ISOLATORS
promariner.com
ProIsoCharge Series
Intelligent Alternator Power Distribution System
Significantly Smarter...
ProIsoCharge delivers digitally controlled alternator output distribution while
protecting the health of engine start batteries, isolating and charging up to
3 other independent battery banks off of a single alternator (model specific).
For dual engine applications, ProIsoCharge offers an exclusive 2 alternator
input model with up to 4 battery banks. Save space and time by eliminating
traditional diode based isolators and ancillary voltage sensitive relays or
solenoids, isolating and charging multiple battery banks simultaneously.
Eliminate typical alternator voltage loss of up to .6V DC that is commonly
associated with traditional diode based isolators. Intelligent zero volt loss
isolation insures fully charged batteries and faster charge times. Installed
with the ProNauticP Series, a boat owner can enjoy the full benefit of shore
power and on the water charging. Designed to provide more time on the water
enjoying what you like most...boating.
•
ProMar Digital Performance Zero Volt Loss Isolation and Charging
All digital design delivers active battery status and automatic engine battery health
priority while digitally distributing the full output of your engine’s alternators.
•
Intelligent Isolation and Charging Software Control
ProIsoCharge’s intelligent software control provides priority charging to a battery
bank that is under load (i.e house bank or power inverter bank) by taking fully
charged batteries off line and priority charging discharged battery banks, while
insuring the health of the engine batteries.
•
Real Time LED Status Indicators
Highly visible LEDs to indicate alternator power is present and battery bank charging
status. Fault LEDs include: high and low alternator output, over-voltage protection
and high voltage conditions that may be present on any one of the battery banks
connected (that are also connected to other charging sources gen set combi etc).
•
Ignition Controlled
Distributed On Demand™ battery bank management will only activate with ignition
power on.
•
Advance Regulator Ready
Advance regulator remote sense connection provided for precision alternator
algorithm control for alternators equipped with an advanced regulator.
•
Easy Installation
Modular design for easy install. Includes all terminal stud insulator boots and
protective snap on safety cover.
•
Built-in Safety
Ignition protected
• Five Year Warranty
Model
ProIsoCharge120 1•2 ProIsoCharge180 1•2 ProIsoCharge120 1•3 ProIsoCharge250 1•2 ProIsoCharge180 1•3 ProIsoCharge250 1•3 ProIsoCharge130 2•4
Part#
23121
23122
23124
23123
23125
23126
23127
Volts
12V
12V
12V
12V
12V
12V
12V
Max DC Amps
120 Amp
180 Amp
120 Amp
250 Amp
180 Amp
250 Amp
130 Amp
Alternator Input
1
1
1
1
1
1
2
Battery Outputs
2
2
3
2
3
3
4
Size (LxWxH)
5.35"x5.875"x3.125" 6.15"x5.875"x3.125" 6.15"x5.875"x3.125" 6.95"x5.875"x3.125" 7.55"x5.875"x3.125" 8.875"x5.875"x3.125" 12.05"x5.875"x3.125"
Weight
2 lbs
3 lbs
3 lbs
4 lbs
5 lbs
6 lbs
7 lbs
Model
ProIsoCharge60 1•2 ProIsoCharge100 1•2 ProIsoCharge60 1•3 ProIsoCharge100 1•3 ProIsoCharge150 1•3 ProIsoCharge80 2•4
Part#
23241
23242
23245
23246
23247
23248
Volts
24V
24V
24V
24V
24V
24V
Max DC Amps
60 Amp
100 Amp
60 Amp
100 Amp
150 Amp
80 Amp
Alternator Input
1
1
1
1
1
2
Battery Outputs
2
2
3
3
3
4
Size (LxWxH)
5.35"x5.875"x3.125" 6.15"x5.875"x3.125" 6.15"x5.875"x3.125" 7.55"x5.875"x3.125" 8.875"x5.875"x3.125" 12.05"x5.875"x3.125"
Weight
2 lbs
3 lbs
3 lbs
5 lbs
6 lbs
7 lbs
IP66
