61 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-00132 61 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-00133 60 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-00134 60 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-00231 61 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-00232 61 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-00233 61 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-00234 60 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-00431 61 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-00432 61 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-00433 62 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-00434 63 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-00831 64 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-00832 65 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-00833 68 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-00834 70 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-01231 66 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-01232 67 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-01233 75 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-01831 66 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-01832 69 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-01833 73 CAB-12C3 24.0 x 12.5 x 17.9 2 RL-02531 99 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-02532 102 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-02533 108 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-03531 102 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-03532 104 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-03533 114 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-04531 110 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-04532 114 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-04533 122 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-05531 112 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-05532 114 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-05533 122 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-08031 113 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-08032 121 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-08033 151 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-10031 117 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-10032 125 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-10033 155 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-13031 117 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-13032 131 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-13033 152 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-16031 129 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-16032 142 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-16033 162 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-20031B14 126 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-20032B14 142 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-20033B14 188 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-25031B14 135 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-25032B14 168 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-25033B14 213 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-32031B14 168 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-32032B14 190 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-32033B14 248 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-40031B14 172 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-40032B14 206 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-40033B14 237 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-50031B14 181 CAB-17C3 31.0 x 17.6 x 26.0 2 RL-50032 319 CAB-26C3 47.0 x 26.6 x 30.0 3 RL-50033 369 CAB-26C3 47.0 x 26.6 x 30.0 3 RL-60031 279 CAB-26C3 47.0 x 26.6 x 30.0 3 RL-60032 334 CAB-26C3 47.0 x 26.6 x 30.0 3 RL-60033 429 CAB-26C3 47.0 x 26.6 x 30.0 3 RL-75031 299 CAB-26C3 47.0 x 26.6 x 30.0 3 RL-75032 349 CAB-26C3 47.0 x 26.6 x 30.0 3 RL-75033 424 CAB-26C3 47.0 x 26.6 x 30.0 3 RL-85031B14 354 CAB-26C3 47.0 x 26.6 x 30.0 3 RL-85032B14 374 CAB-26C3 47.0 x 26.6 x 30.0 3 RL-85033B14 494 CAB-26D3 72.0 x 26.6 x 34.0 3 RL-90031B14 374 CAB-26D3 72.0 x 26.6 x 34.0 3 RL-90032B14 394 CAB-26D3 72.0 x 26.6 x 34.0 3 RL-90033B14 494 CAB-26D3 72.0 x 26.6 x 34.0 3 RL-100031B14 323 CAB-26D3 72.0 x 26.6 x 34.0 3 RL-100032B14 394 CAB-26D3 72.0 x 26.6 x 34.0 3 RL-100033B14 494 CAB-26D3 72.0 x 26.6 x 34.0 3 RL-120031B14 374 CAB-26D3 72.0 x 26.6 x 34.0 3 RL-120032B14 454 CAB-26D3 72.0 x 26.6 x 34.0 3 RL-120033B14 569 CAB-26D3 72.0 x 26.6 x 34.0 3 RL-140031 859 CAB-42C3 72.0 x 42.6 x 40.0 3 RL-140032 884 CAB-42C3 72.0 x 42.6 x 40.0 3 RL-140033 1209 CAB-42C3 72.0 x 42.6 x 40.0 3 RL-150031 994 CAB-42C3 72.0 x 42.6 x 40.0 3 RL-150032 819 CAB-42C3 72.0 x 42.6 x 40.0 3 RL-150033 1119 CAB-42C3 72.0 x 42.6 x 40.0 3 RL Reactors 11

Reactors RL Reactors Best-in-class power quality units for absorbing power line disturbances RLW Reactors State-of-the-art solution for absorbing everyday power line disturbances DC Link Chokes The cost-effective, versatile solution to solving power quality problems mtecorp.com VFD Motor RLW Reactor RLW Reactor Utility Power 12

Smaller. Lighter. Our RLW Line/Load Reactors are a state-of-the-art solution for absorbing everyday power line disturbances that can damage or shut down variable frequency drives (VFDs) and other sensitive equipment. They work on both the line side and load side to give you an economical way to reduce nuisance tripping, reduce harmonic distortion and minimize long lead effects. Their epoxy impregnated design also reduces audible noise, and improves structural and moisture integrity. Put an end to power spike issues and minimize downtime with our RLW Line/Load Reactors from MTE. Proven performance in the field Reliable and economical Compact and light-weight Ideal for OEMs, integrators and panel builders RLW Reactors 13

Stop nuisance tripping and harmonic distortion with our RLW Reactors. RLW Reactors Performance Specifications Impedance Levels 1.5%, 3% and 5% Continuous Service Factor 100% Overload Rating - Line Side 150% of RMS rating for 1 minute 200% of RMS rating for 10 seconds Input Voltage Range 208V – 690V Current Range 0.5A – 750A Temperature Rise 140°C Ambient Temperature -40°C to 50°C Altitude Maximum Without Derating 1,000 meters Fundamental Frequency 50/60 Hz Inductance Curve 100% at 100% Current 80% at 150% Current 50% at 200% Current Final product specifications subject to change at any time. RLW Reactors RLW Reactors Our RLW Reactors are the state-of-the art filtering solution for virtually any 4 or 6-pulse rectifier or power conversion unit. There are units available for amperage ratings from 0.5A to 750A. Our 3% impedance option is 90% effective and our 5% option extends spike protection to 99%. Smaller size and weight makes these units ideal for OEMs, integrators and panel builders. Wider range of impedance values for accurate and cost-effective selection. DIN Rail mounting options for easy panel installation. UL/cUL listed and CE marked for all your installation requirements. Waveform without reactor Waveform without reactor Waveform with reactor Waveform with reactor MTE Output Reactor MTE Input Reactor Utility Power Motor VFD 0 3300 6600 9900 13200 16500 1.05 1.00 0.95 0.90 0.85 0.80 0.75 0.70 Current Derating Factor Altitude (feet) Altitude Derating Curve 50 100 150 200 250 0 10 20 30 40 50 60 70 80 90 100 % Nominal Inductance % Rated Current RLW Inductance Curve 14

mtecorp.com ENCLOSURES FIGURE 1 FIGURE 2 FIGURE 3 FIGURE 4 NOTE: HOODS ONLY ON NEMA 3R ENCLOSURES H H W W W D D D D W H Note: Figure illustrations are for reference only. Actual hardware may differ. Please visit mtecorp.com for detailed information. H RLW Reactors 15

RLW REACTOR SELECTION TABLES Phase Input Voltage & Hz % Impedance 0.25 HP 0.18 kW 0.33 HP 0.25 kW 0.5 HP 0.37 kW 0.75 HP 0.55 kW 1.0 HP 0.75 kW 1.5 HP 1.1 kW 2.0 HP 1.5 kW 3.0 HP 2.2 kW 5.0 HP 3.7 kW 7.5 HP 5.5 kW 10.0 HP 7.5 kW 15.0 HP 11.0 kW 20.0 HP 15.0 kW 25.0 HP 18.5 kW Three Phase Input Applications Selected by Motor 3 Phase 208V 60 Hz 3% RLW01P601 RLW02P101 RLW03P401 RLW04P801 RLW04P801 RLW07P601 RLW07P601 RLW001101 RLW002101 RLW002801 RLW003501 RLW005501 RLW006501 RLW008301 3 Phase 208V 60 Hz 5% RLW01P603 RLW02P103 RLW03P403 RLW04P803 RLW07P603 RLW07P603 RLW001103 RLW001403 RLW002103 RLW002803 RLW004603 RLW006503 RLW008303 RLW010403 3 Phase 240V 60 Hz 3% RLW01P601 RLW02P101 RLW03P401 RLW03P401 RLW04P801 RLW07P601 RLW07P601 RLW001101 RLW002101 RLW002801 RLW002801 RLW004601 RLW005501 RLW008301 3 Phase 240V 60 Hz 5% RLW01P603 RLW02P103 RLW03P403 RLW03P403 RLW04P803 RLW07P603 RLW07P603 RLW001103 RLW002103 RLW002803 RLW003503 RLW004603 RLW006503 RLW008303 3 Phase 400V 50 Hz 3% RLW0P7505 RLW0P7503 RLW01P605 RLW02P103 RLW03P405 RLW03P403 RLW04P803 RLW07P605 RLW001105 RLW001405 RLW002105 RLW002805 RLW003503 RLW003503 3 Phase 400V 50 Hz 5% RLW0P7506 RLW0P7505 RLW01P606 RLW02P106 RLW03P406 RLW03P405 RLW04P806 RLW07P606 RLW001106 RLW001406 RLW002106 RLW002806 RLW003505 RLW003505 3 Phase 480V 60 Hz 3% RLW0P7503 RLW01P105 RLW01P103 RLW01P603 RLW02P103 RLW03P403 RLW03P403 RLW04P803 RLW07P603 RLW001103 RLW001403 RLW002103 RLW002803 RLW003503 3 Phase 480V 60 Hz 5% RLW0P7506 RLW01P106 RLW01P105 RLW01P605 RLW02P105 RLW03P405 RLW03P405 RLW04P805 RLW07P605 RLW001105 RLW001405 RLW002105 RLW002805 RLW003505 3 Phase 600V 60 Hz 3% RLW00P505 RLW0P7505 RLW01P105 RLW01P605 RLW02P105 RLW03P405 RLW03P405 RLW04P805 RLW07P605 RLW001105 RLW001103 RLW002105 RLW002805 RLW002803 3 Phase 600V 60 Hz 5% RLW00P506 RLW0P7506 RLW01P106 RLW01P606 RLW02P106 RLW03P406 RLW03P406 RLW04P806 RLW07P606 RLW001106 RLW001106 RLW002106 RLW002806 RLW002806 3 Phase 690V 50 Hz 2% - - - - - - - RLW03P403 RLW04P803 RLW07P603 RLW001105 RLW001403 RLW002105 RLW002103 3 Phase 690V 50 Hz 3% - - - - - - - RLW03P406 RLW04P805 RLW07P606 RLW001106 RLW001405 RLW002106 RLW002105 Single Phase Input Applications 1 Phase 400V 50 Hz 5% RLW01P105 RLW01P606 RLW02P105 RLW03P405 RLW04P805 RLW07P606 RLW07P605 RLW001106 RLW001405 RLW002105 RLW002805 RLW004605 RLW005505 RLW006505 1 Phase 480V 60 Hz 5% RLW01P606 RLW01P605 RLW02P105 RLW03P405 RLW04P806 RLW07P606 RLW07P606 RLW001106 RLW001405 RLW002105 RLW002805 RLW004605 RLW005505 RLW006505 1 Phase 600V 60 Hz 5% RLW01P106 RLW01P105 RLW01P605 RLW03P406 RLW03P406 RLW04P806 RLW04P805 RLW07P606 RLW001106 RLW002106 RLW002106 RLW003505 RLW004605 RLW005505 Three Phase Output Selected by Motor 3 Phase 480V 60 Hz 1.5% RLW01P101 RLW01P101 RLW01P601 RLW02P101 RLW03P403 RLW04P803 RLW04P801 RLW07P601 RLW001101 RLW001401 RLW002101 RLW002801 RLW003501 RLW004601 3 Phase 600V 60 Hz 1.5% RLW0P7503 RLW01P103 RLW01P603 RLW02P103 RLW02P101 RLW03P403 RLW03P403 RLW07P603 RLW001103 RLW001403 RLW001403 RLW002803 RLW002803 RLW003501 3 Phase 690V 50 Hz 1.5% - - - - - - - RLW04P805 RLW07P605 RLW001105 RLW001103 RLW002105 RLW002103 RLW002803 Impedance Rating: 1.5% impedance reactors are the recommended maximum impedance for load side reactor applications. 3% impedance reactors are typically sufficient to absorb power line spikes and motor current surges. They will prevent nuisance tripping of drives or circuit breakers in most applications. 5% impedance reactors are best for reducing harmonic currents and frequencies. Use them when you must reduce VFD drive generated harmonics, and to reduce motor operating temperature, or to reduce motor noise. *The effective impedance of the reactor changes with actual RMS current. A 5% impedance reactor becomes 3% if its current is reduced to 60%. Note: The recommended reactor selections above are based on fundamental current ratings. Contact appengrg@mtecorp.com with any questions regarding the proper reactor selection. 16

mtecorp.com 30.0 HP 22.0 kW 40.0 HP 30.0 kW 50.0 HP 37.5 kW 60.0 HP 45.0 kW 75.0 HP 55.0 kW 100.0 HP 75.0 kW 125.0 HP 93.0 kW 150.0 HP 112.0 kW 200.0 HP 150.0 kW 250.0 HP 187.0 kW 300.0 HP 225.0 kW 350.0 HP 262.0 kW 400.0 HP 300.0 kW 500.0 HP 375.0 kW 600.0 HP 450.0 kW 700.0 HP 550.0 kW 800.0 HP 600.0 kW Three Phase Input Applications Selected by Motor RLW010401 RLW013001 RLW016001 RLW020001 RLW025001 RLW032201 RLW041401 RLW051501 RLW060001 RLW075001 - - - - - - - RLW010403 RLW013003 RLW020003 RLW020003 RLW025003 RLW032203 RLW051503 RLW041401 RLW075003 RLW075001 - - - - - - - RLW008301 RLW010401 RLW013001 RLW016001 RLW020001 RLW025001 RLW032201 RLW041401 RLW051501 RLW060001 RLW075001 - - - - - - RLW010403 RLW013003 RLW016003 RLW020003 RLW020003 RLW032203 RLW032203 RLW041403 RLW060003 RLW075003 RLW075003 - - - - - - RLW004603 RLW006503 RLW008303 RLW008303 RLW010403 RLW016003 RLW020003 RLW020003 RLW032203 RLW041403 RLW041403 RLW051503 RLW051503 RLW075003 - - - RLW004605 RLW006505 RLW008305 RLW008305 RLW010405 RLW016005 RLW020005 RLW020005 RLW032205 RLW041405 RLW041405 RLW051505 RLW060005 RLW075005 - - - RLW004603 RLW005503 RLW006503 RLW008303 RLW010403 RLW013003 RLW016003 RLW020003 RLW025003 RLW032203 RLW041403 RLW051503 RLW051503 RLW075003 RLW075003 - - RLW004605 RLW005505 RLW006505 RLW008305 RLW010405 RLW013005 RLW016005 RLW020005 RLW025005 RLW032205 RLW041405 RLW051505 RLW051505 RLW060005 RLW075005 - - RLW003503 RLW004603 RLW005503 RLW006503 RLW008303 RLW010403 RLW013003 RLW016003 RLW020003 RLW025003 RLW032203 RLW041403 RLW041403 RLW051503 RLW060003 RLW075003 - RLW003505 RLW004605 RLW005505 RLW006505 RLW008305 RLW010405 RLW013005 RLW016005 RLW020005 RLW025005 RLW032205 RLW041405 RLW041405 RLW051505 RLW060005 RLW075005 - RLW002803 RLW003503 RLW004603 RLW005503 RLW006503 RLW008303 RLW010403 RLW013003 RLW016003 RLW020003 RLW025003 RLW032205 RLW032203 RLW041403 RLW051503 RLW051503 RLW060003 RLW002806 RLW003505 RLW004605 RLW005505 RLW006505 RLW008305 RLW010405 RLW013005 RLW016005 RLW020005 RLW025005 RLW032205 RLW032205 RLW041405 RLW051505 RLW051505 RLW060005 Single Phase Input Applications RLW008305 RLW010405 RLW013005 RLW016005 RLW020005 RLW025005 RLW032205 RLW041405 RLW060005 RLW060005 RLW075005 - - - - - - RLW008305 RLW010405 RLW013005 RLW016005 RLW020005 RLW025005 RLW032205 RLW032205 RLW051505 RLW060005 RLW075005 RLW075005 - - - - - RLW006505 RLW008305 RLW010405 RLW013005 RLW016005 RLW020005 RLW025007 RLW025005 RLW041405 RLW051505 RLW051505 RLW060005 RLW075005 - - - - Three Phase Output Selected by Motor RLW005501 RLW006501 RLW008301 RLW010401 RLW013001 RLW016001 RLW020001 RLW025001 RLW032201 RLW041401 RLW051501 RLW060001 RLW060001 RLW075001 - - - RLW004603 RLW005501 RLW006501 RLW008303 RLW010403 RLW013003 RLW016001 RLW020003 RLW025003 RLW032201 RLW041401 RLW051503 RLW051501 RLW060001 RLW075001 - - RLW003503 RLW004603 RLW005503 RLW006503 RLW008303 RLW010403 RLW013003 RLW016003 RLW020003 RLW025003 RLW032203 RLW032203 RLW041403 RLW051503 RLW060003 RLW075003 RLW075003 Note: The recommended reactor selections above are based on fundamental current ratings. Contact appengrg@mtecorp.com with any questions regarding the proper reactor selection. RLW Reactors 17

RLW REACTOR SELECTION TABLES Open Open Part Number Amps Rating Inductance mh Watts Loss Open Weight (lbs) Size (in) (H x W x D) RLW-00P501 0.5 22 2.3 2 3.7 x 4.5 x 1.5 RLW-00P503 0.5 46 3.6 2 3.7 x 4.5 x 1.5 RLW-00P505 0.5 74 4.8 2 3.7 x 4.5 x 1.5 RLW-00P506 0.5 92 5.4 2 3.7 x 4.5 x 1.5 RLW-0P7501 0.75 15 4.2 2 3.7 x 4.5 x 1.5 RLW-0P7503 0.75 31 6.6 2 3.7 x 4.5 x 1.5 RLW-0P7505 0.75 49 8.8 2 3.7 x 4.5 x 1.5 RLW-0P7506 0.75 61 10.1 2 3.7 x 4.5 x 1.5 RLW-01P101 1.1 10 4.8 2 3.7 x 4.5 x 1.5 RLW-01P103 1.1 21 7.8 2 3.7 x 4.5 x 1.5 RLW-01P105 1.1 33 10.1 2 3.7 x 4.5 x 1.5 RLW-01P106 1.1 42 11.9 2 3.7 x 4.5 x 1.5 RLW-01P601 1.6 6.9 6.9 2 3.7 x 4.5 x 1.5 RLW-01P603 1.6 14 10.9 2 3.7 x 4.5 x 1.5 RLW-01P605 1.6 23 15 2 3.7 x 4.5 x 1.5 RLW-01P606 1.6 29 17.7 2 3.7 x 4.5 x 1.5 RLW-02P101 2.1 5.3 9 2 3.7 x 4.5 x 1.5 RLW-02P103 2.1 11 14.3 2 3.7 x 4.5 x 1.5 RLW-02P105 2.1 18 19.6 2 3.7 x 4.5 x 1.5 RLW-02P106 2.1 22 22.3 2 3.7 x 4.5 x 1.5 RLW-03P401 3.4 3.2 12.3 2 3.7 x 4.5 x 1.5 RLW-03P403 3.4 6.8 19.6 2 3.7 x 4.5 x 1.5 RLW-03P405 3.4 11 26.5 3 4.0 x 4.2 x 2.6 RLW-03P406 3.4 14 31.5 3 4.0 x 4.2 x 2.6 RLW-04P801 4.8 2.3 13.8 2 3.7 x 4.5 x 1.5 RLW-04P803 4.8 4.8 23 2 3.7 x 4.5 x 1.5 RLW-04P805 4.8 7.7 37.5 3 4.0 x 4.2 x 2.6 RLW-04P806 4.8 10 40.1 4 4.0 x 4.2 x 3.0 RLW-07P601 7.6 1.5 19.2 2 3.7 x 4.5 x 1.5 RLW-07P603 7.6 3 37.2 3 4.0 x 4.2 x 2.6 RLW-07P605 7.6 4.8 47.8 4 4.0 x 4.2 x 3.0 RLW-07P606 7.6 6 53.8 4 4.0 x 4.2 x 3.0 RLW-001101 11 1 26.8 3 4.0 x 4.2 x 2.6 RLW-001103 11 2.1 40.9 4 4.0 x 4.2 x 3.0 RLW-001105 11 3.3 54.4 5 4.0 x 4.2 x 3.3 RLW-001106 11 4.3 59.1 7 4.7 x 5.9 x 2.9 RLW-001401 14 0.79 32.7 3 4.0 x 4.2 x 2.6 RLW-001403 14 1.6 48.2 4 4.0 x 4.2 x 3.0 RLW-001405 14 2.6 60.6 7 4.7 x 5.9 x 2.9 RLW-001406 14 3.3 66 9 5.7 x 5.9 x 3.3 RLW-002101 21 0.53 38.3 4 5.2 x 4.2 x 3.0 RLW-002103 21 1.1 57.4 7 6.0 x 5.9 x 2.9 RLW-002105 21 1.8 73.5 10 6.0 x 5.9 x 3.3 RLW-002106 21 2.2 78 13 6.8 x 7.1 x 3.5 RLW-002801 28 0.39 48.2 5 5.2 x 4.2 x 3.3 RLW-002803 28 0.82 66.8 10 6.0 x 5.9 x 3.3 RLW-002805 28 1.3 93.8 10 6.0 x 5.9 x 3.3 RLW-002806 28 1.6 110.6 14 6.8 x 7.1 x 3.5 RLW-003501 35 0.35 69 10 6.0 x 5.9 x 3.5 RLW-003503 35 0.71 103 13 5.8 x 7.1 x 3.7 RLW-003505 35 1.2 122 18 5.8 x 7.1 x 4.2 RLW-003507 35 2.12 204 28 8.3 x 8.9 x 5.7 RLW-004601 46 0.3 78 12 5.8 x 7.1 x 3.7 RLW-004603 46 0.55 100 17 5.7 x 7.1 x 4.2 Open Open Part Number Amps Rating Inductance mh Watts Loss Open Weight (lbs) Size (in) (H x W x D) RLW-004605 46 0.98 179 24 8.3 x 8.9 x 4.6 RLW-004607 46 1.6 192 33 8.4 x 8.9 x 4.9 RLW-005501 55 0.27 68 18 5.5 x 7.1 x 4.9 RLW-005503 55 0.48 110 20 5.6 x 7.1 x 5.6 RLW-005505 55 0.75 150 26 7.0 x 8.9 x 5.7 RLW-005507 55 1.33 283 35 7.0 x 9.0 x 6.8 RLW-006501 65 0.19 87 18 5.6 x 7.1 x 5.0 RLW-006503 65 0.36 105 22 5.7 x 7.1 x 6.0 RLW-006505 65 0.64 215 26 7.0 x 8.9 x 5.7 RLW-006507 65 1.1 191 44 7.0 x 8.9 x 7.0 RLW-008301 83 0.17 119 19 5.6 x 7.1 x 5.9 RLW-008303 83 0.29 155 26 7.0 x 8.9 x 5.8 RLW-008305 83 0.51 198 35 7.0 x 8.9 x 6.5 RLW-008307 83 0.91 240 54 7.0 x 8.9 x 7.5 RLW-010401 104 0.12 94 22 5.6 x 7.1 x 5.6 RLW-010403 104 0.23 200 28 7.1 x 8.9 x 6.2 RLW-010405 104 0.375 208 41 7.2 x 9.6 x 7.0 RLW-010407 104 0.67 256 57 7.2 x 9.6 x 7.5 RLW-013001 130 0.095 132 26 7.1 x 8.9 x 6.4 RLW-013003 130 0.18 153 37 7.0 x 9.6 x 6.9 RLW-013005 130 0.3 198 52 7.2 x 9.6 x 7.9 RLW-013007 130 0.56 480 80 8.5 x 10.8 x 8.1 RLW-016001 160 0.08 110 34 7.0 x 8.9 x 6.4 RLW-016003 160 0.155 195 40 7.3 x 9.6 x 7.1 RLW-016005 160 0.26 309 53 7.3 x 9.6 x 7.9 RLW-016007 160 0.47 561 91 8.6 x 10.8 x 9.9 RLW-020001 200 0.06 159 34 6.9 x 8.9 x 6.4 RLW-020003 200 0.115 224 49 7.2 x 9.6 x 7.9 RLW-020005 200 0.2 293 75 8.5 x 10.8 x 8.5 RLW-020007 200 0.34 509 91 8.5 x 10.8 x 9.5 RLW-025001 250 0.05 276 35 7.1 x 8.9 x 6.9 RLW-025003 250 0.095 284 55 7.2 x 9.6 x 7.9 RLW-025005 250 0.16 402 93 8.5 x 10.8 x 10.5 RLW-025007 250 0.27 465 121 8.4 x 10.8 x 10.6 RLW-032201 322 0.05 300 57 7.3 x 9.6 x 8.4 RLW-032203 322 0.07 383 76 8.4 x 10.8 x 8.7 RLW-032205 322 0.13 494 108 8.4 x 10.8 x 10.9 RLW-032207 322 0.225 780 172 11.2 x 14.3 x 10.5 RLW-041401 414 0.033 333 78 8.4 x 10.8 x 9.2 RLW-041403 414 0.066 531 98 8.5 x 10.8 x 10.4 RLW-041405 414 0.11 588 125 8.5 x 10.8 x 12.3 RLW-041407 414 0.185 1007 197 11.2 x 14.3 x 13.1 RLW-051501 515 0.025 314 81 8.4 x 10.8 x 8.8 RLW-051503 515 0.05 496 118 8.5 x 10.8 x 12.1 RLW-051505 515 0.08 695 193 11.1 x 14.3 x 12.7 RLW-051507 515 0.15 1096 248 11.2 x 14.3 x 13.2 RLW-060001 600 0.02 375 375 8.5 x 10.8 x 9.9 RLW-060003 600 0.04 747 144 11.2 x 14.3 x 11.8 RLW-060005 600 0.065 780 204 11.2 x 14.3 x 12.6 RLW-060007 600 0.12 1190 292 11.2 x 14.3 x 14.7 RLW-075001 750 0.017 468 105 8.6 x 10.8 x 11.0 RLW-075003 750 0.035 838 166 11.3 x 14.3 x 11.0 RLW-075005 750 0.055 858 245 11.1 x 14.3 x 13.8 RLW-075007 750 0.095 1426 348 11.2 x 14.3 x 17.2 Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. 18

mtecorp.com Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. NEMA 1/2 Part Number Weight (lbs) Cabinet Size (in) (H x W x D) Ref Figure RLW-00P511 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-00P513 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-00P515 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-00P516 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-0P7511 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-0P7513 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-0P7515 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-0P7516 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-01P111 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-01P113 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-01P115 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-01P116 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-01P611 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-01P613 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-01P615 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-01P616 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-02P111 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-02P113 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-02P115 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-02P116 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-03P411 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-03P413 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-03P415 8 CAB-8 8.0 x 8.2 x 6.3 1 RLW-03P416 8 CAB-8 8.0 x 8.2 x 6.3 1 RLW-04P811 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-04P813 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-04P815 8 CAB-8 8.0 x 8.2 x 6.3 1 RLW-04P816 9 CAB-8 8.0 x 8.2 x 6.3 1 RLW-07P611 7 CAB-8 8.0 x 8.2 x 6.3 1 RLW-07P613 8 CAB-8 8.0 x 8.2 x 6.3 1 RLW-07P615 9 CAB-8 8.0 x 8.2 x 6.3 1 RLW-07P616 10 CAB-8 8.0 x 8.2 x 6.3 1 RLW-001111 8 CAB-8 8.0 x 8.2 x 6.3 1 RLW-001113 9 CAB-8 8.0 x 8.2 x 6.3 1 RLW-001115 10 CAB-8 8.0 x 8.2 x 6.3 1 RLW-001116 12 CAB-8 8.0 x 8.2 x 6.3 1 RLW-001411 8 CAB-8 8.0 x 8.2 x 6.3 1 RLW-001413 9 CAB-8 8.0 x 8.2 x 6.3 1 RLW-001415 12 CAB-8 8.0 x 8.2 x 6.3 1 RLW-001416 23 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-002111 18 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-002113 21 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-002115 24 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-002116 27 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-002811 19 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-002813 24 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-002815 24 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-002816 28 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-003511 24 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-003513 27 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-003515 32 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-003517 42 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-004611 26 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-004613 31 CAB-13V 13.2 x 13.2 x 13.1 3 NEMA 1/2 Part Number Weight (lbs) Cabinet Size (in) (H x W x D) Ref Figure RLW-004615 38 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-004617 47 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-005511 32 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-005513 34 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-005515 40 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-005517 49 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-006511 32 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-006513 36 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-006515 40 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-006517 58 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-008311 33 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-008313 40 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-008315 49 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-008317 68 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-010411 36 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-010413 42 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-010415 55 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-010417 71 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-013011 40 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-013013 51 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-013015 66 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-013017 94 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-016011 48 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-016013 54 CAB-13V 13.2 x 13.2 x 13.1 3 RLW-016015 96 CAB-17V 24.0 x 17.1 x 18.5 4 RLW-016017 134 CAB-17V 24.0 x 17.1 x 18.5 4 RLW-020011 77 CAB-17V 24.0 x 17.1 x 18.5 4 RLW-020013 92 CAB-17V 24.0 x 17.1 x 18.5 4 RLW-020015 118 CAB-17V 24.0 x 17.1 x 18.5 4 RLW-020017 134 CAB-17V 24.0 x 17.1 x 18.5 4 RLW-025011 78 CAB-17V 24.0 x 17.1 x 18.5 4 RLW-025013 98 CAB-17V 24.0 x 17.1 x 18.5 4 RLW-025015 136 CAB-17V 24.0 x 17.1 x 18.5 4 RLW-025017 164 CAB-17V 24.0 x 17.1 x 18.5 4 RLW-032211 100 CAB-17V 24.0 x 17.1 x 18.5 4 RLW-032213 213 CAB-26C2 47.0 x 26.6 x 24.9 2 RLW-032215 245 CAB-26C2 47.0 x 26.6 x 24.9 2 RLW-032217 309 CAB-26C2 47.0 x 26.6 x 24.9 2 RLW-041411 215 CAB-26C2 47.0 x 26.6 x 24.9 2 RLW-041413 235 CAB-26C2 47.0 x 26.6 x 24.9 2 RLW-041415 262 CAB-26C2 47.0 x 26.6 x 24.9 2 RLW-041417 334 CAB-26C2 47.0 x 26.6 x 24.9 2 RLW-051511 218 CAB-26C2 47.0 x 26.6 x 24.9 2 RLW-051513 255 CAB-26C2 47.0 x 26.6 x 24.9 2 RLW-051515 330 CAB-26C2 47.0 x 26.6 x 24.9 2 RLW-051517 385 CAB-26C2 47.0 x 26.6 x 24.9 2 RLW-060011 223 CAB-26C2 47.0 x 26.6 x 24.9 2 RLW-060013 281 CAB-26C2 47.0 x 26.6 x 24.9 2 RLW-060015 341 CAB-26C2 47.0 x 26.6 x 24.9 2 RLW-060017 429 CAB-26C2 47.0 x 26.6 x 24.9 2 RLW-075011 242 CAB-26C2 47.0 x 26.6 x 24.9 2 RLW-075013 303 CAB-26C2 47.0 x 26.6 x 24.9 2 RLW-075015 382 CAB-26C2 47.0 x 26.6 x 24.9 2 RLW-075017 485 CAB-26C2 47.0 x 26.6 x 24.9 2 RLW Reactors 19

Reduce AC input line harmonics Absorb voltage/current spikes Reduce AC ripple on DC bus Solve nuisance over-voltage tripping Reduce DC Bus transient over-voltage Economical. Versatile. Our DC Link Chokes are an economical means of filtering the DC bus voltage in variable frequency drives (VFDs). Designed to be added to a VFD’s internal bridge and bus, they help reduce AC input line current harmonic distortion while absorbing DC bus voltage spikes. They can be used individually, typically on the positive DC bus, or in pairs with one each on both the positive and negative bus. Take advantage of maximizing the circuit inductance for power quality reasons without causing an AC input line voltage drop with DC Link Chokes from MTE. DC Link Chokes 21

Performance Specifications Component Recognized UL-508 (File #E180243) Maximum Voltage 1000V DC Ripple Frequency 300 Hz or 360 Hz Ambient Temperature 40°C Ripple Current 10% peak-to-peak Insulation System Class B (130C) Final product specifications subject to change at any time. An economical and versatile solution to solving power quality problems. DC Link Chokes The ability of our DC Link Chokes to be used across multiple applications is just one reason these chokes stand above the rest. With factory capabilities to customize mounting, inductance, current or ripple requirements, our DC Link Chokes will meet all of your needs. Solid copper box lug type available on most sizes. Specially constructed and epoxy impregnated for low noise. Series A link chokes are also available in NEMA 1-2 or NEMA 3R enclosures upon request. Understanding the DC Link Choke Series A Part Number: Mechanical Configurations 0 = Open Magnetics (No Enclosure) 1 = General Purpose (NEMA 1/2) 3 = Weather (NEMA 3R) Series A Current Rating 0004 is 4 Amps 0050 is 50 Amps 0200 is 200 Amps DC Link Choke DC A _ _ _ _ X X Reactor Relative Impedance No. 1, 2, 3, 4 (1 is lowest value) Understanding the DC Link Choke Series RB Part Number: Series RB Current Rating 4 is 4 Amps 50 is 50 Amps 200 is 200 Amps _ _ _ _ RB 00 X Reactor Relative Impedance No. 1, 2, 3, 4 (1 is lowest value) • AC PWM inverters/drives • Variable frequency motor drives • DC to AC inverters • Electrical vehicle inverters Useful Applications 22

mtecorp.com DC Link Chokes 1000V 360Hz DC Amps Inductance mH MTE Part Number Ref Fig DC Amps Inductance mH MTE Part Number Ref Fig DC Amps Inductance mH MTE Part Number Ref Fig DC Amps Inductance mH MTE Part Number Ref Fig 1 35.00 1RB001 1 25 0.45 25RB001 1 80 0.75 80RB004 3 300 0.08 300RB001 3 1 60.00 1RB002 1 25 1.00 25RB002 2 80 1.25 DCA008005 3 300 0.135 300RB002 3 1 80.00 1RB003 1 25 1.275 DCA002504 2 92 0.20 DCA009201 3 300 0.32 300RB003 3 2 10.00 2RB001 1 25 1.75 DCA002503 2 92 0.60 DCA009202 3 450 0.055 450RB001 4 2 15.00 2RB002 1 25 4.00 DCA002505 2 92 1.00 DCA009203 3 450 0.11 450RB002 4 2 20.00 2RB003 1 32 0.85 DCA003201 2 110 0.25 110RB001 3 450 0.14 450RB003 4 2 50.00 DCA000204 1 32 1.62 DCA003202 2 110 0.30 DCA011002 3 450 0.25 450RB004 4 4 5.00 4RB001 1 32 2.68 DCA003203 2 110 0.45 DCA011003 3 500 0.043 500RB001 4 4 12.00 DCA000402 1 40 0.50 DCA004001 2 125 0.11 125RB001 3 500 0.09 500RB002 4 4 15.00 DCA000403 1 40 0.75 DCA004002 2 125 0.22 DCA012502 3 500 0.14 500RB003 4 4 25.00 DCA000404 2 40 1.00 DCA004003 2 125 0.50 125RB003 3 500 0.19 500RB004 4 9 2.00 9RB001 1 40 2.50 DCA004004 2 125 0.85 125RB004 3 600 0.04 600RB001 4 9 3.22 DCA000902 1 50 0.625 DCA005001 2 150 0.15 150RB001 3 600 0.11 600RB002 4 9 7.50 DCA000903 2 50 0.97 50RB002 2 150 0.22 DCA015002 3 600 0.18 600RB003 4 9 11.50 DCA000904 2 50 1.35 DCA005003 2 150 0.32 150RB003 3 700 0.044 700RB001 4 12 1.00 DCA001201 1 50 2.0 DCA005004 3 150 0.65 DCA015004 3 700 0.06 700RB002 4 12 2.10 DCA001202 2 62 0.35 DCA006201 3 200 0.12 200RB001 3 700 0.15 700RB003 4 12 4.00 DCA001203 2 62 0.61 DCA006202 3 200 0.21 DCA020002 3 850 0.036 850RB001 4 12 6.00 DCA001204 2 62 0.67 62RB003 3 200 0.40 200RB003 3 850 0.065 850RB002 4 18 0.65 DCA001801 1 62 1.20 62RB004 3 200 0.50 200RB004 3 850 0.11 850RB003 4 18 1.375 DCA001802 2 62 1.50 62RB005 3 240 0.09 240RB001 3 1000 0.02 1000RB001 4 18 2.75 DCA001803 2 80 0.31 80RB001 3 240 0.25 240RB002 3 1000 0.042 1000RB002 4 18 3.75 DCA001804 2 80 0.40 DCA008002 3 240 0.35 240RB003 3 1000 0.10 1000RB003 4 18 6.00 DCA001805 2 80 0.50 80RB003 3 OPEN MAGNETICS FIGURE 1 FIGURE 3 FIGURE 2 FIGURE 4 Note: Figure illustrations are for reference only. Actual hardware may differ. Please visit mtecorp.com for detailed information. 23

dV Sentry® dV E-Series The dV Sentry® and its patented Triple Defense Core is proven to reduce common mode, protect against peak voltage, and reduce rise time – all-in-one unit. The dV E-Series is lighter, more efficient, and runs cooler than other dV/dt solutions making it the optimal solution for leads less than 1,000 ft. SineWave Guardian® This best-in-class filter cleans up the PWM waveforms generated by VFDs. It virtually eliminates high frequency content and voltage peaks to reduce motor downtime. *Also available for High Frequency and Permanent Magnet Motors SineWave Nexus® microNexus™ SineWave Nexus® filters eliminates common mode voltage which causes motor bearing failures such as pitting, frosting, or fluting damage - up to 15,000 feet. The microNexus takes the unparalleled performance of our SineWave Nexus and shrinks it down into a space-saving solution that integrates into any micro drive application. Matrix® AP The Matrix® AP is the most advanced passive filter on the market to meet IEEE-519. Its patented Adaptive Passive Technology adapts to varying loads to virtually eliminate harmonics. Matrix® ONE single phase filters are optimized to work in remote and rural areas where three phase power is not available. Matrix® ONE The Matrix® E-Series harmonic filter meets the international harmonic distortion requirement of 10%-15% while also supporting the compliance of IEEE-519. Matrix® E-Series HARMONIC MITIGATION FILTERS REACTOR PRODUCTS MOTOR PROTECTION FILTERS RL Reactors DC Link Chokes The RL family of line and load reactors is unequaled in absorbing power line disturbances to reduce nuisance tripping, reduce harmonic distortion, and minimize long lead effects. Designed to be added to a VFD’s internal bridge and bus, DC Link Chokes help reduce AC input line current harmonic distortion while absorbing DC bus voltage spikes. RLW Reactors The RLW family of line and load reactors provides an engineered solution to protect electrical systems against harmful and annoying power distortions. Our Products 24

Trusted by leading industries. At MTE, we leverage our know-how to provide not just any solution, but the perfect solution customized to fit even the most demanding industries. As the power quality partner of choice for hundreds of leading companies, we protect your most valuable assets by combining our knowledge, expertise, and support to increase uptime and improve your bottom line. Whatever the power quality problem, MTE is the trusted solution. Cloud Uptime Production Uptime Energy Resilience Expedited Delivery Supply Assurance Cooling Efficiency Food Safety mtecorp.com 25

MTE Corporation (800) 455-4683 • (262) 253-8200 Scan QRC for home page. MTE-CAT-REA-E 0523 Reactors Product Catalog
