ISOLATORS

promariner.com

ProSafeFS Series

Galvanic Isolator

Protecting your Boat’s Outdrive, Props and Metal Fittings while Maximizing

Zinc Life...

The ProSafe FS Series of FailSafe 30 and 60 Amp Galvanic Isolators will interrupt

galvanic current flow with other boats at a marina when installed on a boat which is

connected to AC Shore Power. This technology maintains AC safety ground and solves

the most common forms of corrosion and premature zinc loss within a boats bonding

system. The ProSafe FS Series is UL Certified to meet the parameters of the ABYC A-28

recommendation ProSafe FS installs easily and does not require a dedicated monitor

to verify the operational status of the galvanic isolator as required by non FailSafe

Certified galvanic isolators. Both the ProSafe 30 and 60 Amp models are built on

robust Flat Pack Semiconductor platforms, ensuring that in the event of a failure, the

failure is safe by not compromising the ground continuity on-board when connected

to AC Shore Power.

ABYC A-28 July ’08 Compliant and Fail Safe Certified

Certified by Underwriters Laboratories (UL). Insures shore power safety ground wire

is maintained through the isolator.

Flat Pack High Power Semiconductors

Robust high power diodes allow the FS Series to meet the new FailSafe criteria for

conducting inrush currents 3,000 and 5,000 amps (FS30 and FS60 respectively) for

the required duration period.

Innovative Design

The FS60 will cool itself in the event it must conduct current insuring cooler operation

in this mode.

Ignition Protected

Meets ISO 8846 and either model can be mounted within an engine compartment.

Gold Plated Terminations

Simply install in your on board green safety ground wire (between your AC inlet and your

AC Panel) to separate your D.C. Bonding System from your Shore A.C Green wire.

• ProSafe FS30 for 30 Amp Shore Cord Applications. ProSafe FS60 for (1) 50 Amp or (2) 30

Amp Shore Cord Applications

• 5 Year Warranty

Unprotected Outdrives

Unprotected sail drive

Unprotected and premature transom & outdrive zinc loss

Model

ProSafeFS30

ProSafeFS60

Part #

22034

22074

Shore Cord Inlet

Compatibility

Single 15, 16, 20 or 30

120/240V AC / 82A / 50 or 60 Hz

Ratings V AC / AMPs / Hz

120/240V AC / 41A / 50 or 60 Hz 120/240V AC / 82A / 50 or 60 Hz

Max Temp.

50˚ C

50˚ C

Size

6.75"x7"x2.5"

7.25"x6.5"x3.75"

Weight

3 lbs

3.7 lbs
