VENTED BATTERY CHARGERS
promariner.com
Model
12V to 12V
Battery to Battery
12V to 24V
Battery to Battery
24V to 12V
Battery to Battery
24V to 24V
Battery to Battery
12V
Alternator to Battery
24V
Alternator to Battery
Part #
05504
05505
05503
05502
05513
05514
DC Input (Volts/Amps)
12 Volts / 40 Amps
12 Volts / 40 Amps
24 Volts / 20 Amps
24 Volts / 20 Amps
12 Volts
24 Volts
Max DC Amps
12 Volts / 40 Amps
24 Volts / 20 Amps
12 Volts / 40 Amps
24 Volts / 20 Amps
12 Volts /
Up to 130 Amps
(varies w/ ALT size)
24 Volts /
Up to 130 Amps
(varies w/ ALT size)
Size (LxWxH)
11"x9.75"x2.5"
11"x9.75"x2.5"
11"x9.75"x2.5"
11"x9.75"x2.5"
11"x9.75"x2.5"
11"x9.75"x2.5"
Weight
8 lbs.
8 lbs.
8 lbs.
8 lbs.
8 lbs.
8 lbs.
Digital Mobile Charge
Advanced Electronic Battery Charging
DC to DC 4-Stage Charging...
Digital Mobile Charge40
is a breakthrough in battery to battery, on-the-water
charging technology. Simply connect to the engine crank battery and your
house electronic battery, allowing for up to 40 amps per hour to be transferred
to your house battery bank. Protects your engine battery while charging and
conditioning your house battery bank, using its all-digital C3 boost-mode-
charging technology.
Digital Mobile Charge130
alternator to battery on-the-water charging system
provides a significant increase in charging capacity of up to 130 amps. Simply
connect your alternator to the Digital Mobile Charge130, then connect Digital
Mobile Charge130 to your engine crank battery and house electronic battery bank.
Digital Mobile Charge130 will provide up to 130 amps per hour to your house battery
bank while protecting your engine battery and charging/conditioning your house
battery bank with its all-digital C3 boost mode charging technology.
•
In-Transit C3 Software Controlled, Multi-Stage Charging
Optimal fast charge, conditioning & maintenance. 4th stage provides on-demand
fast charge mode when needed.
•
C3 Software - Engine Battery Management
Intelligently monitors & manages the health of the engine battery while providing
maximum charge capacity to the auxiliary battery or bank.
•
C3 Intelligent Self-Calculating Absorption/Conditioning Mode
Automatic programming of charge/ absorption time based on discharge state of
auxiliary battery or bank resulting in a 100% charge while desulfating battery
plates and extending battery life.
•
On-Board C3 Digital Dash Includes Hi-Vis LEDs
Battery type, charge modes, temperature and fault conditions.
•
User Programmable Battery Type Selector
Select Flooded (lead-acid), AGM and GEL batteries.
•
Remote Temperature Probe Included
•
Built in Safety
Ignition protection, over temperature and over voltage protection. Intelligent alternator &
battery over temperature protection. Meets a boat’s demand for on-the-water power and
charging for 12 or 24 Volt DC systems, allowing for radar, lighting, live wells and other DC
systems to operate while managing and charging batteries when running your engine.
• Two Year Warranty
