Manage
|
Distribution Components
Manage:
Battery Distribution Accessories
+
=
+
+
Typical Cluster example
1x
49mm(1.9")
98mm(3.8")
147mm(5.8")
249mm(9.8")
.5x
1.5x
2.5x
49mm(1.9")
49mm(1.9")
49mm(1.9")
Product Footprints
Heavy-duty Busbars
777-BB4S-500
4 Stud
4
777-BB3S-650
3 Stud
4
777-BB5S-650
5 Stud
4
777-BB8S-650
8 Stud
4
Z Busbars
777-Z10W-200
10 Way
4
777-Z18W-200
18 Way
4
ANL Fuseholders
778-ANL
ANL
4
778-ANL2S
ANL with additional
cable clamping studs
4
778-ANLTP
ANL Through Panel
4
Class-T Fuseholders
778-T2S-400
225–400A
4
778-T2S-600
450–600A
4
Insulated Studs
IST-8MM-1S
Single 8mm
4
IST-8MM-2S
Double 8mm
4
IST-10MM-8MM
Double 10mm/8mm
4
IST-10MM-1S
Single 10mm
4
IST-10MM-2S
Double 10mm
4
IST-8MM-1SPT
Single 8mm with
power tapping plate
4
IST-10MM-1SPT
Single 10mm with
power tapping plate
4
