Z Busbars
Marinco BEP Products have created a completely new concept
for small cable termination with the Z-Bar range. These busbars
maximize power density by utilizing high and low level bars to
optimize cable runs, saving even more installation space.
Specifications:
• 10 Way and 18 Way versions
• 4x 6 mm (1/4") studs with anti-seize lubricant
• 4mm (5/32") terminals with captive lock washers
• 200A maximum per bar (2x 200A)
• 50 VDC
• Tinned CDA102 Copper conductors
• Stainless steel studs, washers, nuts for longevity in the
marine environment
• Metric threads
Description
Item #
OEM #
Footprint*
10 way, Z Busbar
777-Z10W-200
777-Z10W-200-B 1 x
18 way, Z Busbar
777-Z18W-200
777-Z18W-200-B 1.5 x
* See page 159 for Footprint details
Cable Entry Same Side Cable Entry Both Sides
(Rotate Top Bar 180°)
Manage:
Battery Distribution Accessories
Description Item #
OEM #
Footprint*
3 Stud Busbar
777-BB3S-650
777-BB3S-650-B 1 x
4 Stud Busbar
777-BB4S-500
777-BB4S-500-B 1 x
5 Stud Busbar
777-BB5S-650
777-BB5S-650-B 1.5 x
8 Stud Busbar
777-BB8S-650
777-BB8S-650-B 2.5 x
* See page 159 for Footprint details
NEW
NEW
NEW
NEW
Heavy-duty Busbars
Pro Installer Heavy Duty Busbars provide a robust means to
connect (bus) together the multitude large cables found in modern
electrical installations. These offer unrivaled flexibility to meet the
requirements of any installation, saving significant cost and space.
Specifications:
• 4 Stud-500A busbar: 8 mm (5/16") stainless steel studs
• 3, 5, and 8 stud-650A busbars: 10 mm (3/8") stainless steel studs
• Studs treated with anti-seize lubricant
• 50 VDC
• Tinned CDA102 Copper conductors
• Stainless steel studs, washers, nuts for longevity in the
marine environment
• Generous stud lengths, metric threads
Optimal space savings
with Pro Installer Link Bars
See page 164
Optimal space savings
with Pro Installer Link Bars
See page 164
