Mastervolt 2023

2 0 2 3 MARINE EMERGENCY VEHICLE INDUSTRIAL RV

Heating Systems Pumps whalepumps.com Actuators Trim Tab System lencomarine.com AC Shore Power Marine Accessories marinco.com Batteries Power Conversion mastervolt.us Battery Chargers promariner.com Battery Management Circuit Protection Power Distribution bluesea.com Lighting Marine Accessories Water and Fuel Systems attwoodmarine.com Digital Control & Monitoring Onboard Offboard UX czone.net Wire Wire Management ancorproducts.com Trolling Motors motorguide.com Lithium Batteries Portable Power AGM Batteries relionbattery.com Metal Fabricated Hardware garelick.com Battery Management Power Distribution bepmarine.com Chartplotters Fishfinders Sonar & Radar Trolling Motors lowrance.com Chartplotters Radar Autopilots Sonar Technology simrad-yachting.com Chartplotters Displays Instruments Sensors bandg.com Marine Cartography c-map.com Your most trusted partner Navico Group is the world’s leading supplier of integrated systems and products to industries ranging from marine to recreational vehicles. We bring together the best brands, products and people to create groundbreaking innovations that reinvent the consumer experience. Our broad portfolio of the industry’s leading brands in power management, digital control & monitoring, networked devices, and marine electronics are distributed globally to a diverse aftermarket and OEM customer base. Navico Group is driven, every day, to be the world’s most trusted partner to the marine and mobile industries, and beyond. AVICO GROUP

Mastervolt is a strong, innovation-driven brand. This capacity to innovate is what truly sets Mastervolt apart. Mastervolt leads the marine and mobile industries in autonomous power solutions. Technologically advanced Lithium Ion batteries and fully integrated power conversion equipment provide off-grid power whether on the water or on the road. I Innovation and Product Development From power conversion and storage to integrated systems, Mastervolt products are at the forefront of technology. Pioneering research is within the brands DNA, highly skilled engineers are responsible for translating tomorrow’s technology into the ultimate performance of today. With comprehensive processes, the Mastervolt team sources and tests the best components and pushes all new product designs to the limits, ensuring the most reliable and complete end product. In essence, customers will receive the highest quality products. I System Solutions Whatever the industry or application, Mastervolt products are power solution focused and designed to easily integrate into comprehensive systems. From DC battery power and power conversion products to complete digital switching technologies and monitoring at the touch of a finger, Mastervolt products provide the flexibility and can be fully customized for your applications. I Worldwide Network The Mastervolt brand offers a global service. With offices and partners in more than 80 countries, top class brand expertise and support is available throughout the world. Our customers know that wherever they are, efficient support is on hand whether it is a technical enquiry or to track the progress of an order. What makes Mastervolt different:

new NEW bug Products Ultra Connection Kit Ultra Connection Kit With the MLI Ultra Relay and Fuse Connect Kit, is an integrated safety switch for use with MLI Ultra Lithium Ion batteries. The kit includes all the required safety accessories in a safe, efficient, and compact way right on top of the MLI Ultra battery. Perfect fit for MLI Ultra 12/2750 and 12/5500 & 24/5500. Part # 79007712 12V Part # 79007724 24V 65 CombiMaster Inverter/Charger The CombiMaster inverter/charger provides the most power and charging in the series. The new 3500W version comes in 12V and can be paralleled stacked in a single system up to 10.5kW. The new 24V models in 3500W & 4500W and 48V 5000W unit can create parallel and series stacked systems to power up to 35kW and be used to power split phase loads. All models provide pure sine wave inverter power and over 60-200A multi-chemistry battery charging, plus the intelligent new design is NMEA 2000 and MasterBus compatible. Part # 35513500 12/3500-200A 120V Part # 35523500 24/3500-100A 120V Part # 35524500-HT 24/4500-100A 120V Part # 35545000-HT 48/5000-120A 120V 16 Mastervolt-CZone Waterproof Drop Cable Adapter cable with integrated waterproof boot for connecting MLI Ultra batteries with CZONE support to the CZONE or NMEA 2000 network. Part # 77061050 1.6 ft (0.5m) Part # 77061100 3.3 ft (1m) Part # 77061200 6.6 ft (2m) Part # 77061500 16.4 ft (5m) Part # 6369230060 Li-Ion Waterproof Field Installable Plug 86 Alpha Compact Alternators Alpha Compact “automotive style” alternators provide an easy fit on factory-installed PTO (power take-off) brackets available from most engine manufacturers. Alpha Compact offers lower weight, smaller dimensions and reduced fuel consumptions. Available in 12V and 24V 200A models – specific to Mercedes brackets. Part # 46228203 28/200 104 Mac Plus The Mac Plus is a DC:DC converter to supply a stable power supply to batteries. For use when the alternator is inactive and the battery voltage is very low or located a distance away from charging source. The Mac Plus comes with integrated MasterBus (CAN) communication and E-mark certification. It seamlessly charges Lithium Ion, Gel and AGM batteries via a 3-stage charging method and is available in 12V, 24V, 36V & 48V options. Part # 81205105 12/12-50 Part # 81205305 12/24-30 Part # 81205205 24/12-50 Part # 81205405 24/24-30 Part # 81206205 12/48-15 Part # 81206405 24/48-15 48 EXPANDED OFFERING 6369230060 EXPANDED OFFERING EXPANDED OFFERING MLI Lithium Ion Series The MLI series delivers ultimate Lithium Ion performance even under the harshest conditions, such as high charge and discharge currents, wet environments, mechanical shocks or vibrations. This is realized by combining our best Lithium-Iron Phosphate (LiFePO4) cells with a proprietary Battery Management System (BMS) inside a sturdy, waterproof housing. Part # 66013000 12/3000 Part # 66016000 12/6000 Part # 66026000 24/6000 64 EXPANDED OFFERING

p. 104 Power Conversion Mastervolt Inverter/Chargers 8 PowerCombi 19 Sine Wave Inverters 20 AC Master 26 Battery Chargers 32 DC-DC Converters 46 AC Transfer Systems 54 Battery Management BI Battery Isolators 90 Battery Mate 90 Charge Mate 91 Battery Monitoring 92 Batteries Lithium Ion Batteries 62 Gel Batteries 66 AGM Batteries 68 Transformers Mass GI 96 IVET Heavy-duty 96 Alternators & Regulators Alpha Alternators 102 Alpha Charge Regulators 106 Solar ChargeMaster 107 Digital Control & Monitoring CZone® Overview 72 Fully Integrated CZone® & MasterBus System Diagram 74 MasterBus Displays 78 MasterBus Network Components 80 MasterBus Interfaces 82 MasterBus Accessories 86 p. 91 p. 91 p. 93 p. 98 p. 98 p. 24 p. 68 p. 66 p. 64 p. 80 p. 82 p. 48 p. 19 p. 16 old NEW bug new NEW bug Index Part Number Index 109 p. 108 p. 106 Table of Contents p. 86 old NEW bug new NEW bug old NEW bug new NEW bug old NEW bug new NEW bug

The Mastervolt Combi Inverter/Chargers are recognized as the best product on the market and offers proven reliability. The Mass Combi Ultra/Pro Inverter/Chargers are based on the well-known Mass Combi range but is even more compact, stronger more efficient and comprehensive. Mastervolt Inverter/Chargers POWER CONVERSION The ChargeMaster and ChargeMaster Plus are suitable for recreational and semi-professional use and safely charges multiple battery banks at the same time. Mass battery chargers are great for the tougher tasks in professional and semi-professional situations. With its integrated alarm functions and various approvals, the Mass is the best choice for professionals. ChargeMaster Plus & Mass Battery Chargers Mastervolt offers a complete range of inverters from 300 watt to 40 kWatt. The AC Master is ideal for small and mediumsized applications, while Mass Sine Inverters and the advanced Sine Ultra Inverters are mainly intended for larger systems and for professional purposes. Mastervolt offers inverters for 230V/50Hz and 120V/60Hz. AC Master & Mass Sine Wave Inverters 8 20 32

POWER CONVERSION Ocean Race's grueling and challenging conditions are a testament to the quality engineering and design put into each Mastervolt product aboard. The Mastervolt transfer system helps you regulate your shore, generator or inverter power and automatically selects the right power sources at the right time. With Mastervolt you can cook and do laundry at the same time, or watch TV with the air conditioning on full blast. Transfer Systems These versatile converters include an energy saving dimmer function as well as output voltage stabilization. Plus, if there are several power consuming devices onboard, the parallel connection allows for capacity of 40, 60, or more amps. Mac Plus, Mac, & Magic Series & DC Master DC to DC Converters 46 54

mastervolt.us POWER CONVERSION 8 Which Inverter/Charger suits you? Mass Combi Ultra The Mass Combi Ultra is more compact, stronger and more efficient. In addition to easy installation and higher capacities, the Combi Ultra has various unique benefits such as full capacity in high temperatures, an integrated solar charge regulator, and separate grid power and generator inputs. Up to ten units can be parallel switched plus a 3-phase power supply. Available for systems ranging from 3,000 watt to 40 kW, designed for professional and semi-professional use. Mass Combi Pro The Mass Combi Pro is the perfect solution for professional applications. This version has all the Mass Combi Ultra features but without solar input and secondary charger. The Pro provides the optimal balance of strength, versatility and cost. CombiMaster This latest Mastervolt innovation delivers unmatched performance at an unprecedented price, and offers the best of both worlds: an advanced battery charger and a quiet inverter combined in one compact device. The CombiMaster is easy to install without expert knowhow thanks to plug & play capability. With a single AC input and intuituve LEDs, it is compatible with MasterBus, CZone and NMEA 2000, the CombiMaster ranges from 1500 to 5000w Watt. Suitable for recreational and semiprofessional use. Inverter/Chargers integrate a powerful battery charger, a quiet and efficient inverter and a versatile switching system in one robust, lightweight and compact device. This multi-faceted product offers a carefree power supply for recreational and professional use. Possible applications vary from launches to yachts, from campers to demo trucks, from holiday homes to remote businesses, and from backup systems to grid connected systems with energy storage. Each Mass Combi, Mass Combi Ultra and Mass Combi Pro Inverter/Charger can be used as an automatic stand-alone device for a non-stop power supply or as part of a larger power system. MasterBus/CZone Compatible The endless MasterBus configuration possibilities are ideal for advanced system integration. The MasterBus interface allows direct modification of system parameters with immediate result. For applications that require duplication (series build of systems) CZone communication is ideally suited. You simply design the configuration file and duplicate this to all systems with one click. Mastervolt Inverter/Chargers: High-quality power supply with first-class comfort, wherever you are

mastervolt.us POWER CONVERSION 9 Power Assist for extra power Not just any battery charger If you require more power than the grid or generator can provide, the Mass Combi series will make up the shortfall by inverting from the battery. The Combi also ensures that the battery is recharged once the peak demand has passed. The built-in battery charger uses Mastervolt’s proven 3-step+ charging technology to allow the optimal charging of all battery types, including our advanced Lithium Ion models. The battery charger supplies a maximum charge current, even with a higher charge voltage, and speeds up the complete recharging of your batteries. Ease of installation The integrated design of three devices into one, lightweight body and robust mounting clamps give considerable savings in (labor) time and costs. Exceptional performance The inverter is quiet, clean and efficient, and offers the full capacity even in extreme ambient temperatures. Pure sine wave energy and a peak capacity of 200% guarantee a problem-free start, even for the heaviest loads.

mastervolt.us POWER CONVERSION 10 Mass Combi Ultra Features • For professional and semi-professional use • Quiet, powerful inverter with 200% peak power • Compact, lightweight and hum-free thanks to HF technology • Pure sine wave voltage prevents malfunctions and damage to sensitive equipment such as adapters • High yield and more power from your batteries • Intelligent 3-step+ battery charger with low DC ripple current for fast charging times and long battery life • Power Assist: prevents blown fuses • A dynamic battery voltage window allows you to enjoy AC power for longer without damaging your batteries • Active Optima Cooling concept prevents unnecessary fan noise • Charges two individual battery banks simultaneously (Mass Combi Ultra) • An integrated MPPT solar charge controller allows for 30% more yield from solar power for charging the batteries (Mass Combi Ultra) • Quick installation and reliable professional connections • CE and ABYC certified Mass Combi Ultra & Mass Combi Pro Inverter/Chargers: Powerful, complete and versatile The Mass Combi Ultra series comprises several models, varying from 3000 W to 3500 W. For higher capacities up to 35 kW the Mass Combi Ultra can be used in parallel or 3-phase configurations. An efficient and integrated solar charge regulator helps make the most of your solar panels. The Mass Combi Ultra Inverter/Charger is equipped with the latest technologies. The new inverter technology ensures a uniquely low stand-by use, while an ultra-fast digital signal processor guarantees seamless switching between all available energy sources. Power assist prevents power dips and failures, even with a weak electricity connection or small generator. Moreover, all Mass Combi Ultra Inverter/Charger models are equipped with MasterBus. Higher yield from solar energy At Mastervolt we used our knowledge gained in the grid connected solar sector to make a super-efficient built-in MPPT (Maximum Power Point Tracker) solar charge regulator. Compared to most solar charge regulators on the market, the MPPT offers up to 30% more yield from solar panels. The solar panels power ‘hidden’ consumers and keep your batteries in optimal condition. ‘Pro’ models For professional applications, Mastervolt offers a ‘Pro’ model, featuring all Ultra functions, but without the solar input and slave battery charger.

mastervolt.us POWER CONVERSION 11 Standard MasterBus System—Mass Combi Ultra and Mass Combi Pro Inverter/Chargers—230V up to 35 kW • Compact and lightweight inverter/charger combination • Two AC inputs with seamless transfer between generator and shore power • Integrated MPPT solar charger regulator • Parallel & 120/240V Split-Phase operation (with the use of autoformer) 1 Mass Combi Ultra Inverter/Chargers 2 Generator 3 Grid power 4 Solar panel MasterBus AC Loads: • Phone charger • Microwave • TV/DVD player • Receptacles • Washing machine • Water heater • Air-conditioning DC Load: • Breaker panel • Alternator • Bow-thruster Best in class performance The Mass Combi Ultra and Mass Combi Pro Inverter/Chargers can provide continuous inverter power at 105°F (40°C) with a 200% startup surge. The battery charger is best in its class providing a powerful charge to the main house battery bank. Ease of installation The carefully designed connections were optimized for installers. Installation and connection have been made quick and easy via a logic layout, solid terminals and by removing the need for cable glands. Dual AC inputs and outputs The Mass Combi Ultra and Mass Combi Pro Inverter/Chargers have inputs for generator or mains supply, each optimized for the power source. A robust intelligent transfer system switches seamlessly between AC power, generator and inverter, and ensures a constant power supply. Flickering lights or failure of electronic equipment belong to the past. Separate AC outputs provide the ability to power heavy users via mains and/or generator. Higher yield from solar power On the DC side the Mass Combi Ultra Inverter/ Chargers has interesting features such as the solar input and the second charger output. Mastervolt has leveraged on the knowledge gained in the grid-connected solar sector to make a super-efficient built-in MPPT solar charge regulator. Compared to most regulators on the market, the MPPT offers a far higher yield from solar power for charging your batteries. Home comforts The Mass Combi Ultra and Mass Combi Pro Inverter/Chargers feature separate AC outputs. One is permanently powered to supply critical loads such as refrigerators and audio systems. The other output is for non-preferential loads including water heaters that can be switched off automatically at any desired setting, always to the benefit of the critical loads. Optimal battery usage Based on Mastervolt’s many years of experience, the Mass Combi Ultra and Mass Combi Pro Inverter/Chargers feature a number of characteristics that ensure you get the most from your batteries in terms of maximum power and lifespan. Key examples include the pure, interference-free DC voltage that prevents unnecessary heating of the batteries and a low ‘no load’ current that guarantees every Ah is deployed in an optimal way. Quiet operation The Mass Combi Ultra and Mass Combi Pro Inverter/Chargers can provide up to 50% of the charging current or inverter capacity without fan cooling. This is perfect for night-time operation; if little power is consumed, the fan stops turning and goes silent. When maximum capacity is required, or the ambient temperature is very high, the Active Optima Cooling concept regulates the fan speed in a linear way, ensuring that it never spins too fast or makes any unnecessary ticking noises. 1 3 4 7 8 6 5 2 120V/240V split-phase operation For more powerful systems the Mass Combi Ultra and Mass Combi Pro Inverter/Chargers allow parallel use up to 10 units. With 240V input and the use of an auto transformer the units provide 120/240V split-phase. Powering the 120V and 240V ships AC loads. Auto Transformer L1 N L2 5 EasyView 5 6 DC Distribution system 7 AGM starter battery 8 Lithium Ion (LiFePO4) battery

mastervolt.us POWER CONVERSION 12 Mass Combi Ultra 12/3000-150 Mass Combi Ultra 24/3500-100 Mass Combi Ultra 48/3500-50 Part # 38013000 38023500 38343500 Specifications Sine Wave Inverter Nomimal DC voltage 12V (9.5–16V) 24V (19–32V) 48V (38–62V) Output voltage 180–260V, adjustable 180–260V, adjustable 180–260V, adjustable Output waveform true sine true sine true sine Continuous power at 104°F (40°C), cos phi 1 3000 W 3500 W 3500 W Surge capability 6000 W 7000 W 7000 W Parallel configuration For larger systems, an external transfer system is required yes, up to 10 standard yes, up to 10 standard yes, up to 10 standard 3-Phase configuration yes, up to 3x3 yes, up to 3x3 yes, up to 3x3 Max. efficiency ≥ 90% ≥ 92% ≥ 93% Energy saving mode consumption 7 W 7 W 7 W Specifications Battery Charger Max. charge current at 104°F (40°C) adjustable 150A at 14.25V 100A at 28.5V 50A at 57V Secondary charger output voltage 12V 12/24V selectable, 3-step+ 12/24V selectable, 3-step+ Secondary charger output current 10A 10A 10A Battery temperature sensor yes, included yes, included yes, included Specifications Transfer System AC input (generator) 50A (switched) 50A (switched) 50A (switched) AC input (mains) 30A (switched) 30A (switched) 30A (switched) AC output 1 67A 67A 67A AC output 2 50A (switched) 50A (switched) 50A (switched) Transfer speed seamless (< 1 ms) seamless (< 1 ms) seamless (< 1 ms) Solar Input DC Specifications Input voltage range 25–50V 25–100V n.a. Max. PV peak power 500 Wp 500 Wp n.a. Max. input current 19A 19A n.a. Max. charge current 30A at 14.25V 15A at 28.5V n.a. MPP Tracker full power at 25–50V full power at 35–80V n.a. General Specifications Display/read-out LED display LED display LED display Dimensions, hxwxd 18.6" x 12.5" x 7" 472 x 318 x 178 mm 18.6" x 12.5" x 7" 472 x 318 x 178 mm 18.6" x 12.5" x 7" 472 x 318 x 178 mm Weight 33.7 lb / 15.3 kg 33.7 lb / 15.3 kg 33.7 lb / 15.3 kg Approvals CE, E-mark, ABYC, RMRS CE, E-mark, ABYC, RMRS CE, E-mark, ABYC, RMRS Technical Specifications Charge characteristic IUoUo, automatic 3-step+ for AGM/Gel/MLI/flooded/traction/spiral Ground relay yes, configurable yes, configurable yes, configurable Temperature range (ambient temp.) -13°F to 140°F, derating > 104°F ( -25°C to 60°C, derating > 40°C) Cooling vario fan vario fan vario fan Protection degree IP23 (vertical mounting) IP23 (vertical mounting) IP23 (vertical mounting) Protections over-temperature, overload, short circuit, high/low battery voltage MasterBus compatible yes yes yes Options Temperature Sensors 41500500, 6M 41500800, 15M included option included option included option EasyView 5 77010310 option option option Waterproof system monitor with ‘daylight readable’ color display and intuitive multi-language touchscreen to show the key system information at a glance. There is also a logbook feature for warnings and alarms, along with a buzzer and alarm notifications. The home button gives access to favorite pages. Mastervolt USB Interface 77030100 option option option Communication port between MasterBus and the USB port of your PC; makes possible reading and configuration of your MasterBus systemon the PC when combined with MasterAdjust software (free to download). RJ12 communication / sync cable, available lengths: 3.3', 9.8', 19.7', 32.8' or 49.2' option option option High quality communication cable fitted with RJ12 type modular plugs, suitable for connecting a remote control panel Also suitable as a sync cable for Mass Combi Ultra or Mass Combi Pro Inverter/Chargers models, both in parallel or 3-phase configurations. Mass Combi Ultra & Mass Combi Pro Inverter/Chargers Specifications – 230V

mastervolt.us POWER CONVERSION 13 Mass Combi Pro 12/3000-150 Mass Combi Pro 24/3500-100 38513000 38523500 12V (9.5–16V) 24V (19–32V) 180–260V, adjustable 180–260V, adjustable true sine true sine 3000 W 3500 W 6000 W 7000 W yes, up to 10 standard yes, up to 10 standard yes, up to 3x3 yes, up to 3x3 ≥ 90% ≥ 92% 7 W 7 W 150A at 14.25V 100A at 28.5V n.a. n.a. n.a. n.a. yes, included yes, included 50A (switched) 50A (switched) 30A (switched) 30A (switched) 67A 67A 50A (switched) 50A (switched) seamless (< 1 ms) seamless (< 1 ms) n.a. n.a. n.a. n.a. n.a. n.a. n.a. n.a. n.a. n.a. LED display LED display 18.6" x 12.5" x 7" 472 x 318 x 178 mm 18.6" x 12.5" x 7" 472 x 318 x 178 mm 33.7 lb / 15.3 kg 33.7 lb / 15.3 kg CE, E-mark, ABYC CE, E-mark, ABYC IUoUo, automatic 3-step+ for AGM/Gel/MLI/flooded/traction/spiral yes, configurable yes, configurable -13°F to 140°F, derating > 104°F ( -25°C to 60°C, derating > 40°C) vario fan vario fan IP23 (vertical mounting) IP23 (vertical mounting) over-temperature, overload, short circuit, high/low battery voltage yes yes included option included option option option option option option option

mastervolt.us POWER CONVERSION 14 The CombiMaster inverter/charger delivers pure sine wave inverter power and multi-chemistry battery charging plus the intelligent new design communicates seamlessly with NMEA 2000, CZone, and MasterBus networks. Designed with the customer in mind and using the latest technology, the CombiMaster is all about user-friendliness and reliability. But don’t let that friendly appearance misguide you: the powerful CombiMaster range drives even the most complex and heavy loads with ease! With the CombiMaster, power dips and failures belong to the past. The automatic AC transfer system switches seamlessly between generator or mains and inverter output, ensuring a constant power supply. Its Power Assist function prevents tripping of the mains fuse in case you’re connected to a weak land line or small generator. The CombiMaster delivers unmatched performance at an unprecedented price. As you would expect from Mastervolt, the CombiMaster is completed with MasterBus, CZone and NMEA 2000 compatible communication, allowing for a broad range of monitoring and system integration options. The CombiMaster inverter/charger replaces the current Mass Combi. CombiMaster Inverter/Chargers old NEW bug new NEW bug

mastervolt.us POWER CONVERSION 15 Remote Control and Monitoring Options • MasterBus compatible via SmartRemote or EasyView 5 displays. • CZone compatible via Control X, Touch 5 or Touch 10. • NMEA 2000 compatible via 3rd Party MFD. CombiMaster Features • Dependable quality for leisure and semiprofessional applications • Most compact and lightweight inverter/charger in its class • Reliable, cost effective and hum-free • High power rating and >200% peak power to start even the heaviest loads • Pure sine technology prevents malfunctions and damage to electronic equipment • Low-loss HF technology allows for longer operation from your batteries • Powerful and Intelligent 3-step+ battery charger for fast and safe charging • Fast, automatic switching between mains and inverter mode • Power assist prevents blown mains fuses. • Generator compatible • Quick installation and heavy duty connections • UL, CE and E-mark certified • With a DC input voltage range from 10–18V DC and flat battery support at 25% under 10V. The new CombiMaster ensures fast, safe, and efficient charging of your Flooded, AGM, Gel, Li-ion batteries. • Wide AC input range (90-140V AC) insures functionality of AC devices even with adverse input power conditions • The new 24V models in 3500W & 4500W and 48V 5000W unit can create parallel and series stacked systems to power up to 35kW and be used to power split phase loads.

mastervolt.us POWER CONVERSION 16 CombiMaster Inverter/Chargers Specifications – 120V CombiMaster 12/1500-60 CombiMaster 12/2000-100 CombiMaster 12/3000-160 CombiMaster 12/3500-200 Part # 35511500 35512000 35513000 35513500 General Specifications Sine Wave Inverter Nominal DC voltage 12V (10.2–16V) 12V (10.2–16V) 12V (10.2–16V) 12V (10.2–16V) Continuous power at 104°F (40°C) 1500 W 2000 W 3000 W 3500 W Peak power (30 sec) 2250 W 3000 W 4500 W 5250 W Surge power (5 sec) 3000 W 4000 W 6000 W 7000 W Parallel Stacking no no no yes, up to 3 Synchronize with mains/generator yes yes yes yes Output voltage 120V (50/60 Hz, configurable) 120V (50/60 Hz, configurable) Output waveform pure sine pure sine pure sine pure sine Max. efficiency 93% 92% 90% 93% Max. ripple on DC (battery at full load) <15% <15% <15% <15% Battery no-load power consumption ≤30 W ≤30 W ≤30 W ≤30 W Energy saving mode consumption ≤10 W ≤10 W ≤10 W ≤20W General Specifications Battery Charger Input voltage range 90-140V 90–140V 90–140V 90–140V Max. input current 9 16.5 25 32 Max. charge current at 104°F (40°C) 60A@14.25V 100A@14.25V 160A@14.25V 200A@14.25V Battery temperature sensor yes, included yes, included yes, included yes, included Battery voltage sense yes, automatic yes, automatic yes, automatic yes, automatic Flat battery support (minimum charging) yes, below 10V @ 25% power yes, below 10V @ 25% power Continuous Battery Charge Output 60A DC 100A DC 160A DC 200A DC Temp Range -13°F to 140°F (-25°C to 60°C) -13°F to 140°F (-25°C to 60°C) Specifications Transfer System AC input 30A (switched) 30A (switched) 30A (switched) 50A (switched) AC output 40A 40A 40A 85A AC input fuse 30A 30A 30A 50A General Specifications Display/read-out LED display LED display LED display LED display Dimensions, hxwxd 14.6" × 11.2" × 6.1" 371 × 284 × 155 mm 17.6" × 11.2" × 6.1" 448 × 284 × 155 mm 17.6" × 11.2" × 6.1" 448 × 284 × 155 mm 22" × 14.2" × 6.7" 559 × 361 × 170 mm Weight 15.2 lb / 6.9 kg 20.5 lb/9.3 kg 20.5 lb / 9.3 kg 25 lb/11.3 kg Approvals ABYC A31, UL1236, UL1741, SAEJ1171, FCC class B ABYC A31, UL1236, UL1741, SAEJ1171, FCC class B Technical Specifications Charge characteristic IUoUo, automatic / 3-step+ for flooded, Gel/AGM, Lithium configurable Recommended battery capacity ~ 100–800 Ah (based on gel batteries, may differ for other types) ~ 200–1000 Ah (based on gel batteries, may differ for other types) Ground relay yes, selectable yes, selectable yes, selectable Yes, always on Temperature range (ambient temp.) -13°F to 140°F, derating 104°F (-25°C to 60°C, derating > 40°C) Cooling Forced Air / Fan 80mm Forced Air / Fan 80mm Forced Air / Fan 80mm Forced Air 92 or 120mm Protection degree IP23 IP23 IP23 IP23 Humidity protection conformal coating, max. 95% relative humidity, non condensing Protections over temperature, overload, short circuit, high/low battery voltage Power Assist yes yes yes yes Power Sharing yes yes yes yes Communciation MasterBus, NMEA 2000 CZone (config file needed for NMEA 2000 120V old NEW bug new NEW bug 120V 120V 120V EXPANDED OFFERING

mastervolt.us POWER CONVERSION 17 CombiMaster 24/2000-60 CombiMaster 24/3000-70 CombiMaster 24/3500-100 CombiMaster 24/4500-120 CombiMaster 48/5000-120 35522000 35523000 35523500 35524500 35545000 24V (20.4–32V) 24V (20.4–32V) 24V (20.0–32V) 24V (20.0–32V) 48V (40-64V) 2000 W 3000 W 3500 W 5000 W 5000W 3000 W 4500 W 4500 W 7500 W 750 0W 4000 W 6000 W 7000 W 9000 W 10000 W no no yes, up to 7 yes, up to 7 yes, up to 7 yes yes yes yes yes 120V (50/60 Hz, configurable) 120V (50/60 Hz, configurable) pure sine pure sine pure sine pure sine pure sine 92% 90% 93% 93% 93% < 5% < 5% < 5% < 5% < 5% ≤30 W ≤30 W ≤30 W ≤ 35 W ≤ 35 W ≤10 W ≤10 W ≤20 W ≤ 25 W ≤ 25 W 90–140V 90–140V 90–140V 90–140V 90–140V 16.5 25 32 41.5 41.5 60A@28.5V 70A@28.5V 100A@28.5V 120A@28.5V 70A @ 57V yes, included yes, included yes, included yes, included yes, included yes, automatic yes, automatic yes, automatic yes, automatic yes, automatic Yes, below 20V @ 25% power Yes, below 20V @ 25% power Yes, below 20V @ 25% power 60A DC 70A DC 100A DC 120A DC 70A DC -13°F to 140°F (-25°C to 60°C) -13°F to 140°F (-25°C to 60°C) -13°F to 140°F (-25°C to 60°C) 30A (switched) 30A (switched) 50A (switched) 50A (switched) 50A (switched) 40A 40A 85A 85A 85A 30A 30A 50A 50A 50A LED display LED display LED display LED display LED display 17.6" × 11.2" × 6.1" 448 × 284 × 155 mm 17.6" × 11.2" × 6.1" 448 × 284 × 155 mm 22" × 14.2" × 6.7" 559 × 361 × 170 mm 22" × 14.2" × 6.7" 559 × 361 × 170 mm 22" × 14.2" × 6.7" 559 × 361 × 170 mm 20.5 lb / 9.3 kg 20.5 lb / 9.3 kg 25 lb/11.3 kg 27 lb / 12.2 kg 27 lb / 12.2 kg ABYC A31, UL1236, UL1741, SAEJ1171, FCC class B ABYC A31, UL1236, UL1741, SAEJ1171, FCC class B IUoUo, automatic / 3-step+ for flooded, Gel/AGM, Lithium configurable ~100–800 Ah (based on gel batteries, may differ for other types) ~140–1000 Ah (based on gel batteries, may differ for other types) ~ 200–1000 Ah (based on gel batteries, may differ for other types) yes, selectable yes, selectable Yes, always on Yes, always on Yes, always on -13°F to 140°F, derating 104°F (-25°C to 60°C, derating > 40°C) Forced Air / Fan 80mm Forced Air / Fan 80mm Forced Air 92 or 120mm Forced Air 92 or 120mm Forced Air 92 or 120mm IP23 IP23 IP23 IP23 IP23 conformal coating, max. 95% relative humidity, non condensing over temperature, overload, short circuit, high/low battery voltage yes yes yes yes yes yes yes yes yes yes MasterBus, NMEA 2000, CZone (config file needed for NMEA 2000) old NEW bug new NEW bug 120V old NEW bug new NEW bug 120V old NEW bug new NEW bug 120V 120V 120V

mastervolt.us POWER CONVERSION 18 CombiMaster Inverter/Chargers Specifications – 230V CombiMaster 12/2000-60 CombiMaster 12/3000-100 CombiMaster 24/2000-40 CombiMaster 24/3000-60 Part # 35012000 35013000 35022000 35023000 General Specifications Sine Wave Inverter Nominal DC voltage 12V (10.2–16V) 12V (10.2–16V) 24V (20.4–32V) 24V (20.4–32V) Continuous power at 104°F (40°C) 2000V A / 1600 W 3000V A / 2600 W 2000V A / 1600 W 3000V A / 2600 W Peak power (30 sec) 3000V A / 2400 W 4500V A / 3900 W 3000V A / 2400 W 4500V A / 3900 W Surge power (5 sec) 4000V A / 3200 W 6000V A / 5200 W 4000V A / 3200 W 6000V A / 5200 W Synchronize with mains/generator yes yes yes yes Output voltage 230V 50/60 Hz, configurable 230V 50/60 Hz, configurable 230V 50/60 Hz, configurable 230V 50/60 Hz, configurable Output waveform true sine true sine true sine true sine Max. efficiency ≥ 93% ≥ 93% ≥ 93% ≥ 93% Max. ripple on DC (battery at full load) < 15% < 15% < 15% < 15% Battery no-load power consumption 20 W on mode / < 1 mA off mode 30 W on mode / < 1 mA off mode 20 W on mode / < 1 mA off mode 30 W on mode / < 1 mA off mode Energy saving mode consumption 10 W 10 W 10 W 10 W General Specifications Battery Charger Input voltage range 90–280V power derating below 170V 90–280V power derating below 170V 90–280V power derating below 170V 90–280V power derating below 170V Max. input current 6A (adjustable) 10A (adjustable) 8A 13A Max. charge current at 104 °F (40 °C) 60A at 14.25V, configurable 100A at 14.25V, configurable 40A at 28.5V, configurable 60A at 28.5V, configurable Battery temperature sensor yes, included yes, included yes, included yes, included Battery voltage sense automatic compensation automatic compensation automatic compensation automatic compensation Specifications Transfer System AC input 25A (switched) 25A (switched) 25A (switched) 25A (switched) AC output 33A 33A 33A 38A AC input fuse yes yes yes yes Transfer speed 10 ms for narrow input range, 20 ms for wide range, configurable 10 ms for narrow input range, 20 ms for wide range, configurable Transfer voltage range narrow input range (170-280V) wide range (90-280V) Transfer frequency range 40–65 Hz 40–65 Hz 40–65 Hz 40–65 Hz General Specifications Display/read-out LED display LED display LED display LED display Dimensions, hxwxd 14.6" × 11.2" × 6.1" 371 × 284 × 155 mm 17.6" × 11.2" × 6.1" 448 × 284 × 155 mm 14.6" × 11.2" × 6.1" 371 × 284 × 155 mm 17.6" × 11.2" × 6.1" 448 × 284 × 155 mm Weight 15.2 lb / 6.9 kg 20.5 lb / 9.3 kg 15.2 lb / 6.9 kg 20.5 lb / 9.3 kg Approvals CE, E-mark, AZ/NZS CE, E-mark, AZ/NZS CE, E-mark, AZ/NZS CE, E-mark, AZ/NZS Technical Specifications Charge characteristic IUoUo, automatic / 3-step+ for flooded, Gel/AGM and MLI, configurable IUoUo, automatic / 3-step+ for flooded, Gel/AGM and MLI, configurable Recommended battery capacity ~100–800 Ah (based on gel batteries, may differ for other types) ~200–1000 Ah (based on gel batteries, may differ for other types) ~100–800 Ah (based on gel batteries, may differ for other types) ~140–1000 Ah (based on gel batteries, may differ for other types) Ground relay yes, configurable by means of mechanical jumper yes, configurable by means of mechanical jumper Temperature range (ambient temp.) -13°F to 140°F, derating 104°F (-25°C to 60°C, derating > 40°C) Cooling vario fan vario fan vario fan vario fan Protection degree IP23 (vertical mounting) IP23 (vertical mounting) IP23 (vertical mounting) IP23 (vertical mounting) Safety class IEC protection class I IEC protection class I IEC protection class I IEC protection class I Humidity protection conformal coating, max. 95% relative humidity, non condensing conformal coating, max. 95% relative humidity, non condensing Protections over temperature, overload, short circuit, high/low battery voltage over temperature, overload, short circuit, high/low battery voltage Power Assist yes, will support AC input power from the battery yes, will support AC input power from the battery Power Sharing yes, allows you to select AC Input fuse setting yes, allows you to select AC Input fuse setting Communciation MasterBus & CZone MasterBus & CZone

mastervolt.us POWER CONVERSION 19 Introducing the PowerCombi Inverter/Charger from Mastervolt. PowerCombi is a pure sine wave inverter/charger offering grid quality AC power and battery charging in one low profile design. Designed to be an independent inverter/charger, yet can easily be integrated into a CZone/MasterBus network (with additional interface). With a built in transfer switch, 2x surge for 3s and on site dipswitch programming— the PowerCombi offers simple installation with multiple operating modes, and can charge various battery chemistries—including a custom profile for use with Li-ion. Full certifications make it perfect for use in RV's, boats, and specialty vehicles. Add a battery temperature sensor (BTS), remote display and a communication interface for custom applications. PowerCombi Inverter/Chargers Simple. Independent. Flexible PowerCombi 12V/1200W-50A PowerCombi 12V/2000W-100A Part # 36211200 36212000 Part # Kit (Includes Remote, BTS) 36211201 36212001 Specifications Continuous Power Rating 77°F (25°C) 1200 W 2000 W Continuous Power Rating 104°F (40°C) 1200 W 2000 W Surge 2400 W (3s) 4000 W (3s) AC Voltage/Frequency 120V-50/60Hz selectable HF - Pure 120V-50/60Hz selectable HF - Pure Idle Power Full 25 W 36 W Inverter Efficiency 89% 89% DC Input Voltage Range 10.0–15.5V DC 10.0–15.5V DC Nominal DC Voltage 12V 12V Flat battery support (minimum charging) NO (6V) NO (6V) Continuous Battery Charge Output 50A DC 100A DC DC Output (second) 20A DC 20A DC Battery Types Flooded, Gel, AGM, custom Flooded, Gel, AGM, custom Transfer Switch (Speed) 30A (10ms) 30A (10ms) Dimensions, hxwxd 15.19" x 9.88" x 4.57" (386 x 251 x 116 mm) 17.83" x 9.88" x 4.57" (453 x 251 x 116 mm) Weight 10.0 lb / 4.55 kg 13.5 lb / 6 kg Approvals UL458 & Supplement SA/CSA C22.2, UL 1741 no. 107.1-01KKK-A-1822F Technical Specifications Temperature range (ambient temp.) 4°F to 140°F (-20°C to 60°C) 4°F to 140°F (-20°C to 60°C) Communications MasterBus compatible via CZone - MasterBus Interface 77032900 Options Temperature Sensor 41500700 recommended recommended PowerCombi Remote Control 77010700 option option Control and monitor your PowerCombi inverter / charger via this easy to use remote monitor. The LCD display is used for setting up the inverter/charger operation, as well as viewing current status or fault messages. CZone/MasterBus PowerCombi Interface 77032900 option option By adding the CZone/MasterBus PowerCombi Interface to your installation, you can control the PowerCombi via the MasterBus communication network. A RJ45 communication cable is included in the delivery.

mastervolt.us POWER CONVERSION 20 Which Mastervolt inverter fits your needs? Mass Sine Ultra Inverter This model is intended for professional applications with high power demands, and extends the Mass Sine series. With 4 kW AC power, the Mass Sine Ultra Inverter meets the highest energy requirements. The latest technology increases the efficiency and enables multiple units to work in parallel and 3-phase configuration. Mass Sine Inverter These high quality sine wave inverters have proven themselves in the most extreme conditions for over twenty-five years. Although the dimensions and connections of the various models have remained the same, the technology has evolved, resulting in a fast, efficient, one-on-one replacement with minimal downtime. AC Master These affordable sine wave inverters convert 12V or 24V battery voltage into reliable grid power, making it ideal for recreational and semi-professional applications. Sine Wave Inverters: Enjoy the comforts of home Your AC installation offers you a wealth of benefits by making the use of any domestic appliance possible, from microwave oven to hair dryer, DVD player to power tools. A Mastervolt inverter allows you to easily convert the voltage of your 12V or 24V battery to 230V/50Hz or 120V/60Hz, so you enjoy all the comforts of home wherever you choose to go. Mastervolt offers a complete range of inverters from 300 watt to 40 kwatt, for 230V/50Hz as well as 120V/60Hz (American voltage). Completely independent Grid power regularly fluctuates and can cause your lights to flicker. Sometimes it may even drop below 180 volts causing some devices to stop functioning. The Mastervolt sine wave inverter ensures a perfect AC voltage, and makes power problems a thing of the past. The pure sine wave technology also helps protect your equipment against failures, humming or interference on monitors or TV’s and ensures a longer lifespan.

mastervolt.us POWER CONVERSION 21 No humming with HF technology Our use of high-frequency switch technology means you can say goodbye to humming transformers and hello to efficiency. Mastervolt inverters are also small and lightweight to ensure easy installation. Efficient use of batteries A high efficiency when inverting and an automatic economy mode when there is no consumption gives you longer use of your batteries. Simple and safe to connect The inverters feature robust connection technology, internal in the larger models and a plug & play socket with cable for the smaller models. MasterBus compatible Every Mass Sine (Ultra) inverter can be easily connected to a MasterBus network with only one cable and one connection. You can also choose central, local or remote monitoring, configuration and control of your system. High peak power during start up Mastervolt sine wave inverters can deliver high peak power (up to 200%) to equipment that requires extra current for a short period of time while powering up. Pure sine wave Mastervolt inverters generate a sine wave shaped output current similar or even better than that of the public grid and perfectly suited for powering sensitive equipment.

mastervolt.us POWER CONVERSION 22 Even under the most extreme conditions the products from the Mass series operate faultlessly, giving you round-the-clock output when necessary. With an MTBF of 180,000 hours at full capacity and 24/7 use, the Mass products are ideal for the toughest tasks and any situation that requires a reliable power supply. Optimal flexibility in system design Choosing an independent sine wave inverter allows you complete freedom of choice of battery charging equipment. You can freely adapt the rating of these chargers, depending on the desired charge time. In case you want to use renewable energy sources, you may want to choose an MPPT solar charge regulator. High efficiency The high efficiency and automatic economy mode is designed to allow digital clocks to work properly and ensure you many more hours of operation from your batteries. The application of high-frequency technology prevents any annoying humming and zooming sounds, while the high peak capacity ensures that the high inrush current required for electrical tools, for example, is seamlessly produced. Mass Sine Ultra and Mass Sine Inverters: For the toughest tasks

mastervolt.us POWER CONVERSION 23 Mass Sine Mastervolt’s Mass Sine inverters have been proving their value in the most extreme conditions for over 25 years. Clear indicators The Mass Sine Inverter features easy controls on the device itself. As inverters are often built in, we also supply an effective remote control panel, the C4-RI. In addition, the Mass can be controlled via its intuitive display, the EasyView 5, thanks to the integration of MasterBus communication using a MasterBus Inverter Interface or AC Power Analyser. Easy and safe connections The Mass Sine inverters provide robust and professional connections for fast and safe installation. Mass Sine Ultra With an AC capacity of 4000W in one unit, the Mass Sine Ultra Inverter can satisfy even the greatest energy demands. As ten units can be switched in parallel or 3x3 in a three-stage configuration, the Mass Sine Ultra Inverter can supply a capacity of up to 40 kW. The inverter provides full power at 104°F (40°C) and works smoothly even in extreme conditions such as engine rooms and technical spaces. Like all Mass products, the inverter is supplied in a compact and robust casing. This inverter is the best choice if you are looking for autonomous AC capacity of over 3 kW. Latest technology The extremely efficient power electronics save volume and weight with minimal sound levels and a very low ripple voltage which extends the lifespan of your batteries. At the same time, digital technology prevents any annoying flickering and voltage fluctuations. Make the most of your batteries The Mass Sine Ultra Inverter is equipped with a dynamic battery voltage window. Taking into account the type of battery and current, this function ensures the inverter can supply AC longer without overtaxing the batteries. Mass Sine Ultra and Mass Sine Features • For heavy duty work in professional and semi-professional applications • Full capacity at temperatures up to 104°F (40°C) • Pure sine wave output prevents failures and damage to connected sensitive equipment • High peak capacity for the seamless switching on of complex and heavy loads • Dynamic, battery-specific input current for an optimal use of every type of battery (Mass Sine Ultra Inverter) • Parallel configuration of up to ten devices for a capacity up to 40 kW (Mass Sine Ultra Inverter) • 3-Phase configuration for a capacity up to 36 kW (Mass Sine Ultra Inverter) • Integrated MasterBus (Mass Sine Ultra Inverter) or MasterBus compatible (Mass Sine Inverter) • Suitable for mobile applications • Professional connections • Automatic, reliable and safe operation • Optional: Masterswitch/Systemswitch for automatic selection of the desired energy source

mastervolt.us POWER CONVERSION 24 Mass Sine 12/2000* Mass Sine 24/800* Mass Sine 24/1500* Part # 230V 24012000 24020800 24021500 General Specifications Nominal battery voltage 12V 24V 24V Recommended battery capacity >200 Ah >50 Ah >150 Ah Output voltage (± 5%) 230V – 50Hz (± 0 .01Hz) 230V – 50Hz (± 0 .01Hz) 230V – 50Hz (± 0 .01Hz) P30 power at 104°F (40°C), cos phi 1 2000 W 800 W 1500 W Continuous power at 104°F (40°C), cos phi 1 1800 W 650 W 1200 W Peak load 4000 W 1600 W 2900 W Output waveform true sine true sine true sine Efficiency 92% 92% 92% Display/read-out LED display LED display LED display Parallel configuration no no no 3-Phase configuration no no no Dimensions, HxWxD 16.5" x 12.5" x 5.1" 420 x 318 x 130 mm 12.8" x 8.7" x 4.4" 325 x 220 x 111 mm 13.4" x 10.3" x 5.1" 340 x 261 x 130 mm Weight 22.3 lb / 10.1 kg 8.6 lb / 3.9 kg 13.7 lb / 6.2 kg Approvals CE, E-mark, ABYC A-31, RRR CE, E-mark, ABYC A-31 CE, E-mark, ABYC A-31 Technical Specification Technology HF switch mode HF switch mode HF switch mode Max. ripple on DC (battery) 5% RMS 5% RMS 5% RMS Input current (nominal load) 183A 36A 68A No load power consumption: • ‘on’ mode (230V) • energy saving mode 480 mA – 6 W 50 mA – 0.6 W 240 mA – 5.6 W 35 mA – 0.8 W 200 mA – 5 W 25 mA – 0.6 W Minimal DC fuse (slow blow)** 250A 63A 100A Minimal cable size 70 mm2 16 mm2 25 mm2 Harmonic distortion typical <5% <5% <5% Cos Phi all power factors allowed all power factors allowed all power factors allowed Temperature range (ambient temp.) -13°F–176°F, >104°F derating (-25°C–80°C >40°C derating) Cooling natural/forced natural/forced natural/forced Transfer System The Masterswitch/Systemswitch can be connected to all sine wave inverters Protection degree IP23 IP23 IP23 Protections over temperature, over load, short circuit, high/low battery voltage MasterBus compatible with MB Inverter Interface or AC Power Analyser with MB Inverter Interface or AC Power Analyser with MB Inverter Interface or AC Power Analyser AC connection internal internal internal Options Model C4-RI 70404110 option option option Remote control on/off for the Mass Sine Inverter. EasyView 5 77010310 option option option In combination with MasterBus Inverter Interface. Waterproof system monitor with ‘daylight readable’ color display and intuitive multi-language touchscreen to show the key system information at a glance. There is also a logbook feature for warnings and alarms, along with a buzzer and alarm notifications. The home button gives access to favorite pages. Mastervolt USB Interface 77030100 option option option In combination with MasterBus Inverter Interface. Communication port between MasterBus and the USB port of your PC; makes possible reading and configuration of your MasterBus system on the PC when combined with MasterView System software (free to download). MasterBus Inverter Interface 77030700 option option option Integrates the Mass Sine Inverter in a MasterBus network in a MasterBus network. AC Power Analyser 77031200 option option option Integrates the Mass Sine Inverter in a MasterBus network and measures the AC voltage, current and power. * Also available in 60 Hz: 2 000W model: Part # 24112000 800 W model: Part # 24120800 1500 W model: Part # 24121500 2500 W model: Part # 24122500 5000 W model: Part # 24195100 ** DC fuse depends on the cable size. Mass Sine and Mass Sine Ultra Inverters Specifications – 230V

mastervolt.us POWER CONVERSION 25 Mass Sine 24/2500* Mass Sine Ultra 24/4000 Mass Sine 24/5000* 24022500 26024000 24095100 24V 24V 24V >200 Ah >350 Ah >400 Ah 230V – 50Hz (± 0 .01Hz) 230V (± 2%) – 50/60 Hz selectable (± 0.005%) 230V – 50Hz (± 0 .01Hz) 2500 W — 5000 W 2000 W 4000 W 4000 W 5000 W 7000 W 9000 W true sine true sine true sine 92% ≥ 92% 92% LED display LED display LED display no yes, up to 10 units no no yes, up to 3x3 no 16.5" x 12.5" x 5.1" 420 x 318 x 130 mm 18.6" x 12.5" x 6.9" 472 x 318 x 178 mm 18.5" x 12.4" x 10" 470 x 315 x 254 mm 22.3 lb / 10.1 kg 33.1 lb / 15 kg 41.9 lb / 19 kg CE, E-mark, ABYC A-31 CE, E-mark, ABYC A-31 CE, E-mark, ABYC A-31 HF switch mode V6 HF switch mode HF switch mode 5% RMS 5% RMS 5% RMS 115A 200A 230A 250 mA – 6 W 25 mA – 0.6 W 660 mA – 16 W 300 mA – 7 W 250 mA – 6 W 50 mA – 1.2 W 160A 250A 1x 250A or 2x 125A 50 mm2 70 mm2 2x 70 mm2 <5% <1% <5% all power factors allowed all power factors allowed all power factors allowed -13°F–176°F, >104°F derating (-25°C–80°C >40°C derating) natural/forced natural/forced natural/forced The Masterswitch/Systemswitch can be connected to all sine wave inverters IP23 IP23 IP23 over temperature, over load, short circuit, high/low battery voltage with MB Inverter Interface or AC Power Analyser yes with MB Inverter Interface or AC Power Analyser internal internal internal option n.a. option option option option option n.a. option option n.a. option option n.a. option For detailed specifications, dimensional drawings, 3D files, images, certificates and manuals see mastervolt.us/inverters. The following models are also available in Quick Connect (OEM) version with a WAGO 770-103 connector and 25 cm cable: • Mass Sine Inverter 12/2000 230V, part # 24021002 • Mass Sine Inverter 12/2000 120V, part # 25012002

mastervolt.us POWER CONVERSION 26 These affordable sine wave inverters convert 12V or 24V battery voltage into reliable grid power, making them ideal for recreational and semi-professional applications. The AC Master series is easy to install and delivers full output, even under the most demanding conditions. The pure sine wave technology provides an outstanding power quality, ensuring the correct functioning of sensitive equipment. The usage of high frequency switching technology eliminates any annoying humming and buzzing sounds. Representing complete value for money, these ruggedly built inverters provide essential home comforts when you’re far from the nearest grid connection. Applications Both recreational and semi-professional use, where grid power varies or is unavailable. Applications include lighting, appliances, electric cooking and power tools. For (mobile) applications in your home, office or service vehicle, or during your holidays. AC Master Series Inverters: Reliable AC power for recreational and semi-professional use
