MTE Solutions Catalog

Motor Protection Note: Weights and dimensions are for reference only. Please visit mtecorp.com for detailed information. 208V – 240V 75Hz Motor (Ref Only) Filter Amps Rating MTE Part Number Enclosure Type Filter Dimensions (H x W x D) Approx Weight Ref Fig Watts Loss Capacitor/Capacitor Panel Assembly Dimensions (H x W x D) Qty Req’d Ref Fig 208V HP 240V HP Inches Millimeters Lbs Kgs Inches Millimeters 2 3 9 SWGM0009A OPEN 6.6 x 8.0 x 4.8 168 x 203 x 122 11 5 7 63 7.5 x 3.0 191 x 76 1 1 SWGG0009A NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 28 13 3 Preinstalled in cabinet SWGW0009A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 69 31 5 3 4 12 SWGM0012A OPEN 6.7 x 8.0 x 5.1 170 x 203 x 130 14 6 7 75 7.5 x 3.0 191 x 76 1 1 SWGG0012A NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 30 14 3 Preinstalled in cabinet SWGW0012A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 69 31 5 5 5.5 17 SWGM0017A OPEN 6.7 x 8.0 x 5.1 170 x 203 x 130 14 6 7 101 7.5 x 3.9 191 x 99 1 1 SWGG0017A NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 30 14 3 Preinstalled in cabinet SWGW0017A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 69 31 5 5.5 7.5 22 SWGM0022A OPEN 6.6 x 8.0 x 5.4 168 x 203 x 137 15 7 7 112 8.3 x 3.0 211 x 76 1 1 SWGG0022A NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 32 15 3 Preinstalled in cabinet SWGW0022A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 71 32 5 7.5 10 30 SWGM0030A OPEN 7.5 x 9.0 x 4.8 191 x 229 x 122 18 8 7 100 8.3 x 3.0 211 x 76 1 1 SWGG0030A NEMA 1/2 13.2 x 13.0 x 13.1 335 x 330 x 333 34 15 3 Preinstalled in cabinet SWGW0030A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 73 33 5 10 - 12.5 15 45 SWGM0045A OPEN 8.7 x 10.5 x 6.7 221 x 267 x 170 28 13 7 138 8.3 x 4.6 211 x 117 1 1 SWGG0045A NEMA 1/2 24.0 x 17.0 x 18.5 610 x 432 x 470 78 35 4 Preinstalled in cabinet SWGW0045A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 85 39 5 15 20 55 SWGM0055A OPEN 9.0 x 10.5 x 7.4 229 x 267 x 188 32 15 8 162 8.3 x 4.6 211 x 117 1 1 SWGG0055A NEMA 1/2 24.0 x 17.0 x 18.5 610 x 432 x 470 80 36 4 Preinstalled in cabinet SWGW0055A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 87 40 5 20 25 70 SWGM0070A OPEN 9.0 x 10.5 x 7.9 229 x 267 x 201 34 15 8 192 8.3 x 3.0 211 x 76 1 1 SWGG0070A NEMA 1/2 24.0 x 17.0 x 18.5 610 x 432 x 470 82 37 4 Preinstalled in cabinet SWGW0070A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 90 41 5 25 30 85 SWGM0085A OPEN 8.7 x 10.5 x 7.2 221 x 267 x 183 38 17 8 201 8.3 x 3.0 211 x 76 1 1 SWGG0085A NEMA 1/2 24.0 x 17.0 x 18.5 610 x 432 x 470 86 39 4 Preinstalled in cabinet SWGW0085A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 93 42 5 30 40 110 SWGM0110A OPEN 8.7 x 10.5 x 8.9 221 x 267 x 226 53 24 8 226 8.3 x 4.0 211 x 102 1 1 SWGG0110A NEMA 1/2 24.0 x 17.0 x 18.5 610 x 432 x 470 101 46 4 Preinstalled in cabinet SWGW0110A NEMA 3R 24.0 x 12.5 x 22.9 610 x 318 x 582 109 49 5 40 50 135 SWGM0135A OPEN 11.0 x 12.0 x 9.3 279 x 305 x 236 72 33 9 299 8.3 x 3.0 211 x 76 1 1 SWGG0135A NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 148 67 6 Preinstalled in cabinet SWGW0135A NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 159 72 50 60 160 SWGM0160A OPEN 10.6 x 12.0 x 9.7 269 x 305 x 246 74 34 9 303 8.3 x 4.6 211 x 117 1 1 SWGG0160A NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 150 68 6 Preinstalled in cabinet SWGW0160A NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 161 73 60 75 200 SWGM0200A OPEN 10.9 x 12.0 x 11.4 277 x 305 x 290 120 54 9 387 8.3 x 4.0 211 x 102 1 1 SWGG0200A NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 199 90 6 Preinstalled in cabinet SWGW0200A NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 209 95 75 100 250 SWGM0250A OPEN 10.5 x 12.0 x 11.2 267 x 305 x 284 110 50 9 374 8.3 x 3.0 211 x 76 1 1 8.3 x 4.6 211 x 117 1 SWGG0250A NEMA 1/2 33.9 x 18.3 x 20.9 861 x 465 x 531 189 86 6 Preinstalled in cabinet SWGW0250A NEMA 3R 33.9 x 18.3 x 26.0 861 x 465 x 660 199 90 100 125 320 SWGM0320A OPEN 14.2 x 15.3 x 11.8 361 x 389 x 300 153 69 10 637 7.4 x 16.4 x 7.6 188 x 417 x 193 1 2 SWGG0320A NEMA 1/2 51.3 x 27.7 x 24.9 1303 x 704 x 632 321 146 6 Preinstalled in cabinet SWGW0320A NEMA 3R 51.3 x 27.7 x 30.0 1303 x 704 x 762 334 151 SINEWAVE GUARDIAN ® SELECTION TABLES 65
