WATERPROOF BATTERY CHARGERS
promariner.com
ProSport Automatic Multi-Stage Charging Profile
ProSport’s fully automatic multi-stage performance charging process delivers five
sequenced modes of operation that are proven to extend the life of your batteries
and will fully charge your batteries each time. Stages include:
Stage 1 - System Check OK and Battery Analyzing
During this stage the ProSport red “Charge” LED will flash indicating ProSport is
analyzing all battery connections in addition to checking each battery is capable of
being charged. Upon completion the “System Check OK” indicator will illuminate
green followed by Stage 2 Charging.
Stage 2 - Charging
During this mode the “Charging” indicator will be red. The ProSport Series will use
all of its available charging amps (as controlled by temperature) until the battery
voltage is raised to 14.6V DC (Flooded lead-acid factory setting).
Stage 3 - Conditioning
During this mode the “Conditioning” status indicator will be amber. Batteries will
hold at 14.6V DC (factory set for Flooded lead-acid batteries) to complete charging
while conditioning each battery connected. Upon completion the ProSport will go
into its Energy Saver Mode.
Stage 4 - Auto Maintain (Energy Saver Mode)
During this mode the blue “Power” and green “Auto Maintain” LED's will be on
indicating Stage 2 charging and Stage 3 conditioning are completed. At this time
ProSport will initiate its Auto Maintain (Energy Saver Mode) which will monitor and
Auto Maintain batteries only when needed to maintain a full state of charge.
Stage 5 - Storage Recondition Mode
During this mode the ProSport “Storage Recondition Mode” green indicator will
illuminate with a slow fade in and out pulse. This indicates that while your
batteries/boat are in storage the ProSport will automatically recondition all
batteries for up to 3 hours once a month extending battery life and maximizing on
the water battery power performance.
14.6V DC Absorption
13.4V DC Maintenance
14.1V DC Absorption
13.8V DC Maintenance
High Performance
(HP) AGM*
14.7V DC Absorption
13.6V DC Maintenance
Color Battery Type
Charge Profile
Flooded (Lead-acid) /
STD AGM
GEL
PROGRAMMING CAP
14
13
12
11
Volts
Flooded
(lead-acid)
Gel
HPAGM*
Charging Conditioning
Auto Maintain
Monthly Storage Reconditioning
Average Voltage
Analyzing
*High Performance AGM profile ProSport20 Dual only
International
ProSport Series
with PFC
Selection
Global AC input
works with outlets
worldwide
Model
ProSport 6 PFC
ProSport 12 PFC ProSport 20 PFC ProSport 20 Plus PFC
Part #
43023
43026
43028
43029
DC Voltage Systems
12
12/24
12/24
12/24/36
Amps
6
12
20
20
No. of Batteries
1
2
2
3
AC & DC Cable Length
6'
6'/6'
6'/6'
6'/6'/6'
Size
7.125"x7.25"x2.75" 9.875"x7.25"x2.75" 12.125"x7.25"x2.75" 12.125"x7.25"x2.75"
Weight
2 lbs
4 lbs
5 lbs
6 lbs
Global AC in (PFC)
100-260V AC 50/60
Hz
100-260V AC 50/60
Hz
100-260V AC 50/60
Hz
100-260V AC
50/60 Hz
Model
ProSport 6
ProSport 8
ProSport 12
ProSport 15*
ProSport 20
ProSport 20 Plus
Part #
43006
43008
43012
43015
43020
43021
DC Voltage Systems
12
12/24
12/24
12/24/36
12/24
12/24/36
Amps
6
8
12
15
20
20
No. of Batteries
1
2
2
3
2
3
AC & DC Cable Length
6'
6'/6'
6'/6'
6'/6'/6'
6'/6'
6'/6'/6'
Size
7.125"x7.25"x2.75" 9.875"x7.25"x2.75" 9.875"x7.25"x2.75" 10.825"x7.25"x2.75" 12.125"x7.25"x2.75" 12.125"x7.25"x2.75"
Weight
2 lbs
3 lbs
4 lbs
6 lbs
5 lbs
6 lbs
AC In
120V AC 50/60Hz
120V AC 50/60Hz
120V AC 50/60Hz
120V AC 50/60Hz
120V AC 50/60Hz
120V AC 50/60Hz
*OEM only
UK
90140
Australia
90130
US
90100
Europe
90110
Brazil
90170
c13 plug adapters
ProSport PFC IEC 6 foot power
cord is compatible with available
in country c13 plug adapters as
shown (not included)
I
N
T
E
R
T
E
K
L
I
S
T
E
D
CM
C
US
ProSport Series
Selection
